Infrared thermometer CTlaser 1M series

digitalfixedindustrial

The Optris CTlaser 1M series is an advanced infrared thermometer known for its high performance and precision in very high-temperature measurement applications, such as molten steel, tungsten, iron, nickel, and semiconductors. Featuring double laser spot marking, a stainless steel sensing head (M48x1.5), and separate configurable electronics, this pyrometer ensures adaptability and accuracy across various applications. Having a two-piece design allows for straightforward installation, facilitating cost-effective mechanical integration. In terms of spectral range and optical resolution, the CTlaser 1M series operates at a specialized range of approximately 1.0 µm, making the IR sensor a reliable choice for accurate temperature measurement in hot applications. The high optical resolution, ranging from 150:1 to 300:1 depending on the model, is crucial for measuring temperatures of very hot, shiny materials with reduced sensitivity to emissivity variations. Covering temperatures from 485 °C to 2200 °C, the series is suitable for extremely high-temperature environments. With response times starting from 1 ms, the CTlaser 1M series excels in dynamic processes requiring rapid temperature measurements. The Optris CTlaser 1M stands out with its double laser aiming marks, which precisely indicate the real spot location at any distance, enhancing accuracy in temperature monitoring. Unlike conventional IR thermometers with single lasers that mark only the center of the spot, the CTlaser 1M’s innovative double laser sighting system provides valuable aiming support into the spot size and ensures accurate alignment.
