Articulated vacuum cup holder 065580

articulated vacuum cup holder
articulated vacuum cup holder
Add to favorites
Compare this product


Characteristics

Type
articulated

Description

Special stainless steel anti-rotation vacuum cup holders Designed for the robot-automotive sector, these cup holders offer ideal solutions to various handling problems that arise in all industrial sectors. In addition the characteristics of the previously described special vacuum cup holders, their distinctive features are their brass stem with hexagonal cross-section and the steel drive bush, also with hexagonal hole. This structure prevents the stem and, as a result, the cup assembled onto it from rotating on its axis. The drive bush is equipped with two fine thread ring nuts to guarantee an accurate fastening of the cup holder to the automation. Moreover, the two ends of the stem, also in stainless steel, are threaded male or female and interchangeable. The straight quick coupler for the connection to the suction hose is screwed to one end, while the cup with support is assembled onto the other end. They are suited for cups with a diameter between 40 mm and 200 mm, although they are especially useful for the assembly of rectangular or elliptical vacuum cups. The actual springing stroke is: - For height C= 55 mm 37 mm - For height C= 110 mm 84 mm
