Faster Production - spindles operating at constant speeds from 25,000rpm to 90,000rpm up to 1.4HP, maintaining constant high speed under variable load with no gears, vanes, or brushes.
Over 40 spindles - easily mounted, maintenance free, requiring no lubrication, provide a finer finish and faster feed rates.
Patented low vibration, super quiet, oil-free, direct drive spindles for faster production and greater durability. Integrated CAT, BT, HSK, and DIN toolholders available for increased accuracy.
|
|
Motor spindle Type 4064 DC
Features:
Clamping-Ø: 60 mm
Speed range: 2,000 - 50,000 rpm
Max. power: 3,600 W
Torque: 72 Ncm
Bearing system: 3 x ceramic, lifetime lubrication
Tool change: pneumatically
Clamping range: 2.35 - 8.0 mm (1/8" + 1/4")
Cooling system: via clamping bracket
Sealing: with sealing air
|
|
HF-Motor Spindle Type 4041 ESD-Router
Features:
Clamping-Ø: 45 mm
Speed range: 5,000 - 50,000 rpm
Max. power: 500 W
Torque: max. 27 Ncm
Bearing system: 2 x ceramic, 1 x steel, lifetime lubrication
Tool change: pneumatically / automatically
Clamping range: 1.0 - 6.0 mm (1/8" + 1/4")
Cooling system: via clamping bracket
Sealing: with sealing air
|
|
- The machining spindles type BEX15 are high-precision turning spindles designed for speeds up to 23500 RPM. with frenquency) converter up to 90 Hz.
- Standard spindle and toolholder options are ER 25. ISO 30. HSK 50 (Includes an integrated 4-polnt clamping set form C). Weldon. and ABS 50.
- An adapter flange is designed for the installation of multiple-spindle heads and angle heads.
- Interchangeable push-on pulleys: see table.
|
|
High-frequency spindles with automatic tool change
- for high-speed milling work on woodworking and plastic processing machines
- maintenance-free grease lubrication
- pneumatic tool-release unit
- reliable shaft sealing with proctecting air flow
|
|
Type Series RHF
- with High Speed Spindle Bearings
- with ceramic balls (Hybrid Bearings)
State-of-the-art Precision:
- Radial tolerance <= 2 µm
- Face runout <= 1 µm
- Balance Class (standard) G 1,6
- acc. DIN ISO 1940
- Sealing (standard)
- slinger disk with integrated
- Labyrinth Seal; (optional) Air Purge
- Lubrication (Standard)
- Lifetime, using special grease
- (Optional) Oil - air mist lubrication
- per agreement
- Increased rigidity, primarily from
- the higher number of balls inside the
-High Speed Spindle Bearings on request.
|
|
Fixing the unit per flansh
stable construction with hardened and ground spindle
high precision
speed range up t0 15.000 rpm
power up t0 50 kW
labyrinth seal with stop-air connection
variable belt box position
variable drive-transmission ratio
automatical tool change possible by pneumatic or hydraulic operation
internal coolant transport or minimum lubrication possible
|
|
IMT CLASSIC 33
Compact high precision series
Performance range: 80 – 300 Watt
Speed range: 5.000 – 60.000 rpm
Tool clamping system: Manual
Common applications:
Light milling and engraving, polishing, grinding, cut off
and drilling.
|
|
|
Automatic, interchangeable motor spindle for retrofitting to all CNC machining centres. Highest feeds, best surfaces and ideal for 3-D milling of hardened steel or aluminium. RPM from 11.000 to 60.000. Now you can use your small tools with the correct cutting speeds.
|
|
A major enhancement to our range of units, mutiple-spindle heads and angular heads are available to increase production cycle efficiency and reduce machining costs. Su-matic products, in both standard and special versions are well suited to fit our standard MAX units for an effective production solution, or can add efficiency to your CNC machining center. Profit from your investment in record time with the Production expert.
|
|
OUTPUT ER8 to ER32 (More options, call for details)
RATIO Call for details
TAPER CAT, BT, HSK, Capto, NMTB, etc...
TORQUE 10 Nm to 50 Nm
Reduce overall machining time for many applications!
BENZ multi spindle heads are the only possibility to increase production volume and lower the price per unit produced at the same time.
BENZ Multi Spindle Heads are modular in design, which makes it possible to reduce outer dimensions and weight to a minimum. This means, even machines with limited room and weight capacity in the tool changer, can be equipped with multi spindle heads. A high degree of component standardization enables us to build many different spindle configurations within a short time frame.
|
|
