Gasoline engine rammer SRE 590 DC

tamping

Overview
Weber MT, the specialist for hand-guided compacting equipment, presents the SRE 590 DC — an electric/battery-powered vibratory rammer designed for indoor work, deep trenches and emission-regulated zones. The DC version delivers comparable performance and compaction results to the gasoline model while reducing local emissions.

UNIVERSAL USE
Variable engine speeds for different applications: 3,600 1/min — 3,300 1/min — 3,000 1/min.

MODULAR DESIGN
One battery platform fits all machines of the new Weber MT DC-Line (tool-free battery change).

HONDA LI-ION BATTERY
Battery capacity: 720 Wh — Voltage: 72 V — Rated capacity: 10 Ah. Charging time: 0–80% = 1 h; 0–100% = 1.5 h.

CONVENIENT
Reliable push-button start for easy operation.

CLEARLY ARRANGED
Battery with clear charge indicator and self-diagnostic function. Intuitive and effortless machine handling.

OTHER BENEFITS OFFERED BY THE SRE 590 DC

• Balanced operating characteristics reduce operator fatigue.
• Durable, high-performance tamping system.
• Maintenance-free tamping foot.
• Easy transport with carrying handles and casters.
• 2-year warranty without restrictions.

Available optional extras

• Honda battery
• Charger for battery
• Wheel kit

TECHNICAL DATA
Technical data for SRE 590 DC:
Operating weight (incl. battery): 68 kg
Shoe width: 28 cm (20 cm available for SF variant)
Percussion rate: 670 1/min
Motor: Honda GXE 2.0 / DC electric
Power output: 1.8 kW

Characteristics / technical specifications

• Operating weight (incl. battery): 68 kg
• Shoe width: 28 cm (20 cm optional for SF variant)
• Percussion rate: 670 1/min
• Motor: Honda GXE 2.0; DC electric
• Power output: 1.8 kW
• Battery: Honda Li-Ion, 720 Wh, 72 V, 10 Ah
• Charging time: 0–80% = 1 hour; 0–100% = 1.5 hours
• Variable engine speeds: 3,600 /min, 3,300 /min, 3,000 /min
