The BA 4510 is based on an advanced, zirconia measurement cell. The highly selective cell combines high mechanical strength with consistent accuracy. With inert gases, the cell delivers an increasing signal if the partial pressure of oxygen drops thus giving a highly precise measurement of trace oxygen levels. The value is shown on the digital display and a current output is provided.
The BA 4510 has an integrated sample pump. The unit is operated with menu guided keys on the front panel.
For O2 measurement in forming gases, a special version is available.
Measurement cell does not require daily or weekly calibration and is nearly drift free
4 - 20 mA analog output
RS 232-Interface
Internal industrial sampling pump
Simple menu-guided operation
Programmable alarm output |
|
Oxygen Flue gas analyser BA 2000
In combustion applications such as process heaters, steam generation boilers or industrial furnaces, the amount of air needed to reach optimum system efficiency can vary rapidly.
Accurate O2 measurement is also essential in the control of NOx and SOx emissions. Equipped with a fast responding sensor and attached directly to the fire box, this professional analyzer provides immediate information to allow adjustment of the combustion process in real-time.
The BA 2000 is designed to ensure accurate and rapid measurement in most combustion processes. The unique fast loop design continuously provides a fresh sample gas stream to the zirconium oxide sensor. The sensor enclosure is heated to 180 °C to avoid condensation. The zirconium oxide sensor does not need any reference gas. 1-point-calibration of the sensor takes place with instrument air which is also used for the aspirator driving the sample gas. Optionally, a 2-point-calibration may be performed.
The measurement cell is protected against dust and particulates by a heated filter. The filter element can be easily replaced without tools by a 90° turn of the handle. Filter elements are available in ceramic, sintered or pleated stainless steel. The BA 2000 can be used with these professional filters for dust loads up approx. 2g/m³. When the dust load exceeds this limit, additional in-situ filters are available.
Fast response
Easy replacement of probe and filter
Flue gas temperature up to1600°C
Durable ZrO2 - cell
Ambient temperature -20°C up to 70°C
No reference gas needed
No calibration gas needed
Calibration by instrument air
No gas conditioning needed |
|
Atmospheric aerosol plays an important role in atmospheric processes There are various sources of atmospheric aerosols including combustion of fossil fuels, biomass burning or mineral dust from desert region. The degree of contribution to the above mentioned effects depends on the type of aerosols, therefore there is a strong need for instruments which can measure not only the total concentration of atmospheric aerosols, but can also classify it. Photoacoustics was always recognized as a highly promising method for qualitative analysis of aerosols, as it can measure directly the amount of light absorption by aerosols, while being largely insensitive to uncharacteristic light scattering. However photoacoustic differentiation between aerosols was strongly hindered by the fact that optical absorption spectra of aerosols are highly uncharacteristic, when measured in a narrow wavelength range. We have developed and patented a method of measuring photoacoustically the absorption spectra in a wide wavelength range, i.e. from the near-infrared to the UV. With our MuWaPas system it is possible top differentiate between aerosol types.
Besides aerosols, we also offer gas professional monitoring systems for ammonia, methane, ozone or BTEX monitoring.
|
|
°C, hPa, O2, CO/H2, CO2 determination, CO/CO2 ambient measurement, gas leak measurement, DT, DP, Eta, qA
•Instrument diagnosis
•400 measurement data sets incl. object address and plant no.
•IRDA interface for transferring data to a PDA/notebook
•USB interface for transferring data to a PC
•ZIV-driver for all other common trade software |
|
O2, CO, COlow, NO, NOlow, NO2, SO2, H2S, HC, CO2 (NDIR)
•Max. 6 measurement cells
•Fast and easy measurement cell changing with pre-calibrated measurement cells
•Measuring range extension for CO with selectable dilution factors
•Integrated Peltier gas preparation with a professional hose pumping for condensate disposal |
|
O2, CO, COlow, NO, NOlow, NO2, SO2
•Max. 3 measurement cells
•Two toxic measurement cells, freely selectable
•High-performance automatically controlled membrane pump
•Logger function
•Parallel DP and m/s measurement for flue gas measurement
•2 measurement range extensions (standard : single dilution with factor 5, option: dilution for all detection with factor 2) |
|
Extractive process gas analysis is characterized by the fact that a sample is extracted from the process line and conveyed to the analyzer. Typically, the sample is extracted by a probe, then transported through a sample line and conditioned before being processed to the analyzer.
