HUMMEL aluminium enclosures are made of Al Si 12 and are silver grey powder coated. Hinges can be mounted to its sides, latches to the bottom. Aluminium resist numerous alcalis and chemicals as well as oil and gasoline. They are very impact resistant.
|
|
The new IDG-A1 DIN rail mount enclosure is ideal for applications requiring a housing for smaller pcbs and minimal DIN rail space loss. The IDG-A1 has sleak lines, making this an attractive packaging medium for applications such as home/building automation.
This enclosure has been designed according to DIN 43 880, providing the dimensions and specifications required for installation component standards. Conforming to VBG 4 and IEC529/DIN VDE 0470-1, the IDG-A1 prevents accidental shock and injury while meeting the requirements of the automation industries.This new housing enables users to incorporate one vertical pcb and a top horizontal pcb or three horizontal pcbs. The top horizontal pcb is ideal for holding signalling devices/indicators and switches. Fully populated, the terminal blocks have a maximum of 12 screw clamp terminals. For applications not requiring all 12 I/O positions or requirements for additional internal space, selective loading may be done, with empty positions being filled with blind plugs.
|
|
The LDG-S serie of enclosures are fully insulated enclosures according to the specifications of the machinery and the auto motive industries.
Designed for easy snap-on assembly onto DIN-rails by integrated snap-on clip. These enclosures facilitate economical device assembly with optimal utilization of space. For the termination of the conductors of the cable 2 enclosure versions are availible:
- pluggable terminals for easy servicing and exchange (commercial pin headers on the pcb.
- screw terminals for a fixed termination of the conductors. For effective heat dissipation the LDG-S enclosure features a base part with integrated ventilation slots. Closed versions (without ventilation slot) are availible upon request.
Features:
2 installation widths: LDG-S2: 22.5 mm; LDG-S4: 45 mm.
Options for the termination of the conductors:
LDG-S2: 4 screw terminal blocks with 4 terminals each or 4 pcb headers with 4 pin contacts each for connecting cable cnnectors with 4 pins.
LDG-S4: 8 screw terminal blocks with 4 terminals each or 8 pcb headers with 4 pin conacts each for connecting cable connectors with 4 pins.
Easy snap-on assembly on DIN-rails according to DIN EN 50 022
Easy assembly of the enclosure achieved by snap-in design of the two base part and the top part
Transparent housing cover with the option for a label
Customized colors and versions upon request
|
|
DISTRIBUTION ENCLOSURES
ECOLOGY series of distribution enclosures can be sealed and they are provided with opaque or transparent (UV protected) reversible windows. They are made from halogen free longlasting plastic material and equipped with dust caps for wall mounting screws and 1/4 quick locking unloosable screws.
They have supports for mounting plates fixing, they are prepared for installation of earth and neutral bars and cable entries are adapted to the metric system. On the 26 and 57 modules versions DIN rail can be adjusted on its height.
|
|
Our product range contains a wide variety of enclosures which offer a selection of sizes, designs and materials. It is designed for single installations as well as for large distribution units. The dimensions of the enclosures are so designed that they can be combined into a large modular unit. A large number of components, such as contactors, switches, instruments and PLCs can be built into these enclosures. Naturally, customer-supplied equipment layout is designed by us to customer's requirements. Cable entry is either direct (cable glands or conduit entries) or indirect via en EEx e housing (stud-type or conductor bushings).
The design and installation of explosion-protected distribution and control boards having flameproof enclosures require considerable experience and careful consideration of relevant regulations in relation to the application data. Only thus are technically and economically satisfactory solutions, which combine a user-friendly design with a high degree of safety, possible. In addition to Ex-regulations, the general regulations must all be bserved in the assembly of distribution and control boards.
Standard industrial electrical equipment can be bult into enclosures. It is, however, subject to a "type test" by a recognised testing station. R. STAHL has such certificates issued by PTB permitting the assembly of explosion-protected systems for all standard applications.
|
|
In an attempt to continuously satisfy the market needs, IDE presents its Fireproof Register Covers. These
RF60 FIRE PROTECTION REGISTER
register covers are especially designed to be installed in landings of buildings to act as protectors for the electrical wiring and as a fire barrier in the event of fire, actively preventing flame propagation. The metal covers are made of cold-rolled steel plate and they have an insulating panel comprised of a silica sand compound that prevents flame propagation.
