fixed caster / base plate / heavy-duty / steel
76 series

{{requestButtons}}

Characteristics

  • Type:

    fixed

  • Mount:

    base plate

  • Other characteristics:

    heavy-duty, steel

  • Load capacity:

    7,000 lb (3,175 kg)

Description



RWM Casters 76 Series industrial casters feature the patented Kingpinless™ caster design. This is the design that RWM patented, and that has proven to be the best solution for demanding heavy duty applications. This is the caster design that all others are copying because it is simply unmatched in extending service life, reducing all possible causes for caster failure.

The 76 Series offers up to 7000 lb. capacity and is available with a wide variety of wheels in 3" width. This caster is designed with beefier legs and extended leads making it an excellent option for towing operation in automotive assembly plants, tire manufacturing and heavy duty industrial applications demanding a superior product. All swivel sections are supplied with a lubrication fitting for field maintenance. The 76 series is case hardened for extended service life. It will not crack like through hardened or induction hardened construction provided by other caster manufacturers. Our 76 series industrial casters are proudly made in the USA! Log in below to download free 2D or 3D CAD drawings and models of this caster. If our standard product line doesnt meet your specifications, give us a call. Custom design and production of custom casters for application specific standards is our specialty!
Features
Raceway Design: Patented Kingpinless™ single ball bearing precision machined raceway hardened to 53 Rockwell C minimum. Swivel section features 3" diameter raceway with 1/2" ball bearings. The notched raceway is standard.
Capacity: 7,000 lbs.
Leg Thickness: 3/8"
Axle: 3/4" bolt with lock or slotted nut as required
Finish: Laguna Blue paint