Siemens has integrated numerous extractive analytical methods in the series 6 industrial analyzers family with a modular and consistent housing and operating concept. Each of the analyzers is thereby a class of its own:
IR-active components: ULTRAMAT 6 and ULTRAMAT 23
IR-active components and Oxygen
Oxygen: OXYMAT 6 and OXYMAT 61 and OXYMAT 64
Hydrocarbons (total content measurement): FIDAMAT 6
Hydrogen and noble gases: CALOMAT 6 and CALOMAT 62 |
|
The portable Bühler O2 Professional analyzer is suitable for various applications in non-hazardous areas. A number of options such as integrated sample gas pump, flow meter or alarm set points allow use of the unit as close as possible to the planned application.
The BA 4000 is powered by an integrated high capacity battery allowing it operate independently from a power supply suppliers for at least 14 hours. An easily accessible fine professional filter protects the measurement cell from particulate contamination. If the unit must be used for wet sample gas, a portable sample conditioning system (Model TGAK) is required
The optional industrial sampling pump is required for applications at atmospheric pressure or light vacuum. Alarm set points can be adjusted individually to indicate deviations from predetermined values. The continuous output can be configured either as 0-1 V or 0/4-20 mA. The calibration can be done easily with N2 as zero gas and ambient air as the span gas.
Paramagnetic operating principle
4-20 mA analog output
Reliable, durable measuring cell
Simple operation
Fast accurate O2 analysis
Various ranges available
Housing in IP 20
Battery operated |
|
MULTILYZER is a digital display flue gas analysis computer with state-ofthe-
art processor technology and convincing, compact design. Measured parameters: O2, COH2, flue gas temperature, combustion air
temperature, draft, pressure, differential pressure.
Options: CO20,000, NO, SO2 Calculated parameters: CO absolute,
CO2, NOx, lambda, eta efficiency, flue gas losses, dew point, temperature
difference. Options: Solid fuel calorific value EB, 15 minutes mean value for solid fuel measurement, eta efficiency condensing systems |
|
Description
Complete measuring system for discontinuous, selective measurement
and indication of up to four different gas components CH4, H2S, O2 and CO2. CH4 and CO2 are detected by means of infrared technology, O2 and H2S by means of electrochemical transducers. All components are integrated in a robust housing for wall mounting.
The system feature a 4-digit LED display and status indicators for
each measurement channel as well as a 4-line, back lit Professional lcd display.
The memory has a history function, all values can be displayed. Output
4-20 mA, fully adjustable alarm supplier of level switches and binary outputs
for: Active, Error, Calibration, Alarm. |
|
| The continuous measurement of oxygen and COe (combustibles) in cement plants has always been a challenge for any type of analysing probe. Up to now, it’s been nearly impossible to extract measuring gas for continuous analysing systems, because the probe becomes “cemented over and sealed” very quickly, resulting in extremely high maintenance costs and kiln production down time. Now ENOTEC has solved these special analysing problems in the cement industry with the new analysing system called CEMTEC®. Now Cement plants are able to significantly reduce their maintenance costs to a fraction of their previous costs. Mounted in a water-cooled outer jacket, the measuring probe is continuously turning +/- 90°. This keeps the gas inlet area free of cement and prevents the dust build up on the probe professional filter. Additionally, a highly effective automatic professional cleaning system with pressurised air ensures that the probe with its dust filtration and the gas channels remain completely clean and clear. The InSitu probe measures oxygen using a ZrO2 cell and the COe concentration with a Ga2O3 sensor. The system delivers 2 continuous measuring signals with a response time less than 1 second. In addition, it is also possible to extract flue gas for the extractive type flue gas analysis (SO2, NOx, etc.). |
|
Fast, non-intrusive measurements of gas concentrations and temperatures, performed inside of the process itself are the domain of the diode professional laser gas analytic. The gas analyzer LDS 6 which combines the compact and service friendly set-up, the easy operation and the network connectivity of Series 6 with the known unique performance of diode laser based in-situ gas analytics.
Fibre optics and IR diode laser technology, standard components of high quality and reliability in communications engineering, give an extremely robust analyzer concept almost free of maintenance which enables process relevant information even under very harsh environmental or process conditions. A build-in hands-off reference gas cell avoids the need for any test gases in the field. By the means of a simple analogue modem a professional remote control or diagnosis of the industrial analyzers is possible (almost) anywhere and anytime.
