Radio receiver SRC-AO Dim

line driverwith integrated antenna

Unidirectional flush-mounted receiving actuator for dimming up to two 1..10 V or 0..10 V dimming actuators and electronic ballasts (ECGs) through EasySens® wireless switches. The SRC-AO DIM can accommodate up to 32 EasySens® wireless switches. • Application/type : Actuator • Purpose : Lighting control • Interface : EnOcean (868 MHz) • Functions : light ON/OFF/DIM, single, double • Configuration : buttons • Output voltage : 0..10 V, 2x 0..10 V, min. load 5 kΩ • Radio technology : EnOcean (IEC 14543-3-10) 868 MHz, 902 MHz, transmission power <10 mW • Data transmission : unidirectional, internal antenna • Operating range temperature (°C) : -20..+60 • Operating ranges temperature (°C) : -20..+60 • Operating range humidity : max. 85% rH non-condensing • Power supply : 15..24 V = (±10%) SELV, 24 V ~ (±10%) SELV • Power consumption : typ. 1 W (24 V =), 1,5 VA (24 V ~) • Enclosure : ABS • Colour : red • Protection (IP) : IP20, according to EN 60529 • Connection : terminal block, max. 1,5 mm² • Mounting : flush-mounted in standard EU box (Ø=60 mm, depth min. 45 mm) • Packaging length (mm) : 90 • Packaging width (mm) : 90 • Packaging height (mm) : 35 • Packaging : case packaging • Device length (mm) : 60 • Device width (mm) : 48 • Device height (mm) : 35 • Weight (g) : 55 • Notes : up to 32 devices can be learned in
