Easy to plug, and easiest to play
The Vacon NXL is a powerful and compact Alternating current drive for industrial and residential purposes in the power range from 0.25 to 30 kW.
The space-saving bookshelf design with high protection classes, versatile control and programming capabilities offer an optimal solution for all operating environments. Installation, connection and commissioning procedures are extremely quick and convenient with instructions attached to the unit.
Thanks to an extremely effective design, everything is included as standard. The units can be installed on the wall without additional professional cabinets because of high protection classes. The Electromagnetic interference filters and professional brake choppers are always integrated. The standard units fit almost everywhere in both industrial and residential areas. The integrated AC choke is the most effective way to protect the drive against the overvoltage spikes and to reduce the stress on supply transformers, professional cables and fuses.
More features, more performance
No additional cabinets required
Everything integrated as standard (dust/water protection, RFI professional filter, AC choke, brake chopper)
Easy to install, easy to use
Low noise (both drive and motor)
Large amount of control possibilities (via I/Os, field buses or display panel)
Large amount of features (e.g. fully programmable I/O, autoidentification, Pid control, flying start)
High performance
|
|
The Vacon NXC industrial cabinet drive is compact and well tested, fully utilizing the flexibility of the Vacon NXP drive.
The Vacon NXC is designed to meet the most demanding requirements on flexibility, robustness, compactness and service-friendliness. It is a safe choice for any application.
Easy ordering
The Vacon NXC incorporates the frequency converter and optional items such as mains switch, contactor, control options as well as output fi ltering in one compact unit which is easy to install and service. Ordering is made easy by integrating the Vacon NXC enclosure options into the typecode to which they are appended with “+” codes. The Vacon NXC cabinet drive is compact and well tested, fully utilizing the fl exibility of the Vacon NXP drive. The Vacon NXC is designed to meet the most demanding requirements on fl exibility, robustness, compactness and service-friendliness. It is a safe choice for any application.
|
|
A full series of flexible solution drives that are versatile and extremely easy to use, featuring control for high performance and unbeatable advantages in their scalability and compact size.
|
|
The frequency inverter for harsh environments NORDAC SK 750E
With its high IP 54 class of protection, the SK 750E is optimally equipped to meet the requirements of distributed drive control.Allowing for alternative mounting options (wall or motor as appropriate) the device can smoothly be integrated into the existing machine and system architecture.The NORDAC SK 750E is a robust drive control package available with outputs between 5.5 and 22 kW, for connection to supply voltages between 200 and 480 VAC.
|
|
The Vector 20 is a Frequency converter with a modulated attachment, which in it´s basic offers excellent market value for goods by using simple applications.
With extra integrated modules it can be alternated for a controlled drive with vector-control or upgraded to a positioning type. The device shows a protection class of IP 20.
The Frequency Professional converter VECTOR 20 is available from 0.09KW till 3KW single phase and from 0.75KW till 3 KW three-phase. |
|
FC750 is a very simple, yet efficient Plug & Play frequency converter for the growing market in simple speed control of 3 phase asyncronous Alternating current motors. The FC750 has been specifically developed for the continuously demanding market involving seamless speed control of especially Professional fans, pumps, ventilators and any simple AC motor application FC750 is an totally integrated and encapsulated frequency industrial converter, with a very simple Interface,, and a very sophisticated set of fault control systems, that will ensure the motor to RUN, even in extreme conditions. The IP54 or higher professional cabinet will ensure that there will be no need for an extra Cabinet, as usually with FC´s. The integrated Emc filtering in the FC750 makes it an ideal solution for many applications, where Plug & Play is a first issue. No need for an external professional filter, no need for an exernal cabinet, no need for any "irritating" setup menus,, just plug it in, and you have a motor that spins as nice as with any other converter.
FC750 has as standard a 0-10 / 2-10V input control range with an auxilary START/STOP signal. Just a wire to the Gnd to make it spin. Also, there is an extra signal, that could make the motor turn in the opposite direction, just connect DIR to Gnd,, if it is needed. FC750 also has an "inbuild" motor protection, that will ensure that motors do not get overheated. The function can be adjusted in 9 steps from the Dipswitch. DIP=0 means NO protection. FC750 will stop the motor and activate the Alarm relay when current has been exeeded for ten times.
FC750 is not the controller for machinery etc, but is meant as a highly integrated power device for small AC motors. Fans, Pumps etc will benefit of this compact Controller. Also, applications requiring simple installation and a high grade of encapsulation will have to contact Motron for more info.
|
|
Delta Drive Micro from MOTRON is a miniature plug and play LOW COST frequency converter, intended for variable speed regulation of professional fans etc up o
370W max with a 2-10V input range and apr. 5-50Hz output range with linear
V/F control. 0V on control line will stop the motor. Delta Drive Micro is an extremely robust product in a Die Cast Aluminium Box which can be placed almost anywhere. It is simple to use, and yet very efficient in control. The electronics has been sealed with resin for maximum robustness and user connections are avaliable throgh terminals inside the professional cabinet.
