Diaphragm valve
pneumaticflangeseat

Diaphragm valve - Valvesonly Europe - pneumatic / flange / seat
Diaphragm valve - Valvesonly Europe - pneumatic / flange / seat
Diaphragm valve - Valvesonly Europe - pneumatic / flange / seat - image - 2
Diaphragm valve - Valvesonly Europe - pneumatic / flange / seat - image - 3
Add to favorites
Compare this product

Characteristics

Type
diaphragm
Operation
pneumatic
Body
flange, seat
Applications
flange, washer
Material
EPDM, stainless steel, stainless, bronze, cast, NBR, iron, nylon
Other characteristics
ANSI, standard
DN

Max.: 600 mm
(23.622 in)

Min.: 50 mm
(1.969 in)

Pressure

10 bar, 16 bar, 25 bar, 40 bar
(145 psi, 232.1 psi, 362.6 psi, 580.2 psi)

Description

Surge Anticipator Valve Body: Ductile Iron, Cast Stainless Steel, Bronze Cover: Ductile Iron, Cast Stainless Steel, Bronze Disc Retainer: Ductile Iron, Stainless Steel, Bronze Diaphragm Washer: Ductile Iron, Stainless Steel, Bronze Trim: Stainless Steel, Bronze Disc: Stainless Steel, Bronze Guide: Stainless Steel, Bronze Seat: Stainless Steel, Bronze Seal: NBR, EPDM, HNBR Diaphragm: Nylon Reinforced EPDM Rubber Stem: Stainless Steel Nut: Stainless Steel Spring: Stainless Steel Design Standards: EN1074-5, BS EN1567 Test Standard: ISO5208, EN12266-1 Connection: EN558-1, ISO5752 Flange Drilling: EN1092-2, ISO7005-2, ANSI, JIS, AS2129
