The Kneader Extruder combines the efficiency of a double arm - sigma blade mixer with the convenience of an extrusion screw for the mixing and discharging of heavy viscous materials.
The Kneader Extruder includes a set of counter-rotating kneading blades and a discharge screw. The blades are mounted on a horizontal axis in a u-shaped trough. Below the blades in a seperate cavity is the discharge screw. During the mixing cycle the blades rotate toward each other while the mixing screw rotates in a reverse direction, constantly feeding new materials into the mixing blades. After the mixing/kneading cycle is complete, the screw is reversed and it transports the mixed materials from the mix zone out through a discharge die and on to further processing or packaging.
The Kneader Extruder has several advantages over conventional non-screw discharge kneaders:
1. Mixes in approx. 15% less time
2. Eliminates the manual task of scraping out sticky/tacky materials.
3.Eliminates operator exposure to materials of elevated temperatures or of a toxic nature, thereby improving plant safety.
Many sizes and designs are availble to meet the most stringent process needs. Kneader Extruders are manufactured in many sizes from 1 through 1000 gallons capacity.
|
|
|
|
|
|
The Kneader Extruder combines the efficiency of a double arm - sigma blade mixer with the convenience of an extrusion screw for the mixing and discharging of heavy viscous materials.
The Kneader Extruder includes a set of counter-rotating kneading blades and a discharge screw. The blades are mounted on a horizontal axis in a u-shaped trough. Below the blades in a seperate cavity is the discharge screw. During the mixing cycle the blades rotate toward each other while the mixing screw rotates in a reverse direction, constantly feeding new materials into the mixing blades. After the mixing/kneading cycle is complete, the screw is reversed and it transports the mixed materials from the mix zone out through a discharge die and on to further processing or packaging.
The Kneader Extruder has several advantages over conventional non-screw discharge kneaders:
1. Mixes in approx. 15% less time
2. Eliminates the manual task of scraping out sticky/tacky materials.
3.Eliminates operator exposure to materials of elevated temperatures or of a toxic nature, thereby improving plant safety.
Many sizes and designs are availble to meet the most stringent process needs. Kneader Extruders are manufactured in many sizes from 1 through 1000 gallons capacity.
|
|
Different processing lengths and screw geometries guarantee a wide area of application. Venting zones, interchangeable grooved bushes, stroke adjustment systems and many more features allow for an extremely versatile application in setting up extrusion lines.
As standard, all extruders are equipped with microprocessor control contained in a swing-out unit above the extruder.
|
|
The particularly designed kneading mechanism ensures the building up of shear stress, which is necessary for the kneading process.
Short process periods are achieved due to the high specific power
Largely dimensioned feeding and discharge systems are ensuring a trouble-free production.
The system allows a high degree of automation
Applications:
- Dispersing of solid materials in liquid matrix
- Production of multiphase mixtures in melts
- Flushing of pigment filter press cake
- Pigment modifications
|
|
|
|
|
|
The Kneader Extruder combines the efficiency of a double arm - sigma blade mixer with the convenience of an extrusion screw for the mixing and discharging of heavy viscous materials.
The Kneader Extruder includes a set of counter-rotating kneading blades and a discharge screw. The blades are mounted on a horizontal axis in a u-shaped trough. Below the blades in a seperate cavity is the discharge screw. During the mixing cycle the blades rotate toward each other while the mixing screw rotates in a reverse direction, constantly feeding new materials into the mixing blades. After the mixing/kneading cycle is complete, the screw is reversed and it transports the mixed materials from the mix zone out through a discharge die and on to further processing or packaging.
The Kneader Extruder has several advantages over conventional non-screw discharge kneaders:
1. Mixes in approx. 15% less time
2. Eliminates the manual task of scraping out sticky/tacky materials.
3.Eliminates operator exposure to materials of elevated temperatures or of a toxic nature, thereby improving plant safety.
Many sizes and designs are availble to meet the most stringent process needs. Kneader Extruders are manufactured in many sizes from 1 through 1000 gallons capacity.
|
|
Different processing lengths and screw geometries guarantee a wide area of application. Venting zones, interchangeable grooved bushes, stroke adjustment systems and many more features allow for an extremely versatile application in setting up extrusion lines.
As standard, all extruders are equipped with microprocessor control contained in a swing-out unit above the extruder.
|
|
