The static rollers play a vital part in our complete product mix. Many countries specify pneumatic tyred rollers to seal compaction surfaces, especially on runways. We offer several pneumatic tyred rollers with varying numbers of wheels and ballast possibilities to meet all requirements. The CS142 is a modern, articulated static three-drum roller with the same static linear load and drum diameter on all drums. The machine is suitable for medium-size and large-size applications. It is ideal for use in areas where the ground should not be vibrated, such as in areas close to old buildings and on bridges.
|
|
The new generation of Ammann pneumatic tyred rollers has been developed on the basis of the latest findings about the compaction of bituminous asphalt layers and natural soils. The modern roller design provides 1 x 1 m visibility in front of the roller and behind it.
A wide range of additional weights can be implemented to optimise the ballasting of the 4 + 4 smooth tyres. A central tyre inflation system ensures correct tyre pressure during operation.
|
|
Reliable operation with simplified maintenance
powerful vibration forces for maximum compaction
key components from world class suppliers
superior shock absorption for smoother operation
|
|
YZ16-7 VIBRATING ROLLER
Main specifications:
* YZ16-7 operating weight: 16000kg
* rated power: 128kW Chinese Engine
* dynamic line force: 1380 N/cm
YL27-3 PNEUMATIC TIRE ROLLER
Main specifications:
* Max operating weight:27000kg
* Min operating weight:15500kg
* rated power: 132kW Chinese Engine
|
|
|
|
|
|
The internationally unique double-wheel radiant hydraulic drive wheel is adopted to make transmission system simple and reliable, and prolong its longevity;
Travel and steering system are hydraulic driven, and stepless speed change;
9 wide-base tyres have an overlapping of 68mm, with good compactness and evenness;
Full hydraulic rear wheel drive avoids impacts in startup and parking, favorable for compactness quality of road surface;
Tyres with air concentratedly filled and pressure adjustment system can change ground pressure of tyres based on the compactness of road surface. That ensures good compactness and high productivity;
Hydraulic control, electric-control throttle, spacious and clear-view cab equipped with air conditioning, for comfortable operation;
Beautiful and tasteful streamlined appearance;
Anti-dumping device, three-level braking system (traveling, parking and emergency) for operational safety, startup locking device, malfunction alarming system and gemel lock-in device for machine security.
|
|
|
Pneumatic tire roller series are designed for the compact cohesive and non-cohesive materials, such as asphalt concrete, cement or lime stabilized soils, gravels, sands and clay mixtures, Rolling Cement Concrete(PCC)in the construction projects, especially suitable for the preparation of the upper courses of high grade highway.
|
|
|
This serial products belong to the hydraulic drive smooth tire roller, which are applied to the compaction of various cohesive and non-cohesive materials of road surface construction such as sandy soil, macadam, stabilized soil, asphalt concrete and dry concrete etc. These machines are the ideal equipment for final treatment of surface layer of high grade highway, airport, municipal engineering and industrial site.
|
|
RP series tyres road rollers :
- The Shangchai diesel engine ensure reliable and constant power with less noise.
- The engine cover is made of streamlined glass-fibre reinforced plastio- it's attractive and convenient to open.
- The rear wheel is joined, while the front wheel is a hang-way model. This ensures that the turning tyres will land envly and sustain the road-rollers at three points.
- Foot Brake System uses a pneumatic hydraulic pressure driving system, which operates easily and conveniently.
- 16 Layered pneumatic tyres are safe and resist wear. With the centralized pneumatic system, the pressure of these tyres can easily be adjusted at any time.
|
|
