The APV DW Rotary Lobe Pump
The most versatile rotary pump on the market
The APV DW range reflects latest technology in the development of rotary positive displacement pumps. No equivalent pump on the market offers such a wide range of features incorporated in a single pump.
Ultra Hygienic
* Meets the strict European hygienic standards (EHEDG)
* 3A Certified
* Designed for both CIP (Cleaning in place) and SIP (Sterilise in place)
* FDA approved elastomers
* AISI 316L product contact parts
* Completely self drainable when vertically ported
Exceptional Performance
* High volumetric efficiency
* Very low noise and vibration levels
* Low NPSH requirement
* Gentle product handling
* Patented rotor design option means pulse free operation
Easy Maintenance
* Minimum downtime with easy access front loaded mechanical seals.
Extensive Range
* Over 30 models, with capacities of 0 to 30 bar and 3 to 1016 litres/100 revs
* Wide choice of shaft seal type and materials
Flexible Design
* Available with a wide choice of additional options such as Thermal Jackets, Rectangular Inlets, Integral Pressure Relief Valve, Non-galling alloy rotors and much more
The DW pump with its flexible design and many variants is the proven solution for hygienic applications in industries such as Dairy, Brewery, Food, Beverage, Pharmaceutical, Personal Care, Chemical and many more.
|
|
The pumps are based on the geometry and properties of the cycloid. In fact, they are lobe pumps (or internal gear pumps). All of the main components are made of sintered materials. In the development of these two types of technology, we have given an emphasis to high performance in terms of capacity and pressure in proportion to the pump size (owing to the reduction in unused volume), as well as to duration and lower noise level (owing to the porosity offered by the powder metallurgy).
Self-lubrication is another important property intrinsic to every model of this product, and it is a guarantee against buckling.
|
|
|
|
|
|
The series WA/WAU Roots vacuum pumps are provided with directly flange-mounted air-cooled standard three-phase motors. The oiled radial sealing rings of the RUVAC WA/WAU for sealing the shaft against the atmosphere are made of FPM (fluor caoutchouc).
The WS/WSU series pumps are driven by air or water-cooled canned motors.
Roots vacuum pumps of the series WAU/WSU are provided with an additional integrated pressure equalization line and a differential pressure valve.
Pumps from these series are supplied with a vertical pumping action as standard.
Advantages to the User
Two air-cooled series, each with four models
Reliable and trouble-free
Sealing rings with their housing can be readily replaced
Shaft seals and elastomer seals made of FPM/Viton
Air-cooled standard motors in accordance with IEC dimensions eg. NEMA dimensions
Easy to exchange with custom motors
Integrated pressure equalization line for protection against overloading at high pressures
Pumping direction may be changed as required
ATEX versions compliant to 94/9/EC possible
Typical Applications
For oil-free compression of gases and vapors in combination with a backing pump
Short cycle pumping processes also in the presence of large quantities of gas and vapor
Supplied Equipment
RUVAC WA/WAU are supplied as standard for a vertical pumping action, horizontal pumping action upon request
Mineral oil N 62 is used as standard
Gasket in the intake flange with dirt sieve
The required oil filling is included in separate bottles
|
|
|
Rotor pump is also named rotary lobe epump, three-lobe pump, sole pump,etc. When the 2 simultaneous reverse rotating rotors(with 2-4 gears)revolve, it produces suction force at the inlet(vacuum),which intakes the material delivered.The 2 rotors divide the rotor housing into many smaller parts and revo-Ive in the sequence of a→b→c→d.When it revolves to position a,only housing I is filled with medium;when it revolves to position b,housing B encloses part of the medium,when it goes to position c,housing A encloses medium,and finally it goes to position d,then housing A,B and II are interlinked and the medium is transported to the outlet.As this process is repeated,medium(material)is transpor-ted continuously.
|
|
|
Pedro Gil, S.L. is a manufacturer company for pressure and vacuum groups, root pumps and vacuum systems.
|
|
|
With five series, including 30 displacements, Viking Pump offers the broadest line of industrial lobe pumps in the world. Providing low shear, high efficiency and pressures to 27 bar, these stainless steel pumps offer a broad variety of rotor forms and shaft sealing options. They can handle liquids from 1 to 440,000 cSt. They are designed to handle steam or solvent-cleaning between batches.
|
|
|
|
|
|
The SteriLobe® series offers the ultimate in modular, flexible design to ensure that the appropriate feature set is provided for every application. The pump can be configured to handle nearly every unique pumping problem.
Product Features:
Easy accessibility to seal area enhances cleaning and CIP capabilities.
Generous seal access facilitates simple front loading and removal of seal, even for flushed and double options without stripping the pump.
Cover joint profile improves hygienic characteristics and self-draining capabilities.
Rugged gearbox construction enables the carrying of radial loads.
Stainless gear cover and electro-less nickel plated bearing housing provide clean and corrosion resistant external finish.