Delta Drive Micro will connect to 230VAC powersupply, a standard 230V Alternating current motor and a simple 2-10V isolated control signal will command the motor to run at specified speed. Typical 5kOhm input impedance !!
Delta Drive Micro has an input detector, which will STOP the motor, if the inputsignal is less than apr. 1V=, so no need for an extra start/stop signal, its all been taken care off.
Delta Drive Micro has a number of build in safety funtions, which all will stop the motor, and retry after apr. 30 seconds. Overtemperature, motor shorts, overvoltage, undervoltage, ground failures etc will be detected and stop the motor.
Delta Drive Micro comes in different versions. Mainly, a Wall Mount version with integrated bottom flanges for mounting. Also, a Flange Version is supplied for mounting directly in some kind of Air Convection systems. This type needs to be cooled by forced air , as in Chimneys etc.
Delta Drive Micro is designed with an integrated Emc filter to comply with International regulations. Isolation between control input and live supply is designed to withstand min 3kV, according to the LVD directive. CE Pending
Delta Drive Micro is as standard supplied with glands and snap in terminals for connections, but an alternative is a Complete Delta Drive with integrated Professional cables as per Customer requirements. Cable and Drive.. |
|
An Intelligent Solution for Every Drive Task
Mitsubishi Electric delivers innovative, open, flexible and reliable drive solutions geared to the special needs of individual markets and customers.
FR-S 500 Series
• Small, compact design
• One-touch Digital Dial for simple operation and configuration
• V/f control
• RS-485 interface
• Pid control
• Motor potentiometer
• Active current control
FR-E 500 Serie
• Compact class dynamic vector frequency inverter
• SLV control method for high torque in the low speed range
• Active current limiting
• Profibus DP, CC-Link, RS-485 interface
• Integrated brake transistor
FR-A 500 Serie
• A high-end drive solution
• SLV, V/f and closed-loop control methods
• Profibus DP, CC-Link, DeviceNet, RS-485 interface
• Automatic motor specifications identification and Online Autotuning
• Soft PWM control
FR-F 700 Serie
• Simple configuration and operation with the one-touch Digital Dial
• Extensive control and data management features, incl. servicing timer
• OEC (Optimum Excitation Control) technology for maximum energy savings
• LonWorks, Profibus DP, CC-Link, DeviceNet and RS-485 interface
• USB port (optional)
• Integrated Emc filter |
|
Solid State Frequency converter with Models from 62.5 to 750 kVA, Standard 47 to 500 Hz (optional to 800Hz)
Maximize Performance and Versatility and Virtually Eliminate Downtime
Pacific's unique master/slave configuration allows up to ten 62.5 kVA mainframes to be paralleled in the field. Any mainframe may be designated as the master. A failed unit is automatically disconnected from the power grid providing unmatched mission reliability.
Pacific's MS-Series Power Source Systems Feature
-Maximum system reliability
-Rugged, powerful output
-Lower installation cost
-All frequency operation
-Lower maintenance cost
-Facility/test power flexibility
-Unmatched performance/price ratio
-Simple display and diagnostics
-Uninterruptible Power Source configuration (UMS Option) readily available
-Power: 62.5kVA/50kW for each 3060-MS.
-Voltage: 0-120/208, 3 phase. May be loaded either WYE or Delta. Other voltages are available as an option.
-Current:175 Arms per phase continuous. 350Apk per phase for non-linear loads.
-Variable Frequency range of 47-500 Hz, as well as switch selectable fixed frequency operation of 50, 60 or 400 Hz is standard on every model (800Hz optional contact factory for more information).
|
|
The Honeywell NX Series drives have been built on the principles of Professional software and hardware modularity. The power unit utilises the most sophisticated semiconductor technology, with highly modular construction that can be adapted to a customer's specific requirements.
Typical power options include input and output professional filters, brake resistors together with IP21 (NEMA1) and IP554 (NEMA12) enclosure types.
Two types of control units are available - the standard sensor-less vector control unit, which has performance that is usually sufficient for most applications. The closed loop vector control unit has servo type performance for more demanding applications - e.g. cranes, lifts, multiple synchronised drives.
|
|
- From 0.1 to 480kW, variable and/or constant torque
- Control V/F, vectorial and sensorless.
- Specific professional software designed for pumping installations and funs.
- Starvert series iE5, iC5, iG5A, iS5, iP5A, iH
- Precision, flexibility and easy operation control
- New iE5, optimum solution for small size motor control |
|
Is a user-configurable crystalbased PLL integrated circuit. It includes a digital phase detector, op-amp, VCXO and additional integrated functions for use in digital synchronization applications.
