Liquid nozzle KYA seriescoolingflat spraystainless steel
Add to favorites
Compare this product
Characteristics
- Fluid
- for liquids
- Function
- cooling
- Stream
- flat spray
- Material
- stainless steel, brass, forged steel
- Applications
- for the steel industry, for cooling systems
- Other characteristics
- threaded, quick-connect
- Flow
Max.: 19.5 l/min
(5.15 us gal/min)Min.: 2.94 l/min
(0.78 us gal/min)- Pressure
Max.: 10 bar
(145 psi)Min.: 1 bar
(14.5 psi)
Description
KYA type special flat fan jet nozzles are the best solution to cool forged steel rolls on continuous casting machines with high spray width values. The direction of the two jets is designed to obtain maximum cooling efficiency over a long reach.
It is available in four different versions: standard (C) or long (L) body, metric thread (A) or quick coupling (X).
Catalogs
No catalogs are available for this product.
See all of PNR Italia‘s catalogsOther PNR Italia products
