Ready to mount 2- or 3- axis systems are also available for electrical cylinders with 24 VDC pulse or 230 VAC servo motor. Thereby the x-axis is a slider type with iron base.
|
|
Motorized solution for sit/stand workplaces - stepless height adjustment to customer specific travel distance
- simple mounting
- integrated position measuring system
- single telescopic function
- synchronisation with up to 24 actuators
|
|
A wide range :
CAT: The modular design concept
CAP: A vast number of possibilities such as motors, front and rear attachments etc.
CAR: A unique standard of performance, durability, and reliability.
MAGFORCE: A spindle lifting drives with worm gears.
Matrix: A powerful AC and DC-actuators
CALA: A compact 12 or 24V DC actuator, intended for industrial use.
ILD: The "Intelligent Linear Drive"
CARE 33: A high dynamic load capacity, silent operation and low current consumption.
RUNNER: A very compact, high performance actuator
|
|
SMAC electric cylinders have been designed with the most demanding of automation tasks in mind and are the first real linear motors to challenge pneumatic devices.
They offer long life and much more precise & repeatable force control and positioning than conventional pneumatic devices. The conventional shape and multiple mounting points allow the electric cylinders to be directly retro-fitted in most cases.
40G Acceleration, 100million+ cycle life.
Compact, Lightweight & Outstanding Performance.
Fully Programmable Force, Position & Velocity.
100 Data Capture & Feed Back Facility.
|
|
ERC and ERC2 series - Easy to Use RoboCylinder
An electric cylinder with built-in controller offering the ultimate in simplicity.
Available as slider and rod type
|
|
RCA Series is a compact RoboCylinder with 24 VAC servo motor and optical encoder.
The product has widely been accepted not only as a compact, programmable, electro-mechanical alternative to air cylinders, but also its integrated PLC function and user-friendly SEL language have made RCA Series an absolute all-rounder in the factory automation.
|
|
RoboCylinder RCS is an electric actuator with ball screw, linear guide and 230 VAC servo motor. Using the know-how obtained from manufacturing 150 thousand axis robots, while retaining the features such as high rigidity, acc/decl, and speed control, the price has been lowered to match that of rod-less pneumatic cylinders.
RCS Series is the next generation electric actuator that employs a high-speed, constant thrust force motor, which maintains constant payload at speed ranging from low to high.
|
|
Designed for ease of use and versatility, the new RoboCylinder RCP2 series features high performance, high ridigity, and high functionality.
Two new width sizes - 73mm Slider Type and 35mm Rod Type - have been added to the lineup, giving you more flexibility for your application needs. In addition, significant technological enhancements have been made in all areas, such as lower operating noise, ease of maintenance, and multi-point positioning of up to 512 points.
|
|
High Performance Electric Servoactuator – INDACT® – According to ISO 6431
ISOMOVE (1-20KN)
• Electric servoactuator by the means of a precision Ball Screw, suitable for high performance applications, featuring overall dimensions and mounting style according to ISO 6431.
• 6 different sizes (IM032, IM040, IM050, IM063, IM080, IM100).
• Wide range of Ball Screw Pitch selection for each size.
• 3 different motor drive solutions (Stepper, Brushless, Custom).
• “D” version featuring axial / direct mounted motor drive with zero-backlash coupling.
• “R” version featuring reduced / parallel mounted motor drive with zero-backlash belt gear.
• 2 different reduction ratio (1:1, 2:1 – “R” version only).
• Max Nominal Thrust up to 20KN.
• Max Linear Speed up to 1600mm/sec.
• High Efficiency mechanical transmission.
• Duty Cycle 100%.
• Grease lubricated.
Modular design according to ISO 6431 allows for maximum adaptability to the widest range of industrial high performance applications.
Wide range of standard accessories/features to ISO 6431.
Special execution on request, please contact Setec Group Italy.
|
|
Electromechanical actuators becoming more and more the preferred drive technology in the field of linear motion. That is because they can handle a wide range of payloads, provide the desired controlled motion and are cost competitive.
