The AD7011-EVA is a real time industrial PC equipped with multiple I/Os that can interface with a variety of external devices. It can be used in a wide range of applications as a controller, simulator, real time data logger, or real time data analyzer.
The AD7011-EVA has the following main features.
1) Real time capability and compatibility with RT-Linux (Xenomai).
2) Support for various types of I/O (AD/DA, Ethernet, GPIO, USB, etc.) for
interfacing with a wide range of external devices and systems.
3) An excellent standalone interface via an LCD touch screen and function
keys.
4) A flexible GUI building tool (AD-VirtualConsole) to create user specific
GUIs.
5) The ability to execute MATLAB/Simulink models at the system, which
enables Simulink model execution on real hardware.
6) A C-code programming environment using Eclipse, free software for C
code developers.
The AD7011-EVA is equipped with packaged hardware and the required software, including S-function device drivers for all I/O, a GUI builder (AD-VirtualConsole), and a software development tool (Eclipse), and a demo license for MATLAB/Simulink can be downloaded from The Math Works website. Users can start creating applications almost immediately.
The main board of the AD7011-EVA is equipped with a Freescale i.MX31 CPU with an ARM11 core, 128 MB of DDR SDRAM, 16 MB of NOR Flash for the OS and a 512 MB microSD card for applications.
The AD7011-EVA is excellent support tool for development.
|
|
|
Advantech offers complete fanless Box PCs with rugged, cableless designs for harsh industrial environments. With compact and rich IO, multiple expansion solutions and multiple mounting methods, these platforms are suitable for a wide variety of applications in a wide range of environments. The UNO-1000 series are DIN-rail, fanless BOX PCs, the UNO-1100 series are DIN-rail, high performance fanless BOX PCs, the UNO-2000 series are compact, embedded fanless BOX PCs with PC/104 extensions, the UNO-2100 series are high performance fanless BOX PCs with PC/104 extensions, the UNO-3000 series are front access, high performance fanless BOX PCs with PCI extensions , and the UNO-4000 series are Rackmountable, fanless BOX PCs with PCI extensions.
|
|
The EM-F343 is based on the Intel Celeron M Processor and the Mobile Intel 910GMLE Express chipset. Its robust fanless design makes the EM-F343 an ideal platform for video applications such as digital signs, outdoor advertising, POS systems, information kiosks and embedded gaming computers. It comes equipped with a wide variety of standard computer outputs including S-Video and VGA out video interfaces, Com port, LAN and six USB 2.0 ports for administration and software input, and SATA II and CompactFlash support for storage. The onboard 600/1000MHz Intel Celeron M processor couples low power consumption with minimal cooling requirements, resulting in improved stability and longevity and allowing for completely fanless computer design.
http://www.lannerinc.com/EM-F343
|
|
Worlds First Industrial 9-port Intelligent PoE Routing computer
* Intel IXP430/435 667MHz networking processor
* Complete Layer3 routing support: OSPF, RIP, DVMRP, IPv6
* 8-port PoE delivers full 15.4W per port, 123w per unit
* Full management features with QoS, VLAN, PoE scheduling
* Separated two DC 12~48V power inputs (48V for PoE)
* Versatile interfaces of USB, DIO, SDIO control, and optional modules for RFID, WLAN, and WiMax
* Embedded Linux UIModulized Webmin, capable of running
customized control programs
* Cross-platform applications by JavaVM
* Fan-less and Ruggedized Industrial Design for anti-vibration,
anti-shock, and -25~70oC operation temperature
(-40~80oC for Wide temperature)
|
|
|
|
|
|
Product Description
CPU
Atom N270 1.6GHz 533MHz L2 512K
Chipset
North Bridge Intel 945GSE Express Chipset
South Bridge Intel ICH7
Memory
1x SO-DIMM memory slots (supports up to 2GB memory)
HDD
2.5 size SATA (Up to 1TB )
Optical Device
Slim CDROM / DVDROM / Combo (DVD+CDRW) / DVDRW (Optional)
Expansion Slots
1x mini PCI-E slots (internal slot)
Audio
Realtek ALC655 6-channel AC'97 Rev2.3 CODEC
LAN
supporting 10/100/1000 BASE-T Ethernet
USB Port
Max. 8x USB 2.0 ports
VGA Port
Intel 945G built in experience superior graphics with Intel GMA950
Multi-Media Card Reader
CF
Back Panel I/O Ports
1 x Power Connector (12V DC Jack Out);
1 x Power Connector (4 Pin DC Jack In);
1 x PS/2 Keyboard ;
1 x PS/2 Mouse ;
2 x Audio (Line Out / MIC) ;
1 x RJ45 ;
2 x RJ11 (One Cash draw, One PCI 512K Modem Optional);
2 x USB 2.0 ;
4 x Serial (3 x External, 1 x Internal);
1 x LPT ;
1 x VGA ;
Side Panel I/O Ports
2 x USB ;
Wireless LAN
32bit Mini PCI-E card Interface. (optional), support 64 and 128 bit WEP Encryption
802.11g : 54Mbps Up to 50m (Outdoor), 20m (Indoor)
Touch Screen
Internal RS-232 for Touch Screen Control Board (optional)
12.1", 15" 5 wires resistive touch screen or SAW Touch Panel, or Capacitive Touch Panel
Fan Speed Control
The CPU fan speed can set by temperature of CPU.