Today, the list of gases able to be measured with NIR manufacturers of diode lasers contains already gases like O2, NH3, HCl, HF, H2O, CO, CO2, H2S, CH4, ... and it is continuously growing with the state of the development in semiconductor laser technology. Additionally, high gas temperatures can be determined non-intrusively with an O2 measurement. |
|
"Zirkonia Oxygen Analyser BA 1000
Low energy consumption
Temperature independent
Linear output signals 4 - 20 mA
Error protected
High measurement precision
Independent of gas matrix
Long life
Variety of applications
No reference gas
No calibration gas" |
|
Our basic system ( WaSul TM -Basic-Ex ) can be used for quality control at gas transfer or sales points, where it can measure e.g. water vapor, hydrogen-sulfide, carbon-dioxide, ammonia, methane, ethane and particulate matter concentration on-line and fully automatically.
For process driver applications our WaSul TM -Mppm-Ex systems, with their exceptionally wide measurement range can be used for multi-point process monitoring:
• at a dehydration unit it can measure the water vapor content of both the unprocessed and the dried natural gas;
• at a glycol re-concentration (or regeneration) unit it can measure the water or BTEX content of both the wet and the dry glycol.
• at a sweetening unit it can measure the hydrogen-sulfide (H 2 S) concentration both of the sour and the sweetened natural gas.
In the above listed applications various WaSul TM systems already proved they excellent reliability and high stability throughout several years of trouble free operation. WaSul TM systems received the approval from the Hungarian Approval Service for Ex-proof Electrical Equipment to be operated at potentially explosive areas.
The installation and operational costs for these systems are practically negligible. |
|
ORBISPHERE 3620 Series
Gas analyser
Dual channel industrial analyzers designed to work with two Orbisphere patented detection. Available in wall-, professional rack- or panel-mounted versions for online measurement or portable version. Designed for optimum measurement and control in harsh environments. Performs equally well in low and in high concentrations, in liquid or in professional gas phase
3620 for PROFESSIONAL CO2 and N2 monitoring for beverage processing.
3621 for O2 and CO2, N2 or H2 monitoring for beverage processing or power generation
3622 for H2 and N2 monitoring for power stations
3623 for O2 and H2 monitoring for nuclear power plants
|
|
| Professional laser based photoacoustic instruments for continuous monitoring of pollutants in natural gas in biogas and in the atmosphere. Measurable components include: water-vapor, hydrogene-sulfide, ammonia, methane, various types of aerosols etc. |
|
| AMETEK Western Research’s UV-VIS photometric industrial analyzers are recognized worldwide offering excellent performance and reliability for continuous monitoring of pollutants emitted from refineries, chemical plants, power plants, and other industrial facilities. Western Research has the full system design and manufacturing capabilities needed to engineer a turn-key solution to meet your requirements. |
|
Designed for measuring simultaneously up to three gases with NDIR technology with correlation cells. Typical gases are CO, NO, CO2, CH4, SO2, etc. No regular service needed, it executes automatically zero autocal with ambient air. This professional analyzer is equipped with 4 analogical output (4-20 ma) and 2 serials (mod-Bus RTU/ASCI), double threshold contact alarm for every measurement, fault and service. A special version with a long optical path allows the measure of extremely low amounts.
4 optional analogical input 4-20 ma and 6 digital input make it the perfect controller for every analysis system (CEMS). European certification in progress.
Hart protocol available as option.
|
|
In order to permit the measurement and the continuous control of smokes generated by the combustion of natural gas, fuel oil, coal or garbage, Fuji Electric has developed a complete line of gas analysers allowing to adapt all industrial facilities to the standards and regulations limiting the disposals of pollutants in the atmosphere.
|
|
Model CEA-9001 Combustion gas analyzer & PEM-9002 Portable Emissions Monitor
The CEA-9001 is a digital, hand-held, flue industrial gas analyzer featuring state-of-the-art microprocessor technology.
Ideally suited for inspecting and servicing small and medium sized heater installations, it is used for safety-relevant technical inspections of CO emission concentrations in gas combustion plants.
The CEA-9001 offers storage of 100 complete blocks of measurement data which can be printed directly via an IR professional printer or processed through an appropriate PC program.
Optional upgrades are available for up to three measurement cells -- O2, CO, and NO -- which allows for CO measurement with H2 compensation, waste gas temperature, O2 / CO2 content, and combustion air temperature measurement.
