Multi-touch screen panel PC SP211

with touch screencapacitive touch screentouch screen

Product Overview
The SP211 is a 21.5-inch industrial panel PC designed for large-format HMI, monitoring and control applications. It ships with Windows 11 Pro / IoT / Home, with Windows 10 available as an option. The unit integrates a 1080×1920 TFT-LCD with 10-point capacitive touch, multiple CPU options (Intel Celeron J6412 standard; optional Intel Core 6th/7th/8th gen or Phydium D2000), scalable memory and storage, and rugged mechanical and I/O design including aviation-style connectors and dual RS232.

Key Features

• Operating systems: Windows 11 Pro / IoT / Home (Windows 10 optional).
• Processor options: Intel Celeron J6412 (quad-core, 2.00 GHz, turbo up to 2.60 GHz, 10W TDP); optional Intel Core (6th/7th/8th gen) or Phydium D2000.
• Display: 21.5" 1080×1920 TFT-LCD with 10-point capacitive touch (multi-touch), typical 200 nits, max 250 nits.
• Graphics: Intel UHD Graphics (16 EUs).
• Memory & storage: standard 16 GB RAM / 256 GB ROM; RAM 8 GB optional; ROM options 128 / 256 / 512 GB.
• Connectivity: Wi‑Fi 802.11a/b/g/n (2.4G WiFi4), Wireless AP support; dual RS232 for legacy equipment.
• I/O: Aviation plug style connectors; DC-IN ×1; HDMI ×1; USB3.0 ×2; USB2.0 ×1; LAN ×1; RS232 ×2 (DB9).
• Ruggedization: IP65 dust/water protection, wide operating temperature range for harsh environments.

Technical Specifications

• OS: Windows 11 Pro / IoT / Home (Windows 10 optional).
• CPU: Intel Celeron J6412 (quad-core, 2.00 GHz, turbo 2.60 GHz, 10W TDP); optional Core 6th/7th/8th gen or Phydium D2000.
• GPU: Intel UHD Graphics (16 EUs).
• RAM/ROM: Standard 16GB/256GB; options: RAM 8GB, ROM 128/256/512GB.
• LCD: 21.5" 1080×1920 TFT-LCD, 200 nits (TYP) / 250 nits (MAX).
• Touch: 10-point capacitive multi-touch.
• Wireless: 802.11a/b/g/n; Wireless AP (Mobile AP); 2.4G WiFi4.
• Audio/Multimedia: Photo viewer BMP/JPG/GIF/PNG; video codecs up to 1080p; multiple audio formats (DTS may require license).
• Environmental: IP65; Operating temp -20°C to 55°C; Storage -30°C to 60°C.
• Mechanical: Dimensions 524 × 315.5 × 45 mm; weight ~5300±50 g (unit), ~5900±50 g (with accessories).

Accessories & Options

• Standard: packaging box, DC charger (12V 4A), Wi‑Fi antenna ×2, screws, aviation plug cables ×8.
• Optional: VESA bracket, speaker, alternate CPU configurations, additional ROM/RAM capacity.

Typical Applications

• Industrial monitoring and control stations, large equipment HMI, process control consoles, industrial command centers requiring rugged, large-format touch interfaces.