Watch Dog
Can be set by 500ms, 1, 2, 4 seconds period. RESET or NMI was generated When CPU did not periodically trigger the timer
Power Lost Recovery
System will auto power on when power failure
Power Adapter
Input : AC / 100~240V (50/60Hz) 2.5A
Output : DC /12V, 7A
|
|
Display:
LCD Panel: 12h TFT LCD Panel+ VFD Customer Display (Optional)
Second Display: 12" TFT Monitor With or Without Touchscreen (Optional)
Touch screen: 5 Wires Resistive Touchscreen
PC Config
Chipsets: Intel 945GC+ICH7
CPUF Intel Atom(TM) 230 1.6G
GraphicF Integrate GMA950 GRAPHICSCsupport DX 9.0
AudioF Integrate ALC655 codec, support2/4/5.1 channel audio-out
RAMF 1G DDRII, support DDRII 533/667,
HDD: 80G / 160G
Lan card: Internal RTL8100C, Support non-HDD system
Power supplyF Input AC 100-240V, Output DC 12V 7.5A
Support OS: Window XP, Linux FC 7
I/O Ports: 4 x USB 2.0, 4 x RJ-45, 4 x Serial 1x LPT, 1x PS/2 keyboard, PS/2 keyboard Mouse 1x 1Xvga out, 2 x Audio (Line Out / MIC), 1 x Parallel, 1x PCI slot
Dimension: 230mm (L) ~360mm (W) x 460mm (H)
Operation TemperatureF0C ~ 50C (CPU with heat sink)
Storage TemperatureF-20C ~ 60C
Optional PeripheralsF
MSRC POS PrinterC Barcode Scanner
|
|
Display:
LCD Panel: 15h TFT LCD Panel+ VFD Customer Display (optional)
Second Display: 12" TFT Monitor With or Without Touchscreen (optional)
Touch screen: 5 Wires Resistive Touchscreen
PC Config
Chipsets: Intel 945GC+ICH7
CPUF Intel Atom (TM) 230 1.6G
GraphicF Integrate GMA950 GRAPHICSCsupport DX 9.0
AudioF Integrate ALC655 codec, support 2/4/5.1 channel audio-out
RAMF 1G DDRII, support DDRII 533/667,
HDD: 80G / 160G
Lan card: Internal RTL8100C, Support non-HDD system
Power supplyF Input AC 100-240V, Output DC 12V 7.5A
Support OS: Window XP, Linux FC 7
I/O Ports: 4 x USB 2.0, 4 x RJ-45, 4 x Serial 1x LPT, 1x PS/2 keyboard, 1x PS/2 keyboard Mouse 1 x VGA out, 2 x Audio (Line Out / MIC),
1 x Parallel, 1x PCI slot
Dimension: 230mm (L) ~360mm (W) x 460mm (H)
Operation TemperatureF0C ~ 50C (CPU with heat sink)
Storage TemperatureF-20C ~ 60C
Optional PeripheralsF
MSRC POS PrinterC Barcode Scanner
|
|
VitaPOS
* Available in 15High brightness LCD
* Available with Resistive and SAW touch screen
* Metal bezel, also offered in stainless steel finish
* Available with Celeron M 1.5GHz or Core 2 Duo 1.66GHz
* Meets 3 1/2 Standard for wall mounting
* Optional Magnetic Strip Reader and/or Biometrics Reader
The VitaPOS comes in 15" with high brightness LCD. Available with Resistive and SAW touch screen. Its construction is in Metal bezel but also offered in stainless steel finish. Available with Celeron M 1.5GHz or Core 2 Duo 1.66GHz. You have the option to attach a credit card reader and/or a customer display.
