Fixed vacuum cup holder Portaventose speciali fix

Product name
Fixed vacuum cup holder with male and female threaded connectors

Description
Fix vacuum cup holders are designed to enable height adjustment of vacuum cups with support using a threaded bush whose thread runs along the entire length. Threaded ends allow mounting of the vacuum cup with support and the connector, providing precise vertical positioning for automated handling systems.

Components

• A threaded bush equipped with two lock nuts for secure mounting on automation equipment
• A quick coupling for connection to the suction hose

Product codes

• 067080
• 067081
• 067082
• 067090
• 067091
• 067092
• 067093
• 067094
• 067095
• 067096

Documents
Drawing / datasheet: 2.157 (PDF available).

Technical characteristics / specifications

• Type: fixed vacuum cup holder with male and female threaded connectors
• Height adjustment via thread along the full length of the threaded bush
• Threaded ends for mounting vacuum cup with support and for connector
• Supplied with two lock nuts for mounting and fixation
• Quick coupling for suction hose connection
• Suitable for automated pick-and-place and handling applications
• Available product codes: 067080, 067081, 067082, 067090, 067091, 067092, 067093, 067094, 067095, 067096