Mounting Options: The SteriLobe® range has cast stainless steel bolt-on feet which offer stable and robust support to the pump with the advantage of corrosion resistance. This enables the pumps to be mounted with shafts in the upper or lower position and for ports to be aligned horizontally or vertically.
Rotor Options: 316 SS Bi-Wing or Multi-Lobe rotor options offer clearances to 300°F (150°C), making them suitable for all CIP and SIP conditions. Closer tolerance rotors are also available for low viscosity / higher efficiency applications, and Multi-Lobe rotors are also available in non-galling Alloy 808.
|
|
|
|
|
|
|
The RTP20 (1.0 liter/rev) and RTP30 series (1.28 liter/rev) design is a proven high-speed rotary transport pump with exceptional performance, advanced durability, application flexibility, and ease of installation to help users achieve enhanced productivity for a lower total cost of ownership. This series’ tri-lobe design, customizable per customer specifications, is compact and light-weight and features removable feet and multiple mountings for easy vertical or horizontal adaptation. Both the RTP20 and RTP30 series efficiently fill rotor voids, allowing for faster and quieter operation on viscous liquids. In addition, with a longer sealing land at rotor tips, the series provides enhanced efficiency when working with lower viscosity products. The RTP20 offers a capacity to 264 GPM (1,000 L/M / 60 M³/Hr.), pressure to 145 PSI (10 Bar), viscosity to 250,000 SSU (55,000 cSt), and operates in temperatures to +230°F (+110°C). The RTP30 offers a capacity to 340 GPM (1,283 L/M / 77 M³/Hr.), pressure to 175 PSI (12 Bar), viscosity to 250,000 SSU (55,000 cSt), and operates in temperatures to +300°F (+150°C). These pumps are available with ACME threaded or tri-clamp ports as well as many other port connection types.
|
|
|
The BR series offers self-priming pumps, called rotary lobes pumps, used for liquids and semi-solids filling, decanting, irrigation or emptying operations. Differently from all other pumps, the liquid pass through the pump. The BR series is composed of 7 models (BR 40, BR 80, BR 120, BR 160, BR 200, BR 240 and BR 280) available in versions /P, /D, /H with capacities from 1425 lt/min. to 4950 lt/min.
|
|
|
The PK pump is designed as a modular construction. It consists of a synchronous gear-head driving the two rotary lobes contained in a pump body having suction and pressure ports and connections. The robust bearings are located in the gear-head where they are protected from the pumped media by a mechanical sealing.Conversely, special seals contain the lubricating oil within the gear-head.
|
|
Standard Features:
- Compact Footprint (17" x 33" of floorspace)
- M-code selectable high and low pressure
- Dual Filter version minimizes service downtime
- Pump Water Based Coolants or Cutting Oils
- Adjustable Discharge Pressure to 1000 psi (70 Bar)
- High Capacity Bag Filter, 10-mic Std.
- Integrated Pressure Switch for automatic filter monitoring
- Inlet/Outlet Gauges to monitor Filter Condition
- Uses Low-Cost Bags
- Coolant and thermal alarms
- 208 - 230VAC Standard, 440 - 480VAC Available
- 12 foot modular cables
- 20 foot high pressure hose
Optional Features:
- Abrasive duty construction for grinders
- Machine prep kit for quick change portability
- Integrated coolant transfer pump
- OEM Interface Kits
- NF Non-filtered units
|
|
The Power Pump Portfolio.
Roots pumps for Every Low and Medium Vacuum Applications.
Our Roots pumps offer pumping speeds ranging from 250 to 25,000 m3/h. They can be safely employed for low and medium vacuum applications in the coating or semiconductor industry, in research & development, metallurgy or in chemistry and process technology.
The gear and bearing chambers in our Roots pumps are completely separate from the gas pumping chamber. Because the rotors operate without making contact, dry, hydrocarbon-free operation is assured.
A further advantage: Thanks to air cooling, operating costs are significantly lower than with water cooling. The design principle of our proven Roots pumps has also been expanded to include magnetic couplings. These hermetically sealed pumps make oil leaks a thing of the past. We have also developed special pumps for processes that take place in explosive environments or for evacuating explosive gases.
|
|
THE ROTARY LOBE FEED PUMP (SKK)
- Designs in grey cast iron, steel, zinc-free bronze, stainless steel and in Hastelloy
- Pressures up to 20 bar
- mechanical sealing independent of sense of rotation
- easy to assemble and to disassemble
- low maintenance cost
- very high efficiency
- robust construction
Typeical fields of application
- Bitumen industry
- Dyes and lacquer industry
- Petrochemistry
- Food-processing industry
- Chemical and pharmaceutical industry
|
|
The Fristam FL design ensures efficient transfer and effective product protection at high volumetric flow rates.