|
|
Display:
LCD Panel: 12h TFT LCD Panel+ VFD Customer Display (optional)
Touch screen: 5 Wires Resistive Touchscreen
PC Config
Chipsets: Intel 945GC+ICH7
CPUF Intel Celeron M 900MHz
GraphicF Integrate 852GM+ICH4
AudioF Integrate ALC655 codec, support 2/4/5.1 channel audio-out
RAMF 512MB, support DDRII 533/667,
HDD: 80G
Lan card: Internal RTL8100C, Support non-HDD system
Power supplyF Input AC 100-240V, Output DC 12V 7.5A
Support OS: Window XP, Linux FC 7
I/O Ports: 4 x USB 2.0, 4 x RJ-45, 4 x Serial 1x LPT, 1x PS/2 keyboard, 1 x PS/2 keyboard Mouse 1 x VGA out, 2 x Audio (Line Out / MIC),
1 x Parallel, 1x PCI slot
Dimension: 230mm (L) ~360mm (W) x 460mm (H)
Operation TemperatureF0C ~ 50C (CPU with heat sink)
Storage TemperatureF-20C ~ 60C
Optional PeripheralsF
MSRC POS PrinterC Barcode Scanner
|
|
PO15AX
- Robust aluminum die-casting housing construction.
- Fanless system that specially targets for the hospitality business that operate under harsh environments and require excellence compatibility.
- Front cover meets spill-proof IP54.
- Intel Atom N270 low power consumption processor delivers outstanding performance for hospitality and retail business.
- Special clam shape rear cover allow system board to remove easily convenient for maintenance.
|
|
VariPOS
* Ultra Compact, Light-Weight Design
* Flexible Mounting Options
* Rugged Construction
* Superior Serviceability
VariPOS is equipped with energy efficient Celeron M 1.5GHz or performance level Core 2 Duo 1.66GHz CPU. The VariPOS provides an all-in-one technology platform that can fit virtually anywhere in any environment. Weighing only 11 pounds and measuring only three inches in depth, the VariPOS provides the ultimate in flexibility and makes it particularly space saving. To ensure the highest quality, reliability and safety, the VariPOS undergoes comprehensive environmental and compatibility testing. Spills and retail abuse are no problem with the NEMA 4/IP 65 dust and water proof display. The system can be easily matched to specific needs with a range of peripherals (VFD customer display, card reader, fingerprint, fingerprint).
|
|
Notebooks and Laptops
Rugged Notebooks are portable PCs designed for use in demanding environment. Their rugged design ensures reliable operation under all outdoor conditions. With our products we cover the complete range from tablet PC's over convertibles up to a highly modular notebook system.
|
|
|
|
|
|
noax Steel Series Industrial PCs - Rugged and Waterproof NEMA4X - for highest hygiene standards
noax Steel Series industrial touch panel PCs are characterized by their polished V2A (1.4301) stainless steel enclosures with absolutely smooth surfaces. The use of special, food safe seals between enclosure and touch display of the units means that there are no chinks and joints any more. The noax Steel IPCs therefore meet the most rigorous hygiene standards such as those prevalent in clinical areas, chemical and pharmazeutical laboratories or in food processing. The fully enclosed design without any ventilation slots and external fans makes the IPCs completely splash-proof and so achieves the IP65 / NEMA4 protection category. The Steel Series industrial PCs are equipped with high-contrast, extremely durable industrial TFT displays that guarantee good readability, even under very poor conditions. They are available in screen sizes of 12, 15 and 19 inch. The integrated resistive touch panels ensure simple operation even with gloves worn.
|
|
Designed for simple measuring applications up to 16 sensors/measurements and basic statistic analysis, Merlin represents a new concept of gage computer using the same technologies created for PDA and portable electronics, for data collection from traditional or wireless measuring devices.