They are available in three different sizes: 450x500 m, 500x700 mm and 300x1350 mm, thus adapting to the requirements of the applicable regulation. They are manufactured in accordance with the requirements of the REBT: 2002 (Low voltage electro-technical regulation) and the NBE-CPI-96 (Basic building code) and are certified in accredited laboratories according to UNE and EN standards. The RF60, RF30 and EI260 qualifications have been obtained (depending on versions).
|
|
Simplify your next operator interface project with a STRONGARM mounting and enclosure combination.
Enclosures are designed to your exact terminal specifications; including the cut-out, cable space, drive access and cooling requirements. Specify pushbutton cut-outs and other extras to complete the ideal, hassle-free enclosure to complement your STRONGARM mounting. Enclosures are specially reinforced for pendant arm mounting to assure solid, wobble-free operation.
Features:
• Operator "friendly" interface
• Compact and repositionable including three levels of vertical travel (13", 23", 30")
• Internal, local, or remote PC (Internal MicroBox PCs available from STRONGARM)
• Multiple keyboard and pointer selections (including STRONGARM's revolutionary Stainless Steel Mouse)
• Feature panel for easy pushbutton additions
• Post Mount, Machine Top Mount, Wall Mount and Ceiling Mount available
• Horizontal and vertical extension capabilities
|
|
OEM Enclosures- PC or ABS
Manufactured from high performance thermoplastic, polycarbonate or ABS. these Enclosures are suitable for demanding OEM applications, e.g. for the protection of electronic and pneumatic components.
|
|
The new DIN enclosures IDG-B6 and IDG-B9 arefullv insulated and fulfill the requirements of the machinery and car industry.
The enclosures have the installation width of 105 mm for the IDG-B6 and 157 mm for the IDG-B9. They are designed for easy snap-in assembly on DIN-rails.
Three different versions of the housing cover allow customer specific solutions- There can be used commercial terminals from different suppliers or for matea-ble solutions with terminal plugs the according PCB headers from different suppliers with the according terminal plug headers.For solutions with connectors or terminals on the front side there is a fully closed version available.
The transparent front cover protects displays, Potentiometers or other contol devices on the front side against disadjustment or damages.
Features:
2 installation widths:
IDG-B6:105.0 mm, max. 36 terminals IDG-B9:157.0 mm, max. 52 terminals
Overall dimensions per DIN 43 880, size 1
Mountableto DIN rails per DIN 46 277 und DIN EN 50 022
Various termination options: 5.0/5.08 mm terminal blocks 5.0/5.08 mm; pluggable terminal block; Choice of connector on front cover.
Transparent front cover protects displays and control devices
DIN rail clip pre-assemled on housing base
Choice of colors and custom design available upon request (pending min. volume)
2 smaller installation widths are also available: IDG-B2: 35 mm; IDG-B4: 70 mm
|
|
IP65-IP67 TIGHT JUNCITION BOXES
Light Series of tight derivation boxes are sealable and made from halogen free long lasting plastic material.
Include 25 and 40 mm. conical cable glands on the EV versions, remoulded entries on the EX versions and plain sides on the EL references. 1/4 turn unloosable and sealable screws are incorporated for fixing the lids to the bases.
The motor protection boxes have an ample internal space for installation of mechanism of larger size, and they are available with transparent and paque lids.
All enclosures are adapted to the metric system and include supports for installation of DIN rail and mounting plates on the base.
|
|
These Enclosures are made of 304 Stainless Steel used in terminal boxes.
We offer acid resistant AISI 316 Stainless Steel solutions upon demand.
Standard equipment includes a perforated mounting angle to facilitate installation of the mounting plate or DIN rails. This makes it possible to drill access holes for cables anywhere along the sidewalls.
|
|
Boxes ATEX GAS and Poussières Z1,2,21, 22
The boxes ATEX Gas and Poussières of CEFEM Technologie are consignment and shutting-off devices intended to be used in the zones at the risk of explosion zone 1,2 gases "G", 21 and 22 dust "D" according to the European directive 94/9/CE.
They answer the normative and regulatory provisions to guarantee the safety of the operators who intervene for the emergency cut, the cut for mechanical maintenance and the cutting of safety near any final circuit low tension.
They are composed of a switch disconnecting switch IM with visible cut ordered by a right side handle cadenassable by three open locks in position interruptory.
A machine-position indicator (ON/OFF or I/O) makes it possible to visualize the position of the switch at a single glance.
The cut of the system is clearly visible by the operator through a window out of glass.
Complementary functions can be equipped according to your schedules of conditions: Pushbuttons, presses packings, instrumentation, etc...