Applications
Frequency Translation
Clock Smoothing
NRZ Clock Recovery
DSLAM, ADM, ATM, Aggregation, Optical Switching/Routing, Base Station
Low Jitter PLL's
Features
Output Frequencies to 65.536 MHz
5.0 V or 3.3Vdc Operation
Tri-State Output
Holdover on Loss of Signal Alarm
VCXO with CMOS Outputs
0/70° or -40/85°C Temperature Range
Ceramic SMD Package
RoHS/Lead Free Compliant |
|
Frequency inverters are used for electronic speed control on machine drives. The needs of the market are wide and varied, and we can offer a homogeneous range of standard products for everything from simple speed control to complex applications with high requirements in respect of drive behaviour and functionality. Our drives are reliable in respect of operation, flexible in terms of application, easy to commission and meet high standards of quality. We can provide a solution to suit any requirement in the power range between 0.25 and 400 kW.
|
|
The L Series consist of a range of AC Power Source products with output power professional levels from 833 VA to 30 kVA. Using high frequency PWM technology, these units provide precision AC power in single, dual (split) or three phase configurations.
All L Series units use dual voltage ranges and programmable current limits to protect the unit under test. Standard voltage ranges of 135 and 270 Volt rms are typical but optional output range options offer voltage ranges up to 400 V rms. The complete solid state, high switching speed PWM architecture of the L Series ensures low noise and low distortion output over a wide range of power levels. |
|
- Series: CF23-05 to CF23-15 CF40-003 to CF40-026
- Output range: 0.37 kW to 2.2 kW (CF23) 0.75 kW to 7.5 kW (CF40)
- Mains voltages: 230 VAC 1~/3~ (180 - 264 VAC),
400 VAC (342 - 506 VAC
- Mains frequency: 50/60 Hz
- Output frequency: 0.1 ... 400 Hz,
- Features: Degree of protection IP 20, ambient temperature at rated data 0 - 40 ºC, relative humidity 0 - 90% (no condensation), cooling by temperature-controlled professional fan, UL / CSA approved, series is compliant with standards EN 61800-3, EN 50178 and EN 60204 |
|
Rexroth offers from now on a range of converters equipped d’ a module d’ food with high-output SINUSfrontend (SFT) re-injection, even for high powers. D’ applications; axes with the high frequency applications, range SFT covers beaches of power of 115 kw to 650 kw.
The module d’ food sinusoidal integrated reduced the returns d’ interferences on the network and returns the resistance of external braking superfluous.
Moreover, Rexroth proposes in range SFT the any last version of its extremely reliable security system IGBT which integrates a function "buffer", thus maintaining operation and l’ stop synchronized on slope in the event of cut of the network. The electronic part of the industrial converter is protected according to standard IP 54. The converters high frequency with modules d’ food sine before are very conceived for the d’ applications; transport (winding/uncurler, professional press), lifting, cut in flight and benches of tests. |
|
compact design
easy commissioning and programming
flat built-under mains professional filters available
IGBT power stage
detachable operating unit
rotating field frequency up to 650Hz
integrated Pid regulator
integrated PLC MANUFACTURERS
optionally with RS 232/485 interface
integrated braking chopper
integrated mains filter (class A)
integrated setpoint potentiometer manufacturers
6 multi-functional inputs
2 multi-functional outputs
for mounting onto Din track (up to 4kW)
degree of protection: IP20
|
|
The VS1SP Manufacturers of ac drive uses a traditional industrial inverter V/Hz control method. Its easy setup, quick startup, and right-out-of-the-box operation make it among the most popular variable speed motor controls. It is ideal for applications where multiple motors are operated simultaneously from one motor control, including pumps, professional fans, and general machinery applications.
|
|
| A full series of flexible solution drives that are versatile and extremely easy to use, featuring control for high performance and unbeatable advantages in their scalability and compact size. |
|
| A full series of flexible solution drives that are versatile and extremely easy to use, featuring control for high performance and unbeatable advantages in their scalability and compact size. |
|
Demag Dedrive Pro frequency inverters:
Our Dedrive Pro frequency inverters are high-performance components ranging from 1.5 to 560 kW for 380 to 690 V systems. They are the solution for a variety of requirements and firmly established their position in the industry. We have developed sophisticated extended functions for special requirements in your company - for example special professional crane functions. |
|
Variable Speed drives (VSD)/ Inverters
A wide range of inverters, either single or 3 phases, with power from 0.37 to 450 KW, input voltages from 200 to 480 Vac, with variable and/or constant torque.
Specific professional software designed for pumping installations and funs. Automatic process drivers with the possibility to control two motors independently with only one industrial inverter.
|
|
|
