Corrosion protection coating service Glossyplate

wear-resistantprotectivehydro-oleophobic

General description
It offers multiple cosmetic and fanciful finishes, bringing out the anti-corrosive properties of steel. Excellent resistance to dampness.

General

• Excellent flexibility to obtain 0T without cracking.
• Good resistance against scratching. Good resistance to abrasion. Pressurised-water cleaning test for 1 hour, 100 bars at 20 cm = no detachments. Excellent resistance to chemicals and cleaning products.
• Good resistance to stains. Easy cleaning.
• Excellent resistance to dampness.
• Inert material, food safe.

Product behaviour
DESCRIPTION | TESTING STANDARD | UNIT | RESULT | OBSERVATIONS
Total coating thickness | EN 13523-1 / ASTM D1005 | µ | 150 | depending on film reference
Specular Gloss (Gardner 60º) | EN 13523-2 / ASTM D523 | % | > 90 | depending on film reference
Colour difference | EN 13523-3 / ASTM D3363 | | ΔE ≤ 1,5 | depending on film reference
Pencil hardness | EN 13523-4 / ASTM D2794 | | H – 2H |
Resistant to rapid deformation | EN 13523-5 / ASTM E643 | joules | 18 | without detachment
Adherence after Erichsen cupping | EN 13523-6 / ASTM E643 | mm | 8 |
T Bending | EN 13523-7 / ASTM D522 | | 0T | without cracking or separation
Resistance to salt spray | EN 13523-8 / ASTM B117 | hours | > 300 | 3mm max. detachment
Resistance to accelerated Xenotest ageing test | EN 13523-10 / ASTM D6695 | hours | > 350 | ΔE < 1
Resistance to MEC friction test | EN 13523-11 / ASTM D5402 | DF | > 150 | without change
Stain resistant (strawberry, orange, butter, fried tomato, mustard, lipstick, oil, milk, coffee, tea, chocolate, and soap) | EN 13523-18 / ASTM D1308 | | stain free | after 24 hours

Caractéristiques / spécifications techniques

• Total coating thickness: 150 µ (depending on film reference).
• Specular gloss (Gardner 60º): > 90% (depending on film reference).
• Colour difference: ΔE ≤ 1,5 (depending on film reference).
• Pencil hardness: H – 2H.
• Resistance to rapid deformation: 18 J without detachment.
• Erichsen cupping (adherence): 8 mm.
• T Bending: 0T without cracking or separation (excellent flexibility).
• Resistance to salt spray: > 300 hours (3 mm max. detachment).
• Resistance to accelerated Xenotest ageing: > 350 hours (ΔE < 1).
• Resistance to MEC friction test: DF > 150 without change.
• Stain resistance: stain free after 24 hours for a wide range of substances (listed above).
• Good resistance to scratching and abrasion; excellent resistance to chemicals and cleaning products.
• Easy cleaning; excellent resistance to dampness.
• Inert material, food safe.
• Typical industry application: Domestic Appliances.