Application:
All industries in zone at the risks of explosion gas and dust zone 1,2,21 or 22
|
|
|
Die cast in aluminium alloy and resistant to atmospheric and marine corrison. These enclosures are ideal for housing sensitive electronic assemblies and eletrical devices in both commercial and industrial environments.Gasketed with foam installing machine for preventing ingress of moisture and dust. Die cast Box's dimension is from 65x60x35 mm to 225x150x80mm. Also, all of HIBOX's products are waterproof and dust-free. (IP 66~67, NEMA 4X) Refer to the general catalogue of HIBOX on Direct-Industry or www.dsehibox.com
|
|
Conformity: Directive 94/9/EC (ATEX)
EC-type Examination Certificate: LOM 02ATEX2034X
Applicable standars: EN 50014, EN 50019 and EN 50281-1-1
Type of protection: EEx e II T6
Equipment classification: 2
Zones of use: 1, 2, 21, 22
Protection grade IP-65 (*) by standards UNE 20324, CEI 529 and EN 60529
Room temperature of use: -20ºC/+40ºC (under order -40ºC/ 55ºC).
CHARACTERISTICS
Series 3000 boxes are suitable for containing terminals for junction systems. They must be installed according to the instructions of standards EN 60079-14 and EN 50281-1-2.
MATERIAL. Box and cover manufactured in aluminium alloy.
SURFACE FINISH. Coated with grey epoxi polyester powder (similar to 7042 RAL) with coarse texture, made by electrostatic projection and dry into an oven to 180-200ºC. To obtain a perfect degreasing and absolute absence of dirt and dust, a pre-tratment is carried out before the surface finish, wich consist of a neutraltype degreasing followed by a non-chromic conversion to aluminium (i.e. no damage to the environment), finished with a dry to 80ºC.
|
|
|
A wide range made up of monobloc enclosures for wall or floor fitting, made in sheet steel painted with polyester resin or manufactured in stainless steel. Combinable modular enclosure systems, ideal for building up large frames and control desks.
|
|
Floorstanding metallic cabinets
Wide range of floor standing metallic enclosures with sizes and characteristics according to DIN 41494 and IEC 297, specially conceived to meet the necessary requirements of big networking and data/voice communication facilities. An excellent quality, added to a stylish design and a high sturdiness.
All Aplei metallic cabinets are CE Certified according to Council Directive 73/23/EEC.
CONSTRUCTIVE FEATURES
Built in 1'5 mm. and 2 mm. thick for the enclosure and 2'5 mm sheet steel for the frame.
Equipment supports of 19" movable in depth.
Cable entries may be performed either by the upper or by the downside part.
Excellent ventilation system by means of lateral slots.
Detachable and reversible glass safety door with key lock.
Lateral and back panels easily detachable.
Baseboard supplied as standard.
Up and down ground connection inlets (optional grounding bar).
Adjustable levelling legs (also available with castors).
Range of supply from 25 U. to 45 U. of high.
Possibility of multiple assembly system.
Coated with epoxy powder. Fine textured in two kinds of textured grey RAL 7035 and RAL 7042 frame and fine textured blue RAL 5010 door.
800x800 floor standing cabinet fully detachable.
Wide variety of fittings: trays, tags, flanges, etc.
|
|
OKW offers a comprehensive range of cases for DIN rail mounting. All types are extremely installation-friendly, for mounting components as well as for connection work!
Your advantages:
- Different connection options for commercial components such as terminals, PCB plug headers and front connectors.
- Without/with integrated connection system.
- Without/with ventilation slots.
- Different sizes following DIN 43880, unit 1.
- Suitable for DIN rails EN 60 715.
|
|
|
All of DSE HIBOX products are Water-proof and Dust-free. (IP 66-67, NEMA 4X) HIBOX received UL 5VA. That means HI-BOX products have been perfected to the highest commercial standards through reinforcement of the box's thickness by more than 30% over existing plastic electic enclosures. The enclosures dimension start from 50X65X55 to 600X800X280 mm and DSE have 400 kinds of enclosures-! Refer to the gereral catalogue of HIBOX in Direct-Industry or www.dsehibox.com
|
|
All of DSE HIBOX products are Water-proof and Dust-free. (IP 66-67, NEMA 4X) HIBOX received UL 5VA. That means HI-BOX products have been perfected to the highest commercial standards through reinforcement of the box's thickness by more than 30% over existing plastic electic enclosures.
