Wear-resistant coating service Thermoplate -PFAS FREE-

abrasion-resistantchemical protectionnon-stick

Product overview
PFAS-free non-stick coating formulated for industrial and food-contact applications. Combines excellent release properties with high scratch and abrasion resistance while retaining good formability and chemical inertness.

General

• Excellent non-stick performance
• Good resistance to temperature and abrasion
• Inert to chemical agents
• Good mechanical forming capacity
• Food contact certificate according to Directive 2004/1935/EC
• PFAS-free formulation designed for safe use in food-related manufacturing

Product behaviour (table)
Total coating thickness — TESTING STANDARD: EN 13523-1 / ASTM D1005 — UNIT: µ / Mils — RESULT: Single layer 6-8 µ (0.24–0.32 mils); Double layer 12-16 µ (0.47–0.63 mils) — OBSERVATIONS: Single layer / Double layer
Specular Gloss (Gardner 60º) — TESTING STANDARD: EN 13523-2 / ASTM D523 — UNIT: % — RESULT: 10–90 — OBSERVATIONS: Depending on colour and type
Pencil hardness — TESTING STANDARD: EN 13523-4 / ASTM D3363 — RESULT: > 3H
Mesh impact — TESTING STANDARD: EN 2409 / ASTM D3359 — RESULT: OK — OBSERVATIONS: Without detachment
Mesh impact after 15 min. and 1 hour in boiling water — RESULT: Class 0 / 5B — OBSERVATIONS: Without detachment
T Bending — TESTING STANDARD: EN 13523-7 / ASTM D522 — UNIT: T — RESULT: 0 - 0.5T — OBSERVATIONS: Without detachment or cracking
Resistance to NMP (N-methyl pyrrolidone) — RESULT: 90 sec
Abrasion test (RAT) — TESTING STANDARD: EN 13523-16 / ASTM D4060 — UNIT: cycles — RESULT: > 4000
Resistance to temperature — TESTING STANDARD: EN 13523-13 / ASTM D3045 — UNIT: ºC / ºF — RESULT: > 230ºC continuous and > 260ºC intermittent ( > 446ºF continuous and > 500ºF intermittent)

Characteristics / Technical specifications

• Product name: Thermoplate (PFAS-free coating)
• Non-stick performance: excellent
• Coating thickness: single layer 6–8 µ (0.24–0.32 mils); double layer 12–16 µ (0.47–0.63 mils)
• Specular gloss range: 10–90% (dependent on colour/type)
• Pencil hardness: greater than 3H
• Mesh impact: OK, without detachment
• Boiling water adhesion: Class 0 / 5B, without detachment after 15 min and 1 hour
• Flexible bending: 0–0.5T without detachment or cracking
• NMP resistance: 90 seconds
• Abrasion resistance: greater than 4000 cycles (RAT)
• Temperature resistance: continuous >230ºC; intermittent >260ºC
• Chemical behavior: inert to chemical agents
• Formability: good mechanical forming capacity
• Compliance: food contact certificate according to Directive 2004/1935/EC