The CEA-9001 is available with a light weight yet rugged carrying case. |
|
Binary Supplier of gas analyzers
The 20 Series Gas Analyzer with thermal conductivity detector (TCD) is designed for non-continuous sampling and quantitative analysis of binary process streams of technical gases and other gas mixing, professional cylinder identification, and atmospheric control applications.
The 50 Series Continuous Duty Gas Analyzer with thermal conductivity detector (TCD) is custom designed to your specific requirements. The analyzer contains a temperature regulated TCD which enables it to be used in continuous monitoring applications with minimum zero drift. Typical applications involve continuous monitoring of gas streams for low ppm impurity.
Both Industrial analyzers:
- Optimized, Self-Contained Gas Flow System
- Built-in Gas Selection Manifold
- Custom Designed to Your Application
- Choice of standard, corrosion resistant or all stainless steel system
- Class 1, Div 1, Group B, C, D Class 1, Div 2, Group B, C, D available systems
We specialize in manufacturing custom engineered analyzers, therefore, we ask you to give us your specific application parameters in order to quote the appropriate analyzer for your needs.
|
|
Gasmet In - Lab Series includes quantitative
multicomponent gas analysers for laboratory
research applications. The Gasmet Cr - Series
incorporates a Fourier Transform Infrared, Ftir spectrometer, a temperature controlled sample
cell, and signal processing electronics. Liquid
nitrogen cooled MCT detector has the highest
performance available.
The Gasmet Cr-2000 is designed for speed and
reliability. It is an ideal tool for example for motor
exhaust measurements, catalyst research
applications, pyrolysis research, or to measure any
compounds in wet corrosive gas mixtures. The
small volume of the sample cell provides short
response times. The gold-coated sample cell can
be heated up to 180ºC. Various sample cell path lenghts are available (from 1 cm to 100 meters). |
|
With one of the most comprehensive families of sensors and on-line industrial analyzers for pH, conductivity and dissolved oxygen, Yokogawa is recognized as a world leader in the field of analytical equipment.
|
|
LAND has a range of portable gas analysers for testing, checking and monitoring combustion processes for operating efficiency; and analyzing pollutant gas emissions for environmental compliance.
The range comprises lightweight, simple-to-use portable gas analysers with facilities aimed at a wide range of applications. Up to 9 gas measurement are available on a single analyser. There are a wide range of options available, including a suppliers of data acquisition system - plus the ability to self-configure the professional analyzer to exactly meet plant and process requirements.
|
|
Measuring parameters:
O2, CO / H2, (NO, SO2 and / or CO-high optional), waste gas temperature, ambient temperature, draft or balance pressure.
NOTE: NO2 measurements are not possible.
Computed values:
CO2, CO non-diluted, Lambda, pressure and temperature difference, degree of efficiency (Eta), waste gas losses (qA), NOx, dew point, and Eta combustion value
This lightweight design incorporates many features including:
Powerful storage battery; approximately 30 hours of operation with activated display illumination
Illuminated display showing four simultaneous measuring values in a selectable display combination
Optional upgrades for up to five measuring cells: O2, CO / H2, CO-high, NO, SO2
Integrated professional printer for plain paper - measuring data can be printed immediately |
|
708 Combustion Efficiency Professional analyzer
1. Combustion Efficiency Analyzer
• Measure 02 and CO
• Calculate CO2, efficiency, excess air and ratio.
• Will work with high efficiency industrial furnaces, hot professional water heaters, and other combustible gas appliances.
2. Co analyser
3. Differential Professional thermometer
709 Combustion Efficiency Analyzer w/ Differential Digital pressure gauge (0.001 inH20)
1. Combustion Efficiency Analyzer
• Measure 02 and CO
• Calculate CO2, efficiency, excess air and ratio.
• Will work with high efficiency furnaces, hot water
heaters, and other combustible gas appliances.
2. Differential Digital Manometer
3. CO Analyzer
4. Differential Thermometer
712 Flue gas analyser
1. Combustion Efficiency Analyzer
• Measure 02 and CO
• Calculate CO2, efficiency, excess air and ratio.
2. Combustible Industrial gas detector
3. CO Analyzer
• Measure 0-10,000 ppm CO
4. Differential Thermometer
5. Differential Digital Manometer
714
1. Combustion Efficiency Analyzer
• Measure 02, CO, and NO
• Calculate CO2, NOX, efficiency, excess and air ratio
2. NO & NOX Analyzer
3. CO Analyzer
4. Differential Thermometer
5. Differential Digital Manometer
|
|
|
