DZ 266: Signal Converter Frequency to Analogue and Frequency to Serial RS232
Multifunctional converter module with fast response time and many programmable features for conversion of frequencies to voltage, to current or to serial data format
Scalable LCD display for indication of the actual input frequency and the operating state
Universal impulse imputs for use with single channel signals (A only),
quadrature signals (A, B, 2x90°) or differential TTL / RS422 signals
A, /A, B, /B
Analogue outputs +/- 10 V (polarity represents direction of rotation) and
0/4 – 20 mA, resolution 14 bits
Wide operationg range: 0,1 Hz bis 1 MHz
Setup by means of the front keys and LCD menu, or by PC
Serial RS232 interface
Power supply 24 VDC, auxiliary output +5V for supply of TTL encoders
DIN rail mounting
|
|
VisConnect 4-20 mA Analog Output Module
VisConnect is a stand-alone, analog/digital output hub that provides access to ViSmart-delivered data via a standard 4-20 mA output signal, allowing customers to acquire multiple channels of continuous viscosity and temperature data and integrate that data into any host control platform, without the use of expensive instrumentation.
The VisConnect has two loop-powered, galvanically isolated channels of 4-20 mA output, allowing customers to configure the minimum and maximum analog outputs to correlate to 4 mA and 20 mA, or optional 0.5V to 4.5V, respectively. With an optional 2 channel analog voltage output, standard communications protocol for industrial applications, the VisConnect can connect to any legacy DAQ or host control system. An RS232 Serial communication interface is present, and an optional CAN interface will be made available in the future.
|
|
Suitable for J and K thermocouple
IN / OUT / supply galvanic isolation
8 programmable temperature ranges
3 programmable output ranges
Simple programming, self calibrating
Availabe version with 24-240 Vac/dc supply voltage
|
|
The K-LINE is a configurable, DC powered, DIN rail mounting, DC input signal conditioner with 1500 volt isolation between input, output and power. The dip switch selectable input and output ranges on the
K-LINE offer flexibility and ease of configuration without calibration equipment. The module provides accuracy better than 0.1%. The module’s high density package (6,2mm) makes it ideal where panel space is topic. Other feature include a power bus option, quick connection spring clamp terminals, and front panel diagnostic LEDs. In addition to high performance, these units are highly reliable with a calculated MTBF specification of greater than 500,000 hours over an extended operating temperature range of -40°C to +65°C.
|
|
|
Delta carries a variety of signal conversion peripherals. Signal conversion peripherals are used to match the signal levels and signal types between components in your motion system. For example, you can convert a voltage drive output to a current drive output in order to control a servo valve. While these products have been designed to satisfy requirements of Delta motion control products, they can be used in any system.
|
|
Signal converters are the ideal interface solution for Class I, Div. 2 and Intrinsic Safety applications - more compact and easier to wire, install, and configure than other methods.
These DIN-rail mounted PLC and I/O system signal conditioners isolate, amplify, filter signals from harsh industrial interferences enhancing the overall reliability of the system.
|
|
eNod 3 : Digital measurement power 3 !
· 24 bits conversion, up to 1 600 meas./s.
· Digital filters
· RS485/232 and CANBus outputs, MODBus-RTU and CANOpen
ENod3 offers a low-cost and powerful solution to convert any strain-gauge sensor into an intelligent digital system:
- Digital high speed transmitter
- Dynamic weighing controller (Checkweigher)
- Peak value detection
Control the power of numerical filtering with eNodView freeware:
· Complete eNod setting up
· Measurement acquisition and displaying
· Signal analysis
· Digital filters simulation
|
|
The iT Transmitter is a signal conditioning module that interfaces with a traditional IEPE accelerometer to provide a 4-20 mA output signal and a buffered dynamic signal. This allows the user to interface an accelerometer with a PLC/DCS system for condition trending, while still providing a dynamic output for more extensive vibration analysis through the BNC connector on the front of the module. The iT Transmitter is ordered with custom settings to meet user-specific requirements.
With unique high- and low-pass filters - and a host of options for customizing the transmitter to your specific needs. By utilizing your existing sensor infrastructure, Wilcoxon's Total Lower Cost (TLC) Approach reduces the expense of online monitoring.
|
|
Reliable and precise, the ME520 and ME52C passed successfully all the tests, from the agro-alimentary processes to the car industries, aeronautical and petrochemical.
The modules of measurement ME520 and ME52C propose a very complete electronic allowing the measurement of all types of sensors or signals, the conditioning of sensor as well as the conversion of many signals.
Modules ME520 are very easy to use. A notch of calibration makes possible to regulate the analogical exit using a potentiometer multi turns.
Modules ME52C, are calibrated in our laboratories, no adjustment is not to be made. The values of entries and exits are fixed and can be adjusted on request.
|
|
Technical Datas Smart-Transmitter MSK 200
MSK 200, MSK 200-T
Smart-2-wire-supply unit in DuoTech Failsafe Technology
Option:
"iExa" Input EExia IIC
"AK4" Certified according to DIN 19250, class 4
|
|
- Transfer Data with accuracy, reliability and simplicity using our new uDockTM Model U2CI through the instrument's IR port
- Easy to install software from CD or www.myronl.com
- The uDock application will operate on Windows XP and Vista*; and Macintosh OS9.2 and OSX**
- Automatic organization of data (record number, type of measurement, value and unit measurement, solution, temperature, date stamp, and time).
- Exports to Office software (Word*, Excel*, Works*...etc) using universal formatting (.CSV) files
- Control your Ultrameter IITM and PoolProTM time and date setting though our uDock software.
