Handheld bender HB632
hydraulicsteel tube

handheld bender
handheld bender
Add to favorites
Compare this product


Characteristics

Configuration
handheld
Operation
hydraulic
Product handled
steel tube
Bending capacity

Max.: 2 in

Min.: 0 in

Bending radius

Max.: 1.5 in

Min.: 0.37 in

Description

Parker's hydraulic tube bender, HB632, is powered by 10,000 psi of pressure to bend steel and stainless steel tube up to 2” and 50mm O.D., and pipe up to 1 ½”. The hydraulic power, size capabilities and accurate bends make this draw bender a great choice for high production bending. Markets: • Construction • Military Ground Systems • Aerial Lift • Agriculture • Material Handling • Military Marine • Machine Tool • Transportation • Alternative Energy • Off-Shore/Oil & Gas Features/Benefits: • The clamp vise arm features a quick release speed screw for positioning the required clamp block. • The hydraulically actuated drive mechanism enables the operator to make bends up to 180° in one continuous smooth operation on tubing up to 2” in diameter. • An adjustable stop ensures the accuracy of bends by controlling the degree of the bend to a maximum of 180° and graduated in 1° increments. • Close second bends can also be performed in either direction. • Bends steel and stainless steel of tube in sizes 3/8” up to 2” and 10mm up to 50mm, as well as pipe in sizes 3/8” up to 1 ½”. Applications: • Bending metal tube for industrial and mobile applications Technical Characteristics: • Minimum components required with the HB32 bender are a hose assembly, hydraulic pump, and a radius slide and clamp block, which match the tube/pipe O.D. to be bent. • Radius blocks for 1 ¾” through 2” O.D. require an adapter plate. • The maximum bend angle is 180° with radii from 1 ¼” to 8”. •If mandrels are used, the HB632 hydraulic bender must be bolted to atable,
