In-line flexographic press YG series

central drumstack4-color

Overview
The YG series flexo printing press range is designed for packaging and label production across paper and film substrates. These models balance high throughput and substrate versatility, making them suitable for narrow-web labels, flexible packaging and corrugated pre-printing. Key decision criteria include machine type, registration accuracy, substrate compatibility and real production speed.

Selection guidance
Choose flexo for stable, high-volume production where plate costs are amortized over long runs. For short runs or variable data work, consider digital alternatives. Evaluate required registration tolerance, substrate (paper 30–300 gsm vs films), and finishing modules (lamination, die-cutting, cold foiling) when selecting between stack, unit-type or CI configurations.

Common machine types and differences

• Stack flexo: Vertical stacking of print units saves floor space and initial investment. Suitable for limited-space plants and start-ups. Multiple web turns reduce registration precision (~±0.3 mm). Typical speeds: 50–150 m/min.
• Unit-type (inline) flexo: Horizontal modular units allowing easy integration of lamination, rotary die-cutting and cold foiling. Common for narrow-web labels and adhesive tapes (web widths under 600 mm).
• Central impression (CI) flexo: Printing units arranged around a single impression cylinder to support the substrate and minimize stretch. Delivers high registration accuracy (practical up to ±0.05 mm) and high speeds (200–600 m/min), ideal for flexible packaging and plastic films.

Parameters (YG-320, YG-420, YG-550, YG-650)

• Models: YG-320 / YG-420 / YG-550 / YG-650
• Max. web width: 320 mm / 420 mm / 550 mm / 650 mm
• Max. printing width: 310 mm / 410 mm / 520 mm / 650 mm
• Printing speed: 10–60 m/min (typical narrow-web)
• Printing colors: 1–8 colors option
• Unwinding/rewinding diameter: up to 600 mm
• Printing length (repeat): 177.8–355.6 mm
• Precision: ±0.15 mm
• Power: 3P 380V ±10%, 50 Hz

Parameters (YG-850)

• Model: YG-850
• Maximum web width: 860 mm
• Maximum printing width: 850 mm
• Plate repeat length: 181–450 mm
• Maximum unwinding/rewinding diameter: 1000 mm
• Registration accuracy: ±0.12 mm
• Gear spec: 1/8cp
• Maximum machine speed: 100 m/min
• Plate thickness: 1.7 mm / 0.38 mm (entries)
• Suitable material: paper 30–300 gsm (listed), films depending on configuration
• Operation console: front of printing unit (Chinese/English)
• Air: 100 PSI (0.6 MPa), clean dry oil-free
• Tension control: 10–100 KG range, accuracy ±0.5 kg
• Drying: IR standard, UV optional; oven max temp 80℃
• Power: 380V ±10% 3PH 50Hz

Real-world applications

• Food & Beverage packaging: labels, pouch bags, paper cups — often water-based inks for food safety.
• Logistics and corrugated pre-print: high-speed printing for shipping boxes and kraft sacks.
• Self-adhesive labels: inline presses combined with rotary die-cutters for print-and-die in one pass.
• Non-woven & paper products: shopping bags, napkins, paper cups (30–300 gsm).

Technical specifications

• Series: YG (models YG-320/420/550/650/850)
• Web/printing widths: 320–860 mm (model dependent)
• Colors: up to 8
• Speed: narrow-web 10–60 m/min; CI presses up to 200–600 m/min; YG-850 up to 100 m/min
• Registration: typical ±0.12–0.15 mm (CI machines can reach ±0.05 mm)
• Unwind/rewind capacity: 600 mm (smaller models) / 1000 mm (YG-850)
• Electrical: 3-phase 380V ±10%, 50 Hz
• Tension control and automation options available to improve registration and reduce scrap
• Drying: IR standard; UV optional
