Advantech provides two different types of controllers with respective I/O modules for versatile applications, PC-based Controllers and Programmable Automation Controllers (PAC). The PC-based controllers are open development environment interface; the PACs are a single platform with multi-disciplined controller functionalities.
|
|
SCM5B MODULES
Dataforth Corporation offers cost-effective, isolated industrial signal conditioning modules. The SCM5B analog modules are form, fit, and functional equivalents to similar products from other manufacturers. The product line includes a complete selection of backpanel options, interface cables, racks, fuses, jumpers, power supplies, and other accessory items.
|
|
Really independent I/O modules with embedded microprocessor
Sigmadue is a system of standalone remote I/O modules designed by Ascon for fieldbus applications, in other words, fully distributed automation. No back planes nor common modules are necessary, also, wiring can be directly connected to the modules thus eliminating termination units. I/O modules have a lot of built-in intelligence. Embedded microprocessors allow them to scale data, linearise them, do signal conditioning, perform diagnostics and take care of alarms. These I/O modules can unburden the PLC memory. Valuable PLC memory can be dedicated only to the digital processing, thereby improving the PLC’s scan times. PLC processor can be downsized. The modules use CANbus or Modbus as bus, and are easily networked together. There are numerous CANbased or Modbus intelligent devices that can be networked together with the modules and brought into the system: PCs, PLCs, motor drives, valves, transmitters for pressures, temperatures. CANbus has the advantage in that the modules can be separated at great lengths from one another; so the I/O system can span large distances. Network adaptors will connect an entire Sigmadue system into Profibus or Ethernet. Ascon can also offer SigmaPAC, the programmable automation controller designed to be the host controller for the Sigmadue system of I/O and suitable to obtain completely open and configurable distributed automation systems.
|
|
AIO160802AY-USB is an analog I/O terminal for USB 2.0 that can be connected to the USB bus.
This product has analog input (16bit, 8ch), analog output (16bit, 2ch), digital input (LVTTL x 4), digital output (LVTTL x 4).
AIO-160802AY-USB includes "C-LOGGER", a data logging software of Windows version. "C-LOGGER" is an easy-to-use yet very flexible tool specifically designed for user's data logging applications.
Users can also use the included driver library "API-USBP(WDM)" to configure the application software for Windows using the programming languages that support Win32AP functions.
|
|
The V470 is 6UVME module that provides sixteen independent, isolated analog outputs that may be user-programmed to operate as voltage outputs or thermocouple simulators. Users may write temperature or voltage values at VMEbus speed, and the uP will transparently do all necessary calculations and update the channel electronics.
In thermocouple simulation mode, theV470's lookup tables for all common thermocouple types allow users to write desired temperature directly to VME registers. Any channel can be associated with any of the reference junction sensors located in the external field-wiring termination panels, or can use the on-board sensor. Cold-junction compensation is via table lookup of thermocouple potential for the type currently selected. Reference junction temperatures are readable.
Two front-panel D-25 connectors interface to external analog devices. Each connector provides eight differential outputs and connections for two 4-wire RTDs. A D9 connector provides in-crate calibration check. Each isolated channel incorporates a software controlled DPDT relay that allows the channel output to be diverted to the test connector.
Up to four output channels may be series-connected to provide outputs up to ±50 volts.
An optional built-in-self-test (BIST) subsystem adds additional switching and an on- board ADC and firmware that allows the invocation of a full closed-loop test of all ranges of all 16 channels.
The V450 analog input module is also available.
|
|
The V450 is a VME 16-channel isolated analog-to-digital converter module which can acquire a wide range of DC voltages, including thermocouple temperatures. Each channel is independent with an isolated DC power supply, optoisolated interface, A/D converter, signal conditioning, input protection circuits, and test relay.
An internal microprocessor manages all data I/O and communicates with the VME bus via a transparent, VMEbus-speed dual-port memory.
Each channel may be user programmed to operate in voltage-input or thermocouple acquisition mode. In each mode, channel operating parameters, acquired measurements, and status flags are accessible in dedicated VME registers. Data rate/filtering options are provided. Data acquisition is managed autonomously by the processor, so VME masters may set channel parameters or read acquired measurements at any time at full VMEbus speed. Any channel can be associated with any of the reference junction sensors located in the external field-wiring termination panels, or can use the on-board sensor. Cold-junction compensation is via table lookup of thermocouple potential for the type currently selected. Reference junction temperatures are readable.
