Waterproof enclosure WGPC serieswall-mountrectangularplastic
Add to favorites
Compare this product
Characteristics
- Construction
- wall-mount
- Configuration
- rectangular
- Material
- plastic, polycarbonate, PC, ASA, stainless steel
- Application
- outdoor, network
- Protection level
- waterproof, immersion, weatherproof, secure, IP68
- Other characteristics
- high performance, protection
- Width
Min.: 100 mm
(3.9 in)Max.: 300 mm
(11.8 in)- Height
Min.: 55 mm
(2.2 in)Max.: 150 mm
(5.9 in)- Depth
Min.: 150 mm
(5.91 in)Max.: 400 mm
(15.75 in)
Description
IP68 high performance plastic enclosure which withstands immersion in water up to 1m for 24 hours.
The WGPC series is made of PC+ASA material, with enhanced heat resistance and flame retardancy.
Equipped with a silicone waterproof gasket, and supported by multiple enclosing screws from the rear side, it allows the enclosure to maintain a stable high waterproofing capability.
Self-tapping captive screws are able to lock into a pre-drilled hole and provide a secure hold for fastening the cover.
Suitable for communication equipment and network devices to be installed outdoors.
Specifications
See TAKACHI website for accessories and optional parts.
The WGPC series is made of PC+ASA material, with enhanced heat resistance and flame retardancy.
Equipped with a silicone waterproof gasket, and supported by multiple enclosing screws from the rear side, it allows the enclosure to maintain a stable high waterproofing capability.
Self-tapping captive screws are able to lock into a pre-drilled hole and provide a secure hold for fastening the cover.
Suitable for communication equipment and network devices to be installed outdoors.
Specifications
- Material : PC/ASA UL94V-0
- Protection class : IP68
- Operating temperature : -30°C to +75°C
- 16 sizes available.
- Available in Light grey.
See TAKACHI website for accessories and optional parts.
