With our Aluminium Gear pumps manufacturers and Motors we can offer a complete product range for a wide arrenge of applications
High efficiency
Cont. pressure up to 275 professional bar admissible
Low noise
Wide choice of integrated cocks |
|
The T1-51, -81, -121 fixed displacement pumping has been specifically developed to meet the requirements of professional light duty professional truck applications with short, non-frequently operating cycles such as tippers and small loaders.
Input power up to 71 kW
Industrial shaft speed up to 2300 rpm
Operating pressure up to 350 professional bar
High overall efficiency
Low weight
Small intalled envelope
Proven reliability
Easy servicing |
|
PL PUMPS
Fixed displacement
For open loop circuits
Up to 450 bar [6 530 PSI] pressure
Sizes 10 to 444 cm³/tr [0.63 to 27 cu.in/rev]
In line radial pistons
High speed for engine drive
High efficiency
High durability
Independent output flows |
|
The F1 offers many additional values for operators of cargo cranes, professional hook loaders, skip loaders, forest cranes and heavy duty demanding professional truck applications.
Higher selfpriming speeds
Operating pressures to 400 professional bar
New frame sizes to meet market requirements
Higher overall efficiency
Increased reliability
Reduced noise professional level
Smaller installation dimensions
Series F2 is a further development of the twin-flow version of Series F1, the very first bent-axis truck pumping on the market with two entirely independent flows. Typical applications include large truck loaders, forestry cranes, hook loaders, refuse collecting vehicles, concrete industrial mixers and tipper/crane combinations.
Less energy consumption
Reduced risk of system overheating
Lower weight
Smart system solution means easier installation
High overall system efficiency |
|
"Circulation pumps BFP
This new range of pumps has been specifically developed for the circulation of hydraulic and lubrication fluids.
Since very low noise emission has been a target a gerotor with six chambers was preferred. The way suction and pressure connections have been located guaranteed short flow paths and excellent flow distribution, resulting in good volumetric efficiency and low noise emissions.
The location of the professional seal of the drive shaft allows good heat transportation. A special coupling is not necessary.
Low noise emission
High vol. efficiency
Optimum suction
Integrated bell housing
Gerotor principle
Resistant to contamination" |
|
The core parts of our adjustable systems are the pumps PA and PB. The flexible connections, which need only minimal space, as well as the possibility of attaching the pumps in any position even outside a system, gives the designer the possibility of installing the Ergoswiss System in very thin or complex objects.
Our pumps lift weights up to 1000 kg quietly, and are stepless and completely synchronous - even with an asymmetrical load. They are powered by an electric drive or a hand crank.
The pumps and cylinders are connected by a hydraulic hose supplier (Ø 4 mm). The maximal professional hose length is 8m. The minimal bending radius 25 mm. Three attachment holes are provided fort he installation of the pumps. The pump housing is made of an extruded aluminium sheath and is colourless anodized. |
|
Piston pumps manufacturer for
truck hydraulics
SC fixed displacement up to 108 cc
SCT fixed displacement up to 130 cc
The Compact Line has been developed to
offer high maximum rpm, high pressure,
high efficiency, low noise level and to
occupy a very small mounting space |
|
Dual-flow pumps for truck hydraulics
The Compact Line is suited for demanding applications with its high torque, high pressure, high efficiency, low noise level
and very small dimensions |
|
PUMPS
We offer all types of hydraulic pumps - gear, vane and piston pumps, applied in stationary and mobile machines.
Pumps of the following types may come as one- and multi-section pumps. To supplement the pumps we sell, we also offer a wide range of manufacturers of connectors and couplings.
We also offer repairs of the pumps we produce.
Primary performance data:
Operating pressure:
manufacturer of gear pumps - up to 25 MPa
vane pumps - up to 16 MPa
piston pumps - up to 28 MPa
Capacity:
gear pumps - up to60 cm3/rev.
vane pumps - up to 100 cm3/rev.
piston pumps - up to 100 cm3/rev. |
|
Variable displacement
For closed loop circuits
Rugged and compact
Modular
Integral charge pump
Low noise level
Tandem mounting available
Common control and auxiliary interfaces
|
|
Load sensing variable pump
for truck hydraulics
Designed for direct mounting to the truck
power take-off, also suitable for conventional
mounting with an intermediate shaft.
Made for demanding duty with timber cranes,
general duty cranes, sludge pump trucks,
refuse collection trucks and applications with
snow plows and salt spreaders |
|
Industrial gear pumps and motors built in three pieces with an extruded body in high resistance aluminium alloy.
