PCI motion control card LPE-L122

EthernetRS-485high-speed

LPE-L122 master control card is designed for users who need to quickly and easily develop applications such as motion control and controls of I/O. LPE-L122 is a standard PCI Express master control card with high speed real-time network extension called Motionnet. Motionnet is a new series of communicating system designed for versatile automation applications. Features ● PCI Express x1 compliant ● Low profile form factor ● Max. 20Mbps transfer rate ● 2 Rings of Motionnet® Master ● Max. 128 Motionnet® slave modules supported ● Easy installation with RJ45 phone jack and LED diagnostic ● Hardware IC with unique ID Motionnet® Number of ring: 2 Serial interface: Half duplex RS-485 with transformer isolation Cable type: CAT5 UTP/STP Ethernet cable Surge protection: 10KV Transmission speed: 2.5Mbps, 5Mbps, 10Mbps and 20Mbps Data flow control: Automatic Communication distance: Max. 100M (20Mbps/32 slave modules) Communication slave module number: 2 Rings with Max. 128 slaves (1 Ring with 64 slaves) Unique ID: Hardware IC Form factor: Low profile General Bus type: 1-lane 2.5 Gb/s PCI Express Power consumption: 3.3VDC at 430mA, 12VDC at 55mA typical Working temperature: 0 to 60°C
