Control knob MNP3

Product
MNP3 swivel knob

Description
The MNP3 swivel knob is molded in high-mechanical-strength thermoplastic (PP). Heat-resistant grades and other resistance grades are available on request. Standard colour: Black; other colours available for suitable quantities.

Table - ROTARY KNOB MODEL MNP3
CODE | ITEM | A | B | C | PCS BOX
EMNP312520 | MNP3/120/FLP - D20 | 120 | 40 | 20 | 50
EMNP312522 | MNP3/120/FLP - D22 | 120 | 40 | 22 | 50

Certifications / Marks

• RoHS compliant
• REACH compliant
• Heat resistance: 80 °C
• Material: PP (polypropylene)

Technical characteristics / specifications

• Model: MNP3
• Material: High-mechanical-strength thermoplastic (PP)
• Available material grades: Heat resistant and other resistance grades (on request)
• Standard colour: Black; other colours available for suitable quantities
• Typical items and dimensions: EMNP312520 — MNP3/120/FLP - D20 — A: 120 mm — B: 40 mm — C: 20 mm — 50 pcs/box; EMNP312522 — MNP3/120/FLP - D22 — A: 120 mm — B: 40 mm — C: 22 mm — 50 pcs/box
• Compliance: RoHS, REACH
• Maximum indicated heat resistance: 80 °C (as per marking)