The rotational movement produced by the electric motor will be converted into linear movement by trapezoidal thread spindles installed within the thrust unit as basic design. The selection of spindle lead guarantees self locking for RACO´s electric actuators. Static loads, which can be higher than the nominal thrust, can be maintained in any intermediate position.
Benefits:
High efficiency of the mechanical system generate high power output
Long lasting operation through wear and tear resistant thrust unit components
High reliability even under worth ambient conditions
Full electromechanical principle without any leakage issue (does not ice up or freeze)
Fulfill actual safety and environmental requirements
Does not consume energy when stopped
Easy to install and putting in operation
Low operating and maintenance costs
|
|
Acme screw linear actuator with worm wheel geared motor.
Self enclosed end switches.
Maintenance free. Life long lubricant, noiseless running.
DC motor.
Linear speed up to 55 mm/sec
Load up to 6.000 N
|
|
|
Electric cylinders are self-locking. So they do not need energy when they stand still. This makes the electric cylinders to be an interesting alternative to pneumatic and hydraulic actuators. Powerful DC motors, signal lines, potentiometers and Hall-ICs for position indication, as well as integrated end switches uncomplicatedly serve for meeting the most frequent requirements.
|
|
HAYDON is recognized worldwide as a leader for linear stepper actuators, based on the most advanced patented technologies converting the rotational motion into a linear motion.
In addition to its Hybrid range of motors, Haydon is offering a complete family of linear actuators ranging from 15mm square to 46mm square. All sizes have three designs available – captive, non-captive and the external linear version. There are over thirty different travels per step available, from 20 microns to 400 microns.
Rare earth magnets are available for higher thrust requirements. All units are built with dual ball bearings for greater motion control, precise step accuracy and long life.
Haydon custom designs and manufactures linear stepper motors for medical equipment, instrumentation, industrial equipment and many other applications.
|
|
Electromechanical remote cylinders
We lead qualitatively high-quality electromechanical remote cylinders, which can replace pneumatics and hydraulic cylinders and save energy, place and river in such a way, while they simplify the control and make an accurate positioning possible.
By the extensive selection of different models we find optimal electrical cylinder for your application, all the same whether small, fast, quietly, high performance, splash-proof or easily.
|
|
Dynamic with roller guide.
• Max. stroke 5,000 mm
• Max. speed 10 m/s
• Repetition accuracy ±0.1 mm
• Max. feed force 1,500 N
|
|
Electric motor solution for the individual sit-stand work station. Stepless height adjustment with customer specific stroke.
- drive for the assembly in the table base
- simple mounting
- integrated position measuring system
- single telescopic function
- synchronisation with up to 26 actuators
|
|
LINAK has several years of experience in development and manufacture of 12 V DC and 24 V DC actuators. The LINAK actuator range offers lifting capacities ranging from 200 N to 12.000 N. All the linear actuators consists of three principal elements: A motor, a gear and a spindle including nut. The actuator is the unit, which converts the
operating voltage from the control box into a linear movement. Some of the actuators are available in black and grey. Please contact your LINAK representative for further specifications.
|
|
Moog provides a wide range of custom Electro-Mechanical actuators for total axis control for industrial applications. All of our actuation products have the proven reliability and precision required for high performance motion control and long service life. Available in multiple sizes and with a selection of Moog-designed and built servomotors and drive electronics, actuation products are built to meet customers requirements.
Moog’s total axis control solutions include the all-steel 887 series with the ability to accommodate peak forces of 350 kN [80,000 lbs.] It is a fully validated, tested option for the most demanding applications.
|
|
|
The Rolaram actuators are designed for precision applications which require high speed and medium to high duty with loads up to 400kN. There are 8 standard models to choose from with varying options, however all units can be customised to suit your exact application requirements.
|
|
A comprehensive selection of linear actuators with programmable control of force, position & velocity. Standard resolution on all SMAC actuators is 5micron with 1micron and half micron options available. They also have a 100% Data Capture & Feed Back Facility.