Fristam FL rotary lobe pumps feature a modern and innovative displacement body design. The shape of the Fristam FL lobes prevents the product from being squeezed, and minimises the risk of damage.
|
|
NETZSCH TORNADO® Rotary Lobe Pumps are used in the petroleum industry for the continuous, pressure-stable, gentle and low-pulsation conveyance of crude oil. The TORNADO® is particularly well suited for running high capacities at medium pressures.
Features of the NETZSCH TORNADO®:
- large ball passage
- self-priming
- intermittent dry run capabilities
- low-pulsation conveyance
- high suction capability
The NETZSCH TORNADO® offers you:
- space-saving design
- low life cycle costs
- high efficiencies
Advantages of the NETZSCH TORNADO®:
- can be employed at high pressures and capacities
- can be operated with a great variety of substances
- proportional capacity adjustment
- various lobe geometries and materials, tailored to the given application
easy serviceability
|
|
|
The volumetric lobe pumps offer to a effective increment nell´efficienza of the transfer of the liquids with lowland, average and high speed.
|
|
|
The Rotary lobe pumps series from Verder Wrightflow is ideally suited for the demands of the food and beverage industry, for pharmaceutical applications and demanding applications with strict hygienic requirements. Max. flow is 230 m3/h, max pressure 15 bar.
|
|
Universal cam and lobe pump is suitable to tenderly transfer high-viscosity matter or the matter containing particles. It is suitable for hygienic and aseptic place. Tenderly handing matter, slow rotational speed(200~600rpm), adjustable transportation speed, especially suitable for the matter that are susceptible to foaming or may be damaged during high-speed transportation. It is also used as a metering pump. It is suitable for on-the-top CIP cleaning and steam sterilization. Hygienic handling conforms to GMP standard.
Application
Medicines: Pill siziness, syrup, medicine thick fluid, milk shape liquid, proteide
Cosmetics: dyes, alcohol, essential oil
Dairy: whey, cream, milk, sugar liquid
Beverages: alcohol, spirits, beer, wort, ferment powder, fruit juice, beverages with particles
Other: sweet industry, baking industry and chemical industry etc.
|
|
| ... products without technical information |
| |
|
|
|
|
The series WA/WAU Roots vacuum pumps are provided with directly flange-mounted air-cooled standard three-phase motors. The oiled radial sealing rings of the RUVAC WA/WAU for sealing the shaft against the atmosphere are made of FPM (fluor caoutchouc).
The WS/WSU series pumps are driven by air or water-cooled canned motors.
Roots vacuum pumps of the series WAU/WSU are provided with an additional integrated pressure equalization line and a differential pressure valve.
Pumps from these series are supplied with a vertical pumping action as standard.
Advantages to the User
Two air-cooled series, each with four models
Reliable and trouble-free
Sealing rings with their housing can be readily replaced
Shaft seals and elastomer seals made of FPM/Viton
Air-cooled standard motors in accordance with IEC dimensions eg. NEMA dimensions
Easy to exchange with custom motors
Integrated pressure equalization line for protection against overloading at high pressures
Pumping direction may be changed as required
ATEX versions compliant to 94/9/EC possible
Typical Applications
For oil-free compression of gases and vapors in combination with a backing pump
Short cycle pumping processes also in the presence of large quantities of gas and vapor
Supplied Equipment
RUVAC WA/WAU are supplied as standard for a vertical pumping action, horizontal pumping action upon request
Mineral oil N 62 is used as standard
Gasket in the intake flange with dirt sieve
The required oil filling is included in separate bottles
|
|
|
Pedro Gil, S.L. is a manufacturer company for pressure and vacuum groups, root pumps and vacuum systems.
|
|
The Power Pump Portfolio.
Roots pumps for Every Low and Medium Vacuum Applications.
Our Roots pumps offer pumping speeds ranging from 250 to 25,000 m3/h. They can be safely employed for low and medium vacuum applications in the coating or semiconductor industry, in research & development, metallurgy or in chemistry and process technology.
The gear and bearing chambers in our Roots pumps are completely separate from the gas pumping chamber. Because the rotors operate without making contact, dry, hydrocarbon-free operation is assured.
A further advantage: Thanks to air cooling, operating costs are significantly lower than with water cooling. The design principle of our proven Roots pumps has also been expanded to include magnetic couplings. These hermetically sealed pumps make oil leaks a thing of the past. We have also developed special pumps for processes that take place in explosive environments or for evacuating explosive gases.
|
|
Wright Flow Technologies proudly introduces its latest innovation in Positive Displacement Pumps for the Sanitary and Industrial Markets, the new RevolutionTM the first true CIP (Clean in Place) Hybrid Circumferential Piston & Lobe Pump.
The RevolutionTM merges the benefits of Lobe & Circumferential Piston technologies into one platform. This new platform delivers:
* Increased product yield
* Increased lifetime of components
* Reduced maintenance costs
* Outstanding CIP cleanability and higher standards of hygiene.
|
|
|
|