Embedded technology allows: small dimensions (the whole system footprint is smaller than an A4 sheet of paper), fanless architecture and no moving parts (flash disk storage media), assuring the highest level of system reliability.
Merlin gage software based on Microsoft Windows CE 5.0 guarantees a friendly and easy to use operator interface. Its touch-screen designed human interface allows to program and acquire measures without any additional input/command device.
|
|
|
Nematron is offering a complete range of Embedded Systems and Panels designed specifically for challenging applications. The Embedded ES and Embedded Formula panels are an excellent choice for this. The ES range starts with a very tiny footprint using a 133MHz CPU (ES8020FL) and ends with the high range full blown 2.0 GHz Core 2 Duo CPUs like the ES5630FL. Almost all combinations of CPU power, Chipsets, RS-232/422/485 ports, many USB ports, Ethernet ports, LVDS, DVI, and other common I/O ports can be found on the many units the whole range offers. Several storage capabilities are available to implement. The wide range of Embedded Formula Panels is starting with Xscale CPU Power and goes up to the same high CPU level as the ES series. Screen sizes starting at 8 towards the big 19 displays are available with many different I/O ports and PCI slots if needed. To help you to choose the best possible fit for your application contact Nematron for assistance. www.nematron.net
|
|
|
SMART embedded computer using a unique fanless design, greatly reducing power consumption and fan noise generated, compact appearance of the structure of similar products to overcome the size limitations, can be adapted to different installation requirements, and able to withstand vibration operating environment, such as poor. SMART support high performance Intel Core2 Duo processor, ultra-low power, high performance and low power consumption of both. At the same time, support VGA / DVI display mode, to maximize the flexibility provided.
|
|
Protech introduces modular IPC with powerful CPU, easy maintenance and versatile mounting
Accelerating the integration and deployment of high-performance embedded PCs for a wide range of industrial applications, Protech Systems Co., Ltd., the leading provider of industrial computers, recently launched the EPC-5500 and EPC-5510 modular IPCs featuring support for socket 478 Intel Pentium M/Celeron M Ultra Low Voltage processors with 400 MHz Front Side Bus and up to 2 GB of system memory using DDR333 MHz DIMMs. The EPC-5500/5510 comes with the Intel 855GME/852GM chipset and offers a comprehensive array of I/O interfaces including four serial communication ports supporting RS232/422/485, four high-speed USB 2.0 ports, a 10/100 BASE-T Ethernet port and Gigabit LAN.
Designed for superior peripheral connectivity and data communications, the EPC-5500/5510 is equipped with a 200W AC power supply to provide a versatile and dependable platform for interactive kiosks and manufacturing automation.
|
|
|
|
|
|
Introduction
Moxa UC-8400 series embedded computers use the Intel XScale IXP435 533 MHz RISC CPU. All models are equipped with 8 RS-232/422/485 serial ports, 3 Ethernet ports, 4+4 DI/DO channels, a CompactFlash socket, 2 USB 2.0 hosts, and a PCI-104 bus for flexible expansion. The UC-8416 is equipped with 8 10/100 Mbps Ethernet switch ports and the UC-8418 features 2 CANbus ports. The built-in 16 MB NOR Flash, 32 MB NAND Flash ROM, and 256 MB DDR2 SDRAM provide enough memory to run application software directly on the UC-8400 series for data storage. Moreover, the 256 KB of backup SRAM offers improved data retention for avoiding data loss. All UC-8400 series embedded computers have passed FCC Class B certification.
Features
Customized expansion for greater versatility
Built-in PCI-104 bus for flexible expansion
Multiple connection options
3 10/100 Mbps Ethernet ports for network redundancy
8 RS-232/422/485 serial ports (50 bps to 921.6 Kbps wide baud rate)
4 to 12 DI and DO channels
2 CANbus ports
8 Ethernet switch ports
Intel XScale IXP435, 533 MHz processor
Built-in 256 MB DDR2 SDRAM faster memory read/write
16 MB NOR Flash onboard to store OS, 32 MB NAND Flash onboard for data storage
2 USB 2.0 hosts for mass storage devices
CompactFlash socket for storage expansion
Fanless, cableless, no hard disk, and low power consumption design
Suitable for various applications
256 KB battery backup SRAM
-40 to 75C wide temperature model available
FCC Class B certification
Various storage expansion options, including CompactFlash socket
DIN-rail or wall mounting installation
Linux platform pre-installed
|
|
|
|
|
|
Introduction
The DA-681 computer is based on the Intel x86 processor and supports VGA, 6 Ethernet ports, 4 RS-232 and 8 RS-485 serial ports with optical isolation, CompactFlash, and USB.
