Waste separator MSB

magnetic beltcompactdensity

Reduce wear levels of shredding machines or recover stainless steel during metal recovery using a magnetic separator Our STEINERT MSB rotary magnetic belt separator includes a conveyor belt and a STEINERT BR magnetic head pulley. This is equipped with permanent magnets to suit the field of application. Whilst the magnetic field at the head of the pulley remains constant, the sorting result is mainly determined by the speed of the circulating, frequency-controlled conveyor belt and the position of the separating splitter. The rotary magnetic belt separator or magnetic separator is always used in traversing operation, thus achieving a high extraction of ferromagnetic materials. Subject to the selected magnet material, it is also possible to use this sorting machine to separate weakly magnetic materials such as stainless steels. Typical areas of use include, for example, separating ferrous commingled waste (e.g. fluff) or the finest grains from shredder residue (SHF/SLF) or from pre-shredded plastics. The STEINERT MSB HG technical enhancement comprises very strong ring magnets with a deep field effect for recovering maximum yields of stainless steel. A high magnet density in a compact radial pole arrangement ensures an optimum combination of magnetic flux and magnetic force coupled with a high depth of field.
