Corrugated box making machine YG-D series

automatichigh-rate

Product overview
An automated carton erecting machine designed for end-of-line packaging. Models YG-D800 and YG-D1200 provide high-speed forming and bottom sealing options to integrate inline with box-making equipment and reduce manual folding on packaging lines.

Key features and benefits

• Production speed: YG-D800 = 50–180 pcs/min; YG-D1200 = 80–320 pcs/min; standard forming and sealing from 12–25 pcs/min on typical low-speed variants.
• Labor reduction: automates folding, forming and bottom sealing to lower packaging labor dependency.
• Sealing options: hot-melt and tape sealing available for secure bottom closure.
• Precise control: PLC control with balanced tape tension, wrinkle-free sealing and hand-crank size adjustments enabling 5–8 minute changeovers for trained operators.
• Hygienic forming: vacuum cup pickup option for contamination-free handling in food and pharma applications.
• Material flexibility: adjustable suction circuits and settings to handle different board types and flute structures.

Suitable materials

• 200-600 g/m2 card paper
• PE coated paper
• Kraft paper
• Corrugated paper

Typical industries

• Food & beverage packaging — hygiene-critical lines benefit from vacuum forming and stainless frames.
• E-commerce and warehousing — fast, flexible box forming for variable shipping volumes and frequent size changeovers.
• Pharmaceuticals and personal care — consistent tape sealing and PLC control for packaging integrity.
• Industrial parts and hardware — strong forming and accurate corner pressing for heavy goods protection.

Case study (summary)
A food plant with manual folding bottlenecks installed a continuous carton erecting machine with hot-melt bottom sealing linked to existing box-making equipment. The system ran at 20 boxes/min, reduced packaging staff from eight to two, increased capacity ~40% and achieved payback in six months.

Common issues and practical tips

• Failure to pick up boxes: check suction cups for wear and maintain stable air supply (~0.6 MPa); clean cups regularly.
• Loose bottom tape sealing: inspect cutter spring tension and roller pressure; keep bottom flap gaps under 2 mm before tape application.
• High humidity or cold-chain operation: choose full stainless-steel frame and moisture-proof cylinders.

Carton Erecting Machine parameters
Type: YG-D800 / YG-D1200
Production capacity: 50-180 pcs/min (YG-D800) / 80-320 pcs/min (YG-D1200)
Suitable material: 200-600 g/m2 card paper, PE coated paper, kraft paper, corrugated paper
Length: L100-450 mm, flap angle: 5°-40°
Width: W100-600 mm (varies by model)
Height: H15-200 mm
Total power: 5 kW (YG-D800) / 6.25 kW (YG-D1200)
Total weight: ~1.8 T (YG-D800) / ~2.8 T (YG-D1200)
Overall dimension: 3600 x 1400 x 1700 mm (YG-D800) / 3600 x 1850 x 1700 mm (YG-D1200)
Power source: 380V / 220V 50Hz (model dependent)
After-sales: spare parts, video technical support, on-site installation/commissioning/training, maintenance and repair, online support

Technical specifications

• Models: YG-D800, YG-D1200 (YG-D series)
• Production ranges: 50–180 pcs/min (YG-D800); 80–320 pcs/min (YG-D1200)
• Board grammage: 200–600 g/m2
• Board types: PE coated, kraft, corrugated
• Box length: 100–450 mm (adjustable); flap angle: 5°–40°
• Box width: up to 600 mm (model dependent)
• Box height: 15–200 mm
• Electrical power: 5 kW (YG-D800); 6.25 kW (YG-D1200)
• Machine weight: ~1.8 t (YG-D800); ~2.8 t (YG-D1200)
• Dimensions: 3600 x 1400 x 1700 mm (YG-D800); 3600 x 1850 x 1700 mm (YG-D1200)
• Power supply: 380V / 220V 50 Hz (depending on model)
• Controls & changeover: PLC control; manual hand-crank adjustments with scale rulers for 5–8 minute changeovers by trained operators
• Suction system: vacuum cup pickup with adjustable circuits for different flute types
• Sealing options: tape sealing and hot-melt bottom sealing
• After-sales service: spare parts, video support, field installation/commissioning/training, maintenance and repair, online support