The DA-681 is suitable for industrial automation applications that require standard 19-inch rackmount solutions, such as power automation, transportation, and oil and gas. Another plus is that the serial ports come with 2 KV optical isolation protection to guarantee communication reliability in harsh industrial environments.
In addition, the DPP-T models have been certified to meet the IEC 61850-3 standard, making them ideal for power substation automation systems.
The DA-681 runs Linux, WinCE 6.0, or Windows XP Embedded (pre-installed), providing a friendly environment for developing sophisticated application software. The great software support that Moxa provides makes the programmers job easier, and helps programmers develop bug-free code quickly and at a lower cost.
Features
IEC 61850-3 certified for power substation automation systems (DPP-T models only)
Intel Celeron M 1 GHz processor with 400 MHz FSB
1 x 200-pin DDR2 SODIMM socket, supporting DDR2 400 up to 1 GB (512 MB built-in)
Six 10/100 Mbps Ethernet ports
1 CompactFlash socket, 1 IDE and serial ATA-150 connectors for storage expansion
USB 2.0 ports for high speed peripherals
4 isolated RS-232 and 8 isolated RS-485 ports
Serial port speed from 50 to 921.6 Kbps, supporting nonstandard baudrates
Embedded Linux, WinCE 6.0, or WinXPe platform
19-inch rackmount model, 1U height
Dual 100/240 VAC/VDC power input (Single power and dual power models available)
Fanless design
|
|
The Command Station (CS) is a stand-alone operator station, which is totally protected against dust and water spray incursion, in an attractive designer housing. The flat enclosure is machined from a solid aluminium block and is fitted with a stainless steel mounting frame at the rear edge, which is intended for support arm mounting or for direct fixing to a wall.
To allow the flexible implementation of individual operator concepts, the system offers numerous options and add on operator consoles, including touch screens, functional and alphanumeric keyboards, operator consoles with switch elements and an emergency stop button or MF2 keyboards in a variety of different versions.
|
|
|
|
|
|
EZPOS 715 is integrated with Intel high performance and low power consumption technology. The fanless feature saves the risk of changing CPU cooler and makes the daily operation working smoothly. The EZPOS 715 is an ideal solution for 24hours, 7 days unremitting workload POS application. The case of EZPOS 715 is made by robust aluminum die-casting which protects the inside system and provides the effective thermal control. With the EZPOS 715 high performance and low power consumption features providing the ideal solution for the customer who wants to provide the fast and friendly service.
-Integrated with Intel low power consumption and high performance technology
-Fanless design solution for stable and reliable POS application
-Easy upgrade and maintenance by modularized design
-Robust aluminum die-casting design
-Supports Wireless LAN,Gigabit Ethernet and battery backup function
-Supports 1 x RS-232/422/485 and 4 x RS-232,power setting by BIOS.
-Optional: customer display, MSR and iButton
|
|
|
|
|
|
Protech launches cost-effective POS system with
high-performance CPU, flexible storage, and ultra-silent operation
Integrated solutions boosts productivity and lowers TCO
Enhancing business productivity through reliable and cost-effective technology, Protech Systems Co., Ltd., the leading provider of industrial computers, recently released the PS8831 a turnkey point-of-sales system with the latest Intel Celeron M Ultra-Low Voltage processor with 1 GHz core speed, an integrated 12.1 low-power TFT LCD, and comprehensive built-in I/O capabilities. A low-cost POS solution for interactive kiosks and multimedia terminals, the PS8831 implements a highly manageable design that includes a swappable 2.5 hard disk drive, easy-access memory and CF card slots, and an exchangeable magnetic stripe reader (MSR). The PS8831 can efficiently handle customer information and payment options through the MSR and a smart card reader for IC-equipped debit or credit cards. Operating at less than 35 dB, the energy-efficient POS is suitable for hotels, airports, restaurants, and other noise-sensitive business establishments.
|
|
|
|
|
|
X-POS 752:
EBN's X-POS 752 , the all-in-one touch screen terminal is specifically designed for POS environments that demand high performance, efficiency and value. The X-POS 752 is powered by the fanless Intel ATOM 1.6GHz CPU which delivers high performance and low heat generation. Pairing the IntelR ATOM? with EBNs innovative and fanless chassis design, this POS terminal is able to operate at maximum efficiency. EBNs clients want their businesses to run like our X-POS family of POS terminalsKcool, calm, and collected!
