Reflectorless total station HTS-820

with prismPC-controllablemotorized

Overview
The HTS-820 from Hi-Target is a robotic total station engineered for single-operator surveying on challenging terrain and complex construction sites. Its hybrid tracking fuses multiple sensor inputs to maintain prism lock through obstructions and to automatically reacquire targets. Intelligent imaging-based stationing removes manual centering and instrument height measurement, providing automatic stationing with up to 1 mm accuracy. Rental options available.

Key system features
The drive motor achieves a maximum rotation speed of 180°/s with direction-change time under 3.5 s and angular positioning accuracy ≤2″. Smart Prism Search offers two modes: 360° Super Search (planar laser) for 20–300 m and AI Search (camera + AI) for up to 20 m. Optional Pole Control System (UHF+IMU or UHF+GNSS+IMU) permits full remote control beyond 600 m with automatic tilt compensation and GNSS-based control-free setup.

Electronics & software
Powered by a Qualcomm octa-core 1.8 GHz CPU with 3 GB RAM and 32 GB ROM. Features a 5.5″ touchscreen (720×1440 px, ≥500 cd/m²), 2 MP camera, LTE/WiFi/Bluetooth connectivity and Android OS. IP65-rated enclosure. On-board software: T-Survey; external controller: Hi-Survey.

Main applications

• Single-operator topographic survey
• Staking out and layout
• Infrastructure surveying: bridges, dams, tunnels
• Machine control and as‑built verification

Technical features

• Model: HTS-820
• Brand: Hi-Target
• Angle measurement — Principle: Rotary absolute encoder
• Angle measurement — Accuracy: 2″
• Compensator: Dual-axis, range ≥6′, accuracy ≤1″
• Distance range (prism): 1.5 m – 3,500 m
• Distance range (reflective sheet): 1.5 m – 500 m
• Distance accuracy (prism): 2 mm + 2 ppm
• Distance accuracy (reflective sheet): 3 mm + 2 ppm
• Max rotation speed: ≥180°/s
• Direction change time: ≤3.5 s
• Control positioning accuracy: ≤2″
• Telescope magnification: 30×
• Field of view: 1°30′
• Minimum focus: 1.5 m
• Guide light range: 5–150 m
• Display: 5.5″ touch, 720×1440 px, ≥500 cd/m²
• Processor: Qualcomm octa-core 1.8 GHz
• RAM / ROM: 3 GB / 32 GB
• OS: Android
• Camera: 2 MP
• Connectivity: LTE, WiFi 2.4 GHz dual-band, Bluetooth BT2.1+EDR/3.0/4.2 LE
• Interface: Type-C, TF card slot
• Battery: 70.56 Wh — duration ≥4.5 h
• Dimensions: 226×227×423 mm
• Weight: 8,000 g
• Operating temperature: −30°C to +50°C
• Storage temperature: −40°C to +70°C
• IP rating: IP65
• Prism search modes: 360° Super Search (20–300 m, planar laser); AI Search (up to 20 m)
• Pole Control (optional): remote control beyond 600 m with UHF+IMU or UHF+GNSS+IMU; GNSS control-free setup
• Intelligent imaging stationing: automatic centering and instrument height calculation up to 1 mm accuracy

Communication Box (optional)

• Dimensions: 102×95×128 mm
• Weight: 406 g
• Processor: Dual-core 1.2 GHz
• RAM / ROM: 128 MB / 8 GB
• UHF radio: 900–920 MHz, 26 dB
• Battery life: ≥10 h
• Power consumption: ≤35.28 Wh
• RTK accuracy (H/V): 8 mm + 1 ppm / 15 mm + 1 ppm RMS
• RTK tilt: ±3 cm (≤30°)
• Optical tilt accuracy: 3 mm + 0.6 mm/° (2σ, 0°–60°)
