Sanyo Denki propose a wide range of AC servo motors from 10 W to 20 kW, depending on input power and rotor inertia with a variety of options such as encoders or brake.
200V R2 SERVO MOTOR
30 to 750 W
40 to 80 mm square
Compact servo motor
Medium inertia, high efficiency and low ripple
200V Q1 SERVO MOTOR
30 W to 7.5 kW
40 to 180 mm square
Low inertia and high power rate
200V Q2 SERVO MOTOR
60 W to 15 kW
42 to 220 mm square
Medium inertia, high efficiency and low ripple
200V Q4 SERVO MOTOR
11 to 20 kW
180 to 220 mm square
Low inertia and high power rate
400V Q2CA SERVO MOTOR
500 W to 7 kW
86 to 220 mm
Medium inertia, high efficiency and low ripple
100V Q1 SERVO MOTOR
30 to 200 W
40 to 60 mm square
Low inertia and high power rate
100V Q2 SERVO MOTOR
50 to 200 W
42 to 76 mm square
Medium inertia, high efficiency and low ripple
200V P5 SERVO MOTOR
10 to 40 W
20 to 28 mm square
Ultra compact
High rigidity and fast postioning
|
|
|
|
|
|
Since 1983, Baldor has been supplying reliable servo motor solutions to worldwide applications. Baldor has the design team, experience, application support, test facilities, information, and the solution for your application needs.
Baldor goes beyond the industry standard with innovations to provide reliable performance, while exceeding customer expectations. Some examples of Baldor firsts:
stocking of servomotors for with immediate delivery - Baldor's commitment to provide you with service;
extra high insulated stator design for protection – Baldor's commitment to provide you with a quality product;
superior bearings with improved Exxon PolyrexEM TM polyrex grease to provide 4 times greater life – Baldor's commitment to you to provide a reliable product;
premium high temperature 200°C moisture resistance, multi-coated copper wire for ability to cope with large current spikes – Baldor's commitment to provide you with a superior product;
You have choices, whether that means a product from stock, or a specific custom design for your application – Baldor believes in providing you with choices and is always ready to tackle the most challenging application.
Baldor has a wide selection of high performance AC and DC servo motors. Brushless servomotors provide the industries highest power density for high torque to inertia in a very compact package. All Baldor servo motors are designed for durability, and ability to handle harsh environments in applications.
Applications include:-
Material handling, X-Y positioning, textile machines, packaging equipment, machine tool equipment, factory automation, and more.
|
|
|
|
|
|
Unimotor fm
055 to 250 Frames
0.72 Nm to 136 Nm(408 Nm Peak)
Unimotor fm
Unimotor fm is a high performance brushless AC servo motor range matched for use with Control Techniques drives. ‘fm’ stands for flexible motor, designed to accommodate a wide range of applications. The motors are available is seven frame sizes with various mounting arrangements and motor lengths.
Reliability and innovation
Unimotor fm is designed using a proven development process that prioritises innovation and reliability. This process has resulted in Control Techniques’ market leading reputation for both performance and quality.
Matched motor and drive combinations
Control Techniques motors and drives are designed to function as an optimised system. Unimotor fm is the perfect partner for Unidrive SP, Digitax ST and Epsilon EP drives.
Features
Unimotor fm is suitable for a wide range of industrial applications, due to its extensive range of features:
Torque range: from 0.72 Nm to 136 Nm
Standard and high energy parking brakes
Numerous connector variants, e.g. vertical, 90° low profile, 90° rotatable and hybrid box on frame size 250
Variety of flange possibilities (IEC/NEMA)
Various shaft diameters; keyed or plain
IP65 conformance; sealed against water spray and dust when mounted and connected
Low inertia for high dynamic performance; high inertia option available
World class performance
Supported by rigorous testing for performance and reliability
Optional high peak torque motors; up to 5 times stall torque
Winding voltages of 400V and 220V
Rated speeds include 1500 rpm, 2000 rpm, 3000 rpm, 4000 rpm, 6000 rpm and others available
|
|
The Dunkermotoren BG range of brushless, direct current motors (EC motors) are notable for:
Very long life
High efficiency
Highly dynamic acceleration
Good regulation characteristics
Wide speed range
High power density
Maintenance-free
Robust design
Integral Hall sensors for rotor position
Low moment of inertia
High degree of protection
Winding insulation - Class E or B
Neodymium magnets
These electronically-commutated DC motors can be combined with control electronics, gearboxes, and encoders in a modular system to provide a flexible, adaptable, market-oriented solution.