The V470 Analog Output Module is also available.
|
|
Introduction
Better I/O Matrix for Monitoring
Moxa's ioLogik E2242 is tailormade for use with remote monitoring and alarm systems. This Active Ethernet I/O product provides 4 analog inputs and 12 configurable DIOs for a 1:3 ratio of analog IOs to digital IOs perfectly adapted to water tank monitoring and environmental monitoring applications, in which 1 analog input is used to trigger 3 digital outputs as High-High, High, and Low alarms. Moxa’s ioLogik E2242 lets you set up your monitoring system without the need for a local PC or RTU.
Features
• 4 fixed differential analog input channels
• 12 configurable digital input/output channels
• DI counter saved automatically when power shuts off
• Instant event messaging by TCP/UDP/email/SNMP-Trap
• PC-based configuration utility and web console
• Easy-to-use Click&Go™ Logic for local output control
• Windows/WinCE VB/VC.NET and Linux C APIs
• I/O control over Modbus/TCP and SNMP protocol
•NIST traceable calibration
|
|
Analog input modules AI20x/SI
* Number of inputs: 2 / 4
* Input current: 0 .. 20 mA
* Differential inputs
* Resolution: 16 bits
* Inputs synchronizable
* Galvanic isolation from system: 500 V
* Galvanic isolation of channels: 500 V
Analog Input modules AI204/x
* Number of inputs: 1 / 2 / 4
* Input voltage: ±10 VDC
* Differential inputs
* Resolution: 16 bits
* Inputs synchronizable
* Galvanic isolation from system: 500 V
* Galvanic isolation of groups: 500 V
Analog Output module AO202
* Number of outputs: 2
* Output voltages: ±10 VDC
* Differential and short circuit proof outputs
* Resolution: 16 bits
* Outputs synchronizable
* Galvanic isolation from system: 500 V
* Galvanic isolation of channels: 500 V
Analog Output module AO208/I
* Number of outputs: 8
* Output current: 0 .. 20 mA or 4 .. 20 mA
* Resolution: 13 bits
* Galvanic isolation of channels: 500 V
* Galvanic isolation of groups: 500 V
Analog In/Output modules AIO288/x
* Number of inputs: 8 (±10 VDC / ±1 VDC or 0 .. 20 mA)
* Number of outputs: 8 (±10 VDC)
* Resolution: 14 bits
* Connection: single-ended or differential
* Number of Pt100 sensors: 4
* Connection: 2- or 4-wire technology
* Optional galvanic isolation: 500 V
|
|
Diamond-MM-32DX-AT:
Analog I/O PC/104 Module with Advanced Automatic Autocalibration
DMM-32DX-AT is Diamond Systems' most advanced embedded A/D board. It includes a comprehensive suite of analog and digital features to fit a wide variety of embedded application needs:
- The 32 A/D input channels feature high-accuracy 16-bit resolution, 250KHz maximum sampling rate, programmable input ranges, and user-selectable single-ended / differential configuration.
- The 4 D/A output channels feature user-selectable output ranges as well as a programmable waveform generator feature, 16-bit standard, 12-bit optional.
- The 24 digital I/O feature bit by bit direction programmability as well as buffers for enhanced output current of -15mA (logic 1) / 64mA (logic 0).
- The on-board programmable counter/timer circuitry includes a 32-bit counter/timer for A/D and D/A sample timing, as well as a 16-bit counter/timer for general counting, timing, and programmable interrupt functions.
- Extended temperature operation of -40 to +85oC is tested and guaranteed. Using our patented auto-autocalibration technology, DMM-32DX-AT will provide accurate analog measurements across its entire rated operating temperature range, ensuring reliable performance for critical applications.
- Our advanced Universal Driver software is included free with DMM-32DX-AT and all our CPU and I/O boards. Universal Driver provides a programming library that simplifies control of all the board's features and enables you to develop your application software quickly.
- Board uses only ceramic capacitators for durability in high altitudes and other harsh environments.
|
|