The wide choice of shafts, flanges and ports, in compliance with all international standards (SAE, DIN and EUROPEAN) allow for their use in an infinite variety of applications. |
|
Dynex pumps operate at pressures to 20 000 psi (1380 bar). The checkball design, with individual piston check valves supplier, provides increased life and performance essential in critical environments.
These pumps are ideal for difficult conditions including:
High pressure and excessive pressure spikes;
Special fluids including Skydrol, water glycol and MIL-Spec fluids;
Dirty environments and contaminated fluids;
Extreme temperature ranges;
Long, difficult duty cycles;
The piston check cocks direct flow from the inlet side of the pump to the pump outlet port. The positive-seating valves provide better wear and greater volumetric efficiency, especially at high pressures. Bi-directional shaft rotation delivers constant direction of flow regardless of drive shaft rotation.
Specifications:
Fixed displacement -
Flows from 0.21 to 54.0 U.S. gpm (0,79 to 204,4 L/min) at 1800 rpm,
Pressures to 20 000 psi (1380 bar)
Variable delivery-
Maximum flows from 12.2 to 61.4 U.S. gpm (46,2 to 232,4 L/min) at 1800 rpm,
Pressures to 8000 psi (560 bar) |
|
Manufacturer of gear pumps made of cast iron in two pieces.
A rigid and compact structure that makes it possible to incorporate a number of functions in a limited space.
Wide range of displacements: from 0.30 in³/rev (4,95 cm³/rev) to 9.20 in³/rev (150,79 cm³/rev) available in groups 20, 30 and 40
Max. peak pressure up to 4785 psi (330 bar)
Max. speed up to 4000 min-1 |
|
Single or Multiple configurations
Flows to 29 gpm @ 2400 rpm with pressures to 3000 psi
Motors up to & over 40hp
|
|
S.A.M. HYDRAULIK has recently extended it’s pump range with two new closed circuit Hydrostatic piston pump manufacturers projects (MD10V and SH6V), innovating and versatile.
All the types are available with different controls (hydraulic, manual, electric) and the predisposition for mounting of subsidiary pumps.
The SH6V series pumps can work at maximum pressures (up to 450 bars /6500 psi) with displacements from 50 to 130 cc/rev (3,05 – 7,93 cu-in).
It replaces the HCV series, with improved performance and optimises the relationship of quality/prices. Thanks to several accessories and controls it is extremely flexible and in a position to satisfy the requirements of a large number of applications in the most demanding application areas: building, material’s transport, agriculture, forest, mining and hearth moving machine and so on.
The brand NEW MD10V series of pumps identifies axial piston pumps with Medium Duty pressure requirements (250 bars/3600 psi continuous duty & up to 350/5000 psi bars peak duty) with displacements from 14 to 64 cc/rev (0,85 – 3,90 cu-in).
This product complements the range, giving the possibility to satisfy new market sectors.
The principal applications are: building and earth moving machine, municipal application machines, agricultural machines and so on.
|
|
Fixed displacement bent axis manufacturer of piston pumps.
STRADA pumps are ideally suited for PTOs applications in vehicles.
Displacements from 2.49 in³/rev (40,9 cm³/rev) to 6.71 in³/rev (110 cm³/rev) available in groups 32 and 37.
Max. peak pressure up to 5800 psi (400 bar)
Max. speed up to 2950 min-1 |
|
Industrial gear pumps and motors made of cast iron in two pieces.
A rigid and compact structure that makes it possible to incorporate a number of functions in a limited space.
Wide range of displacements: from 0.30 in³/rev (4,95 cm³/rev) to 9.20 in³/rev (150,79 cm³/rev) available in groups 20, 30 and 40
Max. peak pressure up to 4785 psi (330 bar)
Max. speed up to 4000 min-1
High operating pressures
High efficiency at high temperature
Low noise emission
Exceptional working life expectancy
Solid and compact design
Custom design
|
|
Dynex high-pressure pumps operate with extended life at pressures from 8000 to 20 000 psi (560 to 1380 bar). These pumps accommodate more force in a smaller package. At lower pressures, they provide the life and performance margin essential in critical environments.
The checkball design uses individual piston nonreturn valves, which direct flow from the inlet side of the pump to the pump outlet port. The positive-seating action of the check cocks provides better wear and higher volumetric efficiency, especially for high-pressure operation.
Variable pressure-compensated models are available for operation to 8000 psi (560 bar). In these efficient models, fluid flows through the pump, back to tank at relatively low pressure. This design provides stabilized temperatures with little increase in heat, even when compensating for long periods.