|
|
No cogging or preferred rotor position
No iron losses
Extremely low current consumption
Low audible and electrical noise
Extremely light and compact
Smooth and accurate speed, position, and torque control
Low vibration
Speeds up to 100,000 rpm
Electronic commutation for extremely long operational lifetime
High precision gearboxes available in all sizes
Feedback components available in all sizes
Control electronics available for all motor series
Custom systems available from design to production
|
|
No cogging or preferred rotor position
No iron losses
Extremely low current consumption
Low audible and electrical noise
Extremely light and compact
Smooth and accurate speed, position, and torque control
Low vibration
Speeds up to 100,000 rpm
Electronic commutation for extremely long operational lifetime
High precision gearboxes available in all sizes
Feedback components available in all sizes
Control electronics available for all motor series
Custom systems available from design to production
|
|
Baldor's DC high performance servo motors were designed rugged to meet demanding requirements of industrial motion control. They can be supplied with many electrical and mechanical options so the design fits your application. Some of the many options available include: tachometers, encoders, brakes, mountings, shafts, windings, speeds, connectors, environmental.
The DC servo motors provide continuous stall torques from 0.2 N-m (1.8 Lb-In) to 6.3 N-m (56 Lb-In). They are designed to provide reliability and dependability and long life in today's tough applications.
The DC servo motors are presently used world wide in applications such as X-Y tables , factory automation, coil winders, labeling equipment, machine tool, insertion machines, robotics, pick and place, packaging, converting equipment, assembly equipment and laboratory equipment.
|
|
Mounting size : 42 to 88 mm
Output Power : 23 to 500 W
Protection class : IP43
FEATURES : low torque ripple, long brush life expectancy, high resolution encoder (till 45000 ppr)
Option / Customisation : brake, tachogenerator, encoder, gear box, special winding
|
|
The motors of the type BG65 CI are
brushless DC-servomotors with integrated
motion controller and CANbus
interface (CAN open drives profile
DSP 402). Therefore even complex
motion profiles with predefined
position-, speed- and acceleration
values can be handled.
The Dunkermotoren BG range of brushless, direct current motors (EC motors) are notable for:
Very long life
High efficiency
Highly dynamic acceleration
Good regulation characteristics
Wide speed range
High power density
Maintenance-free
Robust design
Integral Hall sensors for rotor position
Low moment of inertia
High degree of protection
Winding insulation - Class E or B
Neodymium magnets
|
|
|
The BLM-N23-50-1000 is a brushless servo motor with a 1000-line encoder. It provides 55 oz-in of continuous torque and 120 oz-in of peak torque in a N23 frame. Brush type servos are also available
|
|
Compared to a solution with servo amplifiers located in a central cabinet, decentral compact servo drives offer some advantages:
* Lower cabeling effort
* Smaller cabinet
* Minimizing of error sources
* Commissioning is faster and more simple
* Lower price because of integration
ECOMPACT is based on our well-proven ECOSTEP motors series 23S. ECOMPACT features digital current, speed, and position control. Comprehensive motion control functionality is integrated. Parameterization and setpoint setting via CANopen.
|
|
Diameter: Ø4 to 12
Voltage : DC 5V to 12 v
Any Encoder are available.
Spur or Planetary gear box are available.
Controller for Ø12 is available
Application
-Robot
-Medical pump
-Chip mounter
|
|
The Milan drive advanced can be used whereever high position accuracy with excellent dynamics is required. The nominal torque of the largest size is 4 Nm, the maximum output speed at size MDA 35.1 is 6000 rpm.
The high enclosure protection IP64, optionally IP67, allows the use in extremely unfavourable ambient conditions.
|
|
|
|
|
|
QUICKSHAFT® Linear DC-Servomotor series LM 1247
NEW TECHNOLOGY
Up to 9,4 N impact
Boasting a slimline design of 12.5 x 47 mm and a weight of only 56 grams, at full power this drive provides an impact force of 9.4 N. For the standard product the travel is 20 mm; optionally travel up to 80 mm is also available. The Linear DC-Servomotor comprises an electromechanical part, a metal housing made from a non-magnetic alloy, a coil and an analogue Hall sensor. A precision sliding metal rod equipped with a permanent magnet completes the linear motor, and together they make a dynamic, high-performance drive in a modern design.