They are designed to perform at exceptionally high speeds and with a very high degree of accuracy & repeatability. This makes them ideal for a wide range of positioning, measuring, inspection and pick & place applications. Particularly where 100% verification is required.
|
|
Venture DC Linear Actuators are available in both Acme Screw or Ball Screw versions and combine our Quality Linear Actuators with a DC voltage electric gearmotor providing a ready to install electric linear drive system.
Standard strokes 4, 8, 12, 18, 24, 32, 36, 40 and 52 inches (custom lengths available)
30% duty cycle motor rating
Optional features include;
Clutch
Limit switches
Reed, Hall Effect, Potentiometer and other sensor options
3000 lb static capacity / up to 1500 lb dynamic load
Lifetime lubrication
Designed for outdoor use
Compression or tension loads
Trunnion, Clevis, or Tube clamp mounting
High strength steel tube assembly with all-steel load support members
Long Life Acme or Ball Screw
12VDC, 24VDC, 36VDC, 90VDC, or 120VDC for rectified 120VAC Gearbox Designs
|
|
Compared to their pneumatic and hydraulic "colleagues" electric linear actuators have many advantages:
- constant stroke speed
- no loss of oil
- mechanical self-locking
- almost maintenance-free
- exact positioning
- large number of speed variants
Whenever optimum combinations of load, speed, installation dimensions, precision and robustness are sought, elero actuator and control systems have the answer.
Even in extreme operating conditions such as:
- heat
- cold
- dirt accumulation
our actuators are trouble-free. Special models can be made of stainless steel, for example,to enable our products to be used outside or in the food industry.
|
|
|
There is an increasing demand for comfort, economic efficiency, safety and respect for ecological values, factors which drive forward the increased use of precisely controllable systems. This requires compact, high-performance and robust actuators at the interface between the control mechanism and the controlled processes. SONCEBOZ linear actuators are eminently suitable for such tasks. This is why they handle idling control in vehicle engines, control three-way valves in heating and air conditioning equipment or control physical processes in medical analysis appliances. All this is possible only because of the robustness against environmental influences, the high precision and proven quality of actuators.
|
|
A comprehensive selection of combined linear rotary actuators with either direct drive or gearbox equipped rotary units. Standard linear resolution on all SMAC actuators is 5micron with 1micron and half micron options available. Fully programmable in force/torque, velocity and position with 100% data capture and feed back facility. The rotary resolution varies between 4864 counts for gearbox units and 20,000 counts for the direct drive. This makes them ideal for a wide range of positioning, measuring, inspection and pick & place applications. Particularly where 100% verification is required.
The SMAC unique “Softland” routine within the actuator allows the rod to approach at high speed then land on the surface of a component with a low programmable force. This unique feature is extremely useful whenever delicate or high value components are being handled.
SMAC electric actuators are used widely in packaging, labelling, automotive, SMT, robotics, pharmaceutical, medical assembly, laser cutting, high speed scanning, glass cutting, dispensing, switch testing, spot welding, soldering & measuring applications to name but a few.
|
|
The BEI Kimco Magnetics RA models are used in many applications ranging from Z axis control in semi-conductor lead bonding equipment to gimbal torques and pick-and-place robotics. Actuators feature maximum stroke of +/- 60 degrees, maximum torque of 20nm, through hole and set screw hole for easy shaft coupling and two through holes for field assembly mounting. Choices include arc-segment and cylindrical designs.
|
|
The ROTARY system is nothing less than a revolution, a silent one that the user does not even notice, as it works behind the scenes. The effect, however, is clear to everybody and ROTARY is the powerful alternative for manufacturers of care and rehab beds. By supplying the
ROTARY motion directly, the number of fittings required on the bed can be reduced. This enables bed manufacturers to integrate a ROTARY actuator far more elegantly than a linear actuator."
|
|
|
SKF rotary actuators are designed to provide rotary motion. Fast or slow. Heavy or light duty. Complex or simple arrangements. You can chose from a wide variety of application areas. You will find a solution with both technical and economic advantages. Since the gearing is produced in one stage, through the use of a ball screw, you can also rely on a high degree of efficiency. Select the zero-backlash versions for maximum precision.
|
|
|