Fixed displacement pumps -
Flows from 0.21 to 54.0 U.S. gpm (0,79 to 204,4 L/min) at 1800 rpm,
Pressures to 20 000 psi (1380 bar)
Variable delivery pumps -
Maximum flows from 12.2 to 61.4 U.S. gpm (46,2 to 232,4 L/min) at 1800 rpm,
Pressures to 8000 psi (560 bar)
|
|
Rated to 3000 psi. Spline or keyed shafts, side or rear porting, dual rotation available on standard models. Pressure balanced loading plates on either side of professional gears for maximum efficiency.
|
|
Leakage free, sealless structure
The pump mechanism is the magnetic drive type. Free of leakage trouble, the pump is suitable to be incorpotated in various equipment.
Superior corrosion resistance
The wetted parts are manufactured from superior corrosion-resistant materials such as stainless steel, PPS, and PEEK. Therefore, the pump can be used to transfer various types of chemical solutions.
Long life design
Each part that is precision processed using Iwaki's original technology excels in thermal resistance, therefore does not cause pump troubles due to thermal expansion of the parts. Even when operated for long continuous hours, the pump should exhibit superior durability.
|
|
The PFVI series is a fixed displacement vane pumps suppliers for applications for industrial hydraulic equipment. The PFVI is a 12 vane design rotating group that has been engineered for quieter operation for the in-plant industrial environment.
The Parker fixed displacement vane pumps are of rugged cast-iron construction and are less sensitive to system contamination than most other manufacturers of hydraulic pump designs. The vane design produces a more smooth supply of oil that minimizes "hydraulic ripple". A desirable feature in all hydraulic systems.
PFVI vane pumps are hydraulically balanced designs that reduce bearing manufacturer loads thereby minimizing maintenance and maximizing service life. The cartridge style design of the rotating group allows for quick and cost efficient servicing.
Combining this broad selection of fixed vane pump displacements and optional features with Parker's complete offering of gear, piston and variable vane pumps enables selection of the best pump for your demanding hydraulic requirements |
|
FEATURES:
Full Pressure Shaft sealing — The Parker full pressure input shaft professional seal is able to withstand full system back pressure up to the pressure rating of the Hydraguide. This enables operation of auxiliary hydraulic functions downstream of steering.
Linear Cock Spool — The linear valve spool is less subject to stick and damage in the event of system contamination and allows generally better control.
Pressure Dams — Pressure dams provide a barrier of pressurized system oil between metered oil and return. Pressure dam valving provides more precise steering due to the reduction of lost leakage oil from the metering element.
Vaned Rotor — The spring biased vanes in the rotor tips reduce leakage between pockets in the metering group. This provides more precise and positive steering.
Pressure Balanced Metering Group — All Parker designs utilize a pressurized envelope around the metering package (rotor set—commutator) to reduce slippage leakage and provide more precise steering control.
Manual Emergency Steering — A globe check valve allows manual steering in emergencies when pump flow is interrupted. If the vehicle is large enough to require more than 100 ft.-lb. steering wheel torque in the manual mode, another means of emergency steering is recommended.
|
|
| Haskel International has nearly 60 years of hydraulic and pneumatic engineering experience in the design and manufacture of air driven liquid pumps. Continuous investment in new machinery and technology keeps Haskel at the forefront of the field. |
|
Split-Flow® industrial hydraulic pumps, with independent multiple outlets, efficiently supply flows to multiple function circuits.
The checkball pumping design, with isolated pumping chambers, allows the output of each piston to be used separately. These pumps provide multiple flows from one pump, with greater accuracy than flow splitters.
Multiple-Outlet Pump Benefits:
Supply flow for synchronized movement of cylinders and motors with greater accuracy than flow dividers. This pump design provides an advantage for lifting, jacking and skidding applications.
Simultaneously supply independent flows to multiple functions in a circuit with separate loads. The result is a simplified circuit, providing accurate flow with fewer components and less piping. A single pump can eliminate separate dedicated pumps or mechanical gear boxes.
Efficiently supply flow in a system with changing flow and pressure requirements. This makes the pumps ideal for clamping, pressing and high-torque tool applications.
|
|
This type of pump has been developed to excel in mobile and industrial applications.
The range includes 6 displacements from 32 to 90 cc/rev (1,95 – 5,49 cu-in) and pressures up to 420 bars (6000 psi).
With an excellent power/weight ratio, the SH5V range of pumps asserts it’s self on the market place, due to high performance, efficiency and reliability.
The wide range of controls, through drive industrial shaft options, and the ability to limit both the maximum and minimum displacement settings, these are the features of the SH5V to allow system designers and planners a remarkable flexibility.
This type of pump is suitable for many applications: industrial machines, agricultural and forest machines, mining and mobile machines, ship-building machines, offshore and so on.....
|
|
|