DSE Electronic Box has been developed to protect electrical and electronic components in wet, dusty, and hazardous environments.
|
|
|
An extensive range of enclosures and accessories that let you install any voice and data application in any area, be it industrial, services or tertiary sector.
|
|
Schlegel and DUX enclosures offer much space inside safeguarding your control units and terminal blocks to an optimum. The enclosures are made of plastic or aluminium alloy casting.
The varied types allow to find the right enclosure for every application.
|
|
INTERTEC instrument enclosures are made of long fibre reinforced polyester (GRP) in sheet moulded compound design. The enclosures are very strong and have an excellent chemical resistance. They are therefore preferred in chemical industry and raffineries.
INTERTEC offers worldwide the largest range of instruments enclosures as well as the corresponding mounting systems.
|
|
As practised by automation engineers for some time, the trend in engineering and plant construction is strongly towards the supply of complete systems. Drawing on several decades of experience, INTERTEC does not have to reinvent the wheel for every new project. Access to an intelligent modular concept allows industrial quality at low costs.
SAFE LINK - A Convincing System
• Enormously reduced engineering costs
• Low material procurement costs
• Pre-installed hook-ups save time and costs at the site
• Sensible standardization reduces the variation in range of instrument installations and saves storage costs
• Field-proven and practice-proven solutions for traditional installations and innovative direct mounting
• High measuring accuracy resulting from short impulse lines
|
|
Enclosures for lightning
Aplei has designed and successfully tested enclosures of connection for lightning which offer an emergency illumination during the extreme conditions of a fire. These enclosures guarantee the continuity of the electrical supply during 120 minutes under fire conditions, with a constant taking-off temperature of 842º C, and they comply with the requirements of the UNE EN 50200 regulation. The product has successfully surpassed different tests under air pressure conditions over those required by the regulation, equal to the action of wind and movement of air generated by a high velocity train passing by. Together with the enclosure itself, the product has the connection of cablegland produced by Aplei, which can be both in stainless steel or polyamide.
Lights
Lights designed by Aplei are also created to support special conditions in tunnels. Alloyed with aluminum, they have an enclosure and a safety crystal. As well as the enclosure, the light is provided with a cablegland of Aplei and bulbholders.
|
|
Beautiful appearance, excellent processing and stability should be guaranteed by material such as High Intensity ABS, PC, AC, and Polyester assured, Flammibility material and Glass 30% annexing material. The products was recognized by the Public Trust International Mark Germany VDE, TUV European Community CE and USA Underwiters Laboratories. The use is convinient for the installation of Terminal Box, the supply Swithchboard, Apparatus Box, electrical power supply and Control Box etc.
HIBOX has a various kinds of terminal box. The dimension is from 190x190x130 to 380x560x180mm. Also these boxes can be customized by cutomer's order. Also, all of HIBOX's products are waterproof and dust-free. (IP 66~67 NEMA 4X) Refer to the general catalogue of HIBOX on Direct-Industry or www.dsehibox.com
|
|
The two body wall-mounted metallic cabinet is a variation of the one body model and it can be made under request.
This type of cabinet maintains the same performance but helped by two pivoting bodies that make easier the wiring installation and facilitating a rear access even when the cabinet has been mounted.
The base body, sized 100 mm. in depth, once installed on the wall, increases the total depth of the enclosure in the mentioned measure.
Built according to dimensions and features of DIN 41494 and IEC 297 standars.
|
|
Desktop housings are available in different sizes and types. They offer designer aesthetics for interior applications.
Your advantages:
- Generously dimensioned, comfortable control and interface panels.
- Ergonomic shape.
- The PCBs can be fitted on both sides with interfaces that project beyond the actual width of the case.
- Non-slip pads for secure table top applications.
- Easy mounting.
- Comprehensive range of accessories.
|
|
The comprehensive range of boxes for potting electronic assemblies. With special cost advantages for series-type production.
Potted assemblies are protected from shock as well as temperature, dampness and chemical influences. The versions made of Duroplast are not highly resistant to fracture.
|
|
Self-extinguishing insulated boxes with double insulation. The bases and opaque lids are in PVC and the transparent lids in polycarbonate. Polished light grey surfaces to RAL 7035.
- Sealing gasket in all models.
- Lid fixing by lodking screws or hinges.
|
|
|
The range of moulded endosures is made up of a wide selection of products such as modular boxes, wall fixed cabinets adapted to special applications for buildings, floor fixed for industrial facilities, electrical distribution, public lighting, etc.
|
|
|
|