The activation of these new QUICKSHAFT Linear motors is provided via the optimally matched motion controllers of the MCLM 3003/06 series, which are also available with a CAN interface. The free FAULHABER version 3 "Motion Manager" software provides rapid and easy control of the linear motor. In numerous applications this newly developed drive has proved itself to be the best-in-class solution for highly demanding linear movement and positioning tasks.
|
|
|
These low-pole AC servo motors of the ECOSPEED series stand out due to extremely low torque ripple at low speed. Torque from 1 - 26 Nm. Flange dimensions 60 mm, 80 mm, 110 mm, 130 mm. Rated speed depending on series between 1500 and 5000 rpm. Available with incremental encoder or absolute value encoder. Holding brakes from 0.5 - 10 Nm (optional). Certified version according to ATEX directive 94/9/EG for use in hazardous locations. Also available as hollow-shaft built-in motor. Approvals: UL/CSA, CE.
|
|
For nearly two decades, the name Moog has been synonymous with high performance brushless servomotors and servodrives offering the highest dynamic performance, power density and reliability. We are committed to offering a full range of products as well as custom solutions and systems expertise. Other electric products offered include electro-mechanical actuators and accessories.
Moog's brushless servomotors and servodrives are rugged for long service life and when you need repairs, ask for Moog Authentic Repair Services.
|
|
The SE500 series brush motors from Trust Automation are stocked at our factory for quick delivery on orders of five or less units. Our servo motors combine standard US style encoders in a compact high quality package.
The SE500 Series motor line includes differential encoder signals, A, B and Index. All models are oil sealed and have brake and tachometer (110W and larger) options. They have very low torque ripple, about .6% of the ripple present in previous generation motors.
|
|
IndraDyn A is the new generation of asynchronous motors in the 1 to 100 KW power range, available in four axis heights (100, 130, 160 and 180), with options like high-resolution, single-turn or multi-turn absolute encoders and a brake. The air and liquid-cooled motors provide significant advantages for service and preventive maintenance due to their integrated modular construction. For example, exchanging a cooling fan is possible in a few minutes with the appropriate safety measures, even when the motor is running. This provides substantial advantages when used in decentrally-powered printing machinery, machine tools, plastics machinery and general automation.
MAD Series – Air-Cooled Asynchronous Servo Motors
With modern development and production processes, a significant performance increase can be achieved in contrast to previous models. Unparalleled performance: Drive and fan motors offer an IP65 protection rating
|
|
4-pole sinusoidal brushless motor, in enclosed form.
- Rotor with NdFeB magnets.
- Safety circuit breaker.
- Winding class F according to VDE0530.
- IP65 insulation according to CEI EN 60529 standards.
-Feedback with resolver 2 poles.
On request it is possible to mount a 24 VDC NC brake with permanent magnets, identified by the letter K (BSK).
|
|
SUPERSAX ®
Complete line of sinusoidal brushless servomotors. Torque ranges from 0.35 up to 30 Nm.
With a fashionable design and a torque range from 0.35 to 30 Nm the SUPER SAX® (6 poles) are an excellent solution for the most demanding needs of industrial automation, where very high performance axis control is required. Specially designed for use with AXOR’s brushless servodrives, all types (MAGNUM 400®, MINI MAGNUM® and Micro B® line).
|
|
The SE700 series brushless motors from Trust Automation are stocked at our factory for quick delivery on orders of five or less units. The modern design of this medium inertia AC motor reduces the overall size of the motor, delivering significantly higher torque than older models. They are designed to meet the demands and requirements of high performance motion control applications.
The SE700 motor line includes standard US 1000 line encoders with differential encoder signals, (A, B, Index), and Hall Sensors with standard Hall signals, (U, V, W). They have very low torque ripple, at 0.3 % of rated torque. All models are oil sealed and have brake and tachometer (110W and larger) options.
|
|
The SE600 series brushless motors from Trust Automation are stocked at our factory for quick delivery on orders of five or less units. Our low inertia AC motors new design reduces the overall package size, delivering higher torque than older models. They are designed to meet the demands and requirements of high performance motion control applications.