EBN's X-POS 752 system is integrated with an ultra-clear 15'' TFT LCD touch sensitive monitor for maximum productivity and super ease of use. The full complement of POS peripheral devices may be quickly added by way of EBN's recessed for example MSR, barcode scanner, finger printerKetc. The built in I/O set includes 3 x RS-232 ports, Parallel port, 4 x USB 2.0 ports, 1x Gigabit High Speed Ethernet interface (RJ45), Cash Drawer jack (RJ-11) and wireless 802.11 b/g support for wireless operation environment.
|
|
High Performance 15" POS Terminal Offers Speed and Flexibility
Taipei, Taiwan, February 27, 2007 - Protech Systems Co., Ltd, the leading industrial PC maker, is releasing a new PS6506 high performance POS terminal. With an Intel 855GME chipset supporting Intel Pentium M or Celeron M processors, the PS6506 features quiet operation, a waterproof 15" TFT LCD display with ELO 5-wire resistive touchscreen and numerous standard and optional enhancements including wireless networking, a CompactFlash memory slot and magnetic swipe card reader (MSR). With a small footprint and strong I/O support for a range of peripherals, the PS6506 is a WEPOS/Windows 2000/XP/XPE/Linux OS compatible POS with the performance and flexible design to support a wide range of applications.
|
|
|
|
|
|
Eurotech offer a wide range of rugged industrial computers in a variety of formats, all designed to withstand harsh environments.
DuraCOR 1130-00
The DuraCOR 1130-00 performs advanced capture & compression functionalities including up to 8 JPEG2000 Video Encoder Channels (NTSC, PAL or SECAM). Designed to withstand harsh environmental conditions, it is EN50155 class T1 and 2004/104/EC compliant. It can achieve extended temperature ranges (-25C/+55C) - no cooling fan is necessary - and can resist shock, vibration & high humidity
http://www.eurotech-ltd.co.uk/en/products.aspx?pg=DuraCOR%201130-00&pp=Access%20Control%20/%20Security&pc=302&pid=10029
APOLLO ICE 1U
The APOLLO ICE 1U (industrial compact enclosure) is optimised for the Intel Pentium M / Celeron M based APOLLO single board computer. The APOLLO ICE 1U is a rugged industrial computer built from seam welded, mild steel. It includes a 180W universal AC input power supply, front panel 'user' information & navigation display, & provides easy access to all the features of the high performance APOLLO platform. The standard system includes a low profile DVD/CDRW drive, floppy drive and internal 2.5" disk drive.
http://www.eurotech-ltd.co.uk/en/products.aspx?pg=PRODUCTS%20Industrial%20PCs&pc=35
|
|
|
Nematron complete range of Shoeboxes and Rackmounts are UL/cUL certified. They come standard Intel Core 2 Duo E8400 3.0GHz CPU's, DRAM up to 4GB and 80GB HDD. Several models available with 6-, 8- or 14 slots. Contact Nematron for more details and suitable Monitors: sales@nematron.net.
|
|
|
|
|
|
Introduction
The V481 embedded computers are based on the Intel x86 processor, and come with VGA interface, dual LANs, 8 serial ports, CF, USB, and audio. The VGA interface was included to make this computer well-suited for industrial applications, such as SCADA and factory automation.
The V481 computers come with 8 software-selectable RS-232/422/485 serial ports built in, making them ideal for connecting a wide range of serial devices. The 10/100 Mbps and 10/100/1000 Mbps LAN ports offer a reliable solution for network redundancy. And, the second CompactFlash socket makes storage expansion easier, and the USB slots can be used to connect different types of devices.
