Distribution electrical enclosure WGVC seriescustomwall-mountedplastic
Add to favorites
Compare this product
Characteristics
- Function
- distribution
- Type
- custom
- Configuration
- wall-mounted
- Material
- plastic, polyamide
- Protection level
- waterproof
- Application
- outdoor, for telecommunications
- Other characteristics
- for harsh environments, with lid
- Width
Max.: 300 mm
(11.8 in)Min.: 100 mm
(3.9 in)- Height
Max.: 150 mm
(5.9 in)Min.: 55 mm
(2.2 in)- Depth
Max.: 400 mm
(15.75 in)Min.: 150 mm
(5.91 in)
Description
The ventilation plug protects the enclosure from deformation caused by thermal expansion. Effective for use under direct sunlight, or in areas with significant change in temperature.
IP68 high performance plastic box which withstands immersion up to 2 meters for 1 hour.
ASA material is resistant to deterioration and discoloration from ultraviolet rays. Perfect for use as outdoor communication or network devices.
Uses self-tapping captive screws which are able to lock into a pre-drilled hole and provide a secure hold for fastening the cover. Please drive the self-tapping captive screws for cutting a thread into the holes at first so that the cover and body can be secured together properly.
Specifications
See TAKACHI website for accessories and optional parts.See TAKACHI website for accessories and optional parts.
IP68 high performance plastic box which withstands immersion up to 2 meters for 1 hour.
ASA material is resistant to deterioration and discoloration from ultraviolet rays. Perfect for use as outdoor communication or network devices.
Uses self-tapping captive screws which are able to lock into a pre-drilled hole and provide a secure hold for fastening the cover. Please drive the self-tapping captive screws for cutting a thread into the holes at first so that the cover and body can be secured together properly.
Specifications
- Material : ASA (UL94HB)
- Protection class : IP68 (withstands immersion up to 2m/1hr)
- Operating temperature : -20°C ~ +60°C
- Vent plug standard flow rate : 1,200mL/min (DP=7KPa)
- 16 sizes available
- Available in Off-white
See TAKACHI website for accessories and optional parts.See TAKACHI website for accessories and optional parts.