The SE600 motor line includes standard US 2000 line encoders with differential encoder signals, (A, B, Index), and Hall Sensors with standard Hall signals, (U, V, W). They have very low torque ripple, at 0.3 % of rated torque. All models are oil sealed and have brake and tachometer (110W and larger) options.
|
|
The new series of servo motors SM2A with integrated motor can be easily programmed through EVER's windows PC based user friendly development environment called ATOMIC.
The SM2A series are constructed with a high protection degree of IP65 and are equipped with reliable connectors. Other features are: AC power supply, fieldbus CANbus or serial RS232/485, optoisolated inputs and outputs, an encoder for the closed loop control of torque, velocity and position (optional), The motor section is made of magnetic Low Loss material and has a holding torque from 3,4 to 12,5 Nm.
|
|
The Gefran-Siei ARTDrive S - XVy series of servo drives offers the most advanced technology for drives used in Motion Control applications.
Integrated state-of-the-art functions and the availability of a wide range of ratings for brushless and asynchronous motors make these ideal for use with the most modern industrial servo systems. Moreover, the integration in the drive of dedicated application software programs allows for unique customisations, to suit specific controls of complex machinery.
|
|
TRM servomotors are designed for optimum performance and durability in demanding variable-speed motor applications, TRM DC high performance servo motors were designed rugged to meet demanding requirements of industrial motion control. They can be supplied with many electrical and mechanical options so the design fits your application. Some of the many options available include: tachometers, encoders, brakes, special mountings, special shafts, different windings, connectors, environmental sealing.
The DC servo motors family provide continuous stall torques from 0.4Nm (0.3 lb-ft) to 30Nm (24 lb-ft.) They are designed to provide reliability and dependability and long life in today's tough applications.
|
|
Simple and yet powerful is the S series, developed for the pump industry as well as the fan and blower application. Foot and flange mounted, with shaft dimensions to the UNEL standard.
|
|
Rexroth IndraDyn S
Synchronous servo motors (MSK) for all requirements, from 1 to 260 Nm and synchronous servo motors for explosive environments (MKE), from 1 to 100 Nm
Rexroth IndraDyn A
Air-cooled asynchronous servo motors (MAD) and liquid-cooled asynchronous servo motors (MAF) for power levels from 10 to 100 kW
Rexroth IndraDyn L
Synchronous linear motors for feed forces from 200 to 22,000 N
Rexroth IndraDyn T
Synchronous torque motors with torque ratings up to 13,800 Nm and rotary speeds up to 2,000 rpm
Rexroth IndraDyn H
Synchronous high-speed motors for maximum torque up to 6,500 Nm and speeds up to 30,000 rpm
Gearboxes
Standard (GTE) and high-performance (GTM) planetary gearboxes for servo motors
Standard and geard boxes
Wirtschaftliche und zuverlässige Technik bekannter Hersteller mit optimaler Anbindung an Rexroth-Antriebssysteme
|
|
UNIMOTOR FM Servomotor - From 0.7 to 410 Nm
General Information:
- Autosynchronous motor, 6 or 8 poles
- 2000 à 6000 rpm
- With or without mechanical brake
- Incremental or Sincos encoder, resolver
- IP 65 protection
- Winding voltage 200/240V or 380/480V
- High or standard peak torque
|
|
Servo motors
Responsive - compact - reliable
Lenze servo motors meet the highest quality requirements within the context of drive technology and feature a modular and application-oriented design. Forming an integral part of a drive axis, they are easy to install and enjoy a long, maintenance-free service life. The motors are universally compatible with the Lenze gearbox ranges.
|
|
Servo Motors: PSM 25/37/55
An aimed supplement to the driving solution: Servo motors show universal strength
Phytron's PSM series synchronic servo motors complement the stepper motors through manifold solutions in the automation technology. The servo motors are brushless, three phased synchronic motors. They feature high torque, small sizes, high efficiency, slight moments of inertia and high overload capacity.
- Small Servo Motors with Continuous Stall Torque from 0.03 to 0.9 Nm.
- Control with a PC-based Motion Controller for Servo Motors and Stepper Motors.
- High torque
- Small size
- High efficiency
- Low mass inertia
- High overload capacity
|
|
|
|