The V481 comes with the Windows CE 5.0 or Windows XP Embedded operating system pre-installed. The great software support that Moxa provides makes the programmers job easier, and makes it possible to develop bug-free code quickly and at a lower cost. In addition, the -35 to 75C wide operating temperature model is also available.
Features
Intel Celeron M 1 GHz CPU, 400 MHz FSB
256 MB (CE) or 512 MB (XPe) DDR SDRAM, 256 MB (CE) or 1 GB(XPe) industrial CompactFlash built in
8 software-selectable RS-232/422/485 serial ports
Serial port speed from 50 bps to 921.6 Kbps, supporting non-standard baudrates
10/100 and 10/100/1000 Mbps LANs for network redundancy
Supports 2nd CompactFlash socket for storage expansion
2 USB 2.0 hosts that support system bootup
LED indicators for system power and storage
Designed to withstand 5G continuous vibration and 50G shocks
Ready-to-run WinCE 5.0 or Windows XP Embedded platform
DIN-rail or wall-mount installation
Robust, fanless design
|
|
|
|
|
|
The W406 is an embedded Linux or WinCE computer that features 2 software selectable RS-232/422/485 ports, 1 Ethernet port, and quad-band GSM/GPRS/EDGE 900/1800/850/1900 MHz for cellular communications. It also comes with an SD socket, USB host, and 4 digital input and 4 digital output channels, making it the ideal computer for a variety of industrial applications such as data acquisition, data processing, protocol conversion, and remote device control and monitoring via wireless communications. The W406 comes pre-installed with either Linux or WinCE 6.0, and offers a reliable and powerful computing platform for industrial environments. Programmers will find that the W406 provides a convenient programming environment for producing bug-free industrial applications at a lower cost.
Features
Cirrus Logic EP9302 32-bit ARM9 processor
On-board 32 MB RAM
Built-in 16 MB Flash
Built-in GSM/GPRS/EDGE cellular communication
GSM 850/900/1800/1900 MHz supported
GPRS/EDGE Class 12 supported
SMS tunnel mode provided
4 DIs, 4 DOs
Two software selectable RS-232/422/485 serial ports
50 bps to 921.6 Kbps, non-standard baudrates supported
10/100M Ethernet for network redundancy
SD socket for storage expansion
WinCE 6.0 or Linux 2.6 platform
Din-Rail and Wall mount installation
Robust, fanless design
|
|
Display Type : 12.1(X-123) , 15.0"(X-152) TFT LCD
Resolution : 800 x 600(X-123) , 1024 x 768(X-152)
CPU : Intel Mobile Celeron 1G
Memory : DDR 512MB (1GB optional)
Storage : Flash disk 4G ~ 8G(HDD 80G optional)
Ethernet : 10/100 Base-T Interface
Port : 2 x RS-232(One port with RS232/422/485), 4 x USB 2.0, VGA,
DIO(internal), Printer(Internal)
Operation Temperature : -5℃ ~ 55℃, Storage : -10℃ ~ 70℃
Power Supply : AC90 ~ 264V, AC50 ~ 60Hz, 60W
Net weight : 5.5kg (X-152), 4.6kg (X-123)
|
|
|
|
|
|
A very gravitational tactile terminal.
Prize winner of the National G-Mark Design Award 2007 in Japan.
An ergonomic and astute design with small overall dimensions for recordings customers and an optimized space of sale.
Design: With the elegance of its vertical lines, its black color, the ST-A10 presents a very attractive ergonomic design, both for the user the customer.
Manufacturer quality: Terminal ST-A10 has a touchscreen luminous and durable, sealed to resist projections of liquids and dust, and ideally adapted to the difficult conditions of the restoration and specialized trade.
Reliability: Conceived to function under difficult conditions (moisture, heat) - It is a stable, reliable and durable platform material with a very weak ownership cost.
Respect of the environment: Products TOSHIBA tce take part in the reduction of the carbon dioxide emissions throughout their life cycle, of the production in our factories, while passing by their use, until the process of recycling.
Easy maintenance: Terminal ST-A10 has a single system of opening by "clips" to reach the main components and to replace them (hard drive, memory or power supply unit), which makes it possible to minimize times of inactivity of the TPV and to offer the most adjusted costs of maintenance of
The ST-A10 is in total conformity with directives RoHS and DEEE.
|
|
|
|