- Clear instrument memory through our uDock software
- Self powered by USB portor eve
|
|
PRODUCT RANGE GENERAL PRESENTATION
The electronic allows the vibration of the viscometer and processes the amplitude variations in order to deliver a linear viscosity response.
960X range
• Viscosity and temperature processor
• Density for kinematic viscosity measure (optional)
• Flush-type mounting
• 24 keys keyboard and graphic display
• User friendly utilisation
• Analogic current outputs 4-20mA, relays, RS 232 - RS 485
800x RANGE
• Viscosity controller
• Maximal process temperature 200°C or 300°C
• Flush-type mounting
• Analog output 4-20 mA
• RS 485 output
• Output relay (switching power 2A - 250VAC)
7000 RANGE
• Viscosity and temperature transmitter
• Maximal process temperature 100°C
• Mounting on standard DIN rail
• Analog output 4-20 mA
• RS 485 output
|
|
M3LU universal and configurable converter
- Universal converter configurable by DIP switch and key in front display without needing a PC computer or an Hand Held Communicator,
- Configuration PC software in option,
- 4 wires technology - 9-36Vdc or 85-264Vac 50/60Hz external power supply,
- Universal input : current (0-20mA), voltage (-10 to +10Vcc), thermocouple (K, E, J, T, B, R, S, C, N, U, L, P), resistance bulbs (Pt100/1000, Ni100/120, Ni508,4, Ni-Fe604, Cu10) or potentiometer (0-4000O),
- Universal output : current (0-20mA) or voltage (-10 to 10Vcc),
- Burnout function (mini./maxi. of scale),
- Input/output isolation: 1500Vca,
- DIN mounting.
|
|
|
|
|
|
In the area of suppression modules for contactors, valves and motors, we offer the corresponding components to increase EMC throughout the whole installation. We can meet all normal requirements in the field of power supplies with our power supply units, incorporating primary switching technology and control-power transformers.
Interface technology is represented in the Lutze programme by a wide range of different components that can be used to create just about any interface needed in your application.
Lütze Microkon Signal Conditioner and Converter Series: With fixed input/output or with 9 adjustable ranges; High accuracy (0.1%); Space-saving Microcompact 6.2 mm design.
Lütze Universal Analogue Signal Converter: With 48 selectable ranges; With 3-way isolation and wide-range input 24 to 240 V AC/DC; Space-saving Microcompact 17.5 mm design; 2- and 3-way separation.
Lütze PT 100 Temperature Converter: With and without galvanic isolation; High accuracy (0.3%); Space-saving Microcompact 6.2mm design; Freely adjustable operating points.
|
|
|
|
|
|
TELIS reinvent measure conversion and transmission
It’s graphic screen display, and it’s joystick make user-frendly and easily programmable device.
It’s USB front face plug enable a very simple programmation with PC.
It’s cutting edge technology allows TELIS to have exceptional caracteristics.
It’s input and output configurations, fitted to market, allow to give solutions to all applications.
It’s double current input design allows TELIS to become a double transmitter in one device.
TELIS is designed in JM concept case unplugable from its DIN RAIL wiring base
TELIS is able to reduce it’s consumption up to 50% and contribute to energy saving and environment protection.
TELIS can be used as one input configuration transmitter, or two inputs configuration transmitter.
- In case of one input configuration, TELIS is a transmitter allowing all input type and sensor power supply.
- In case of two input configuration, TELIS can use it’s calculation function or become a double transmitter; in this case TELIS becomes a double transmitter in one device.
Whatever input configuration is used, TELIS offers 1, 2 current or/and tension output, 1, 2, 3, 4 relay outputs.
TELIS has also a RS485 modbus, jbus digital output and an USB front face plug allowing a very simple programmation with PC.The free sofware SETLINE enables a very simple product configuration, and to save configurations, etc.…
TELIS is designed in 22.5mm or in 45mm width case, with or without graphic screen display, and joystick, according to references
|
|
In the process control and automation field, often the need arises of interfacing low level signals generated by thermocouple, Pt-100, load cell, current and voltage transducers, LVDT etc.. to the process controllers, PLC, DCS etc.. Also, one signal needs to be fed to the multiple control device. To take care of common ground loop of many sensors to single system and also avoid loading effect, isolation of these signal from one another is must. The models featured here provides optical and/or galvanic isolation between input and output, maintaining the desired level of accuracy and linearity.
APPLICATIONS
For conversion and isolation of low level dc signals to (4-20)mA signal for interfacing to PLC, SCADA, DCS etc..
|
|
|
A full range of signal converters and isolators to meet every process application. The high end allow flow, pressure, and level calculations. Simple loop powered isolators are also available.
|
|
|
|
|
|
General description :
Intersil is introducing a new family of the world's lowest power, high-performance analog-to-digital converters. Our innovative FemtoCharge® CMOS technology yields ultra-high performance ADCs that consume a fraction of the power of the competition. The unmatched size and power advantages of our data converters enable increased functionality in a broad cross section of applications including:
Communication: Cellular base station receivers, set-top boxes, portable radios
Networking: Cable head-end infrastructure, networking cards
Instrumentation: data acquisition, digital scopes, telecom test equipment
Industrial: security screening equipment, industrial and medical imaging
Military: Electronic warfare, radar, broadband secure communications
Video & Imaging: PC peripherals (card scanners)
FemtoCharge® ADCs deliver outstanding dynamic and low power performance combined with superior wideband capabilities and a compact footprint. These ADCs boast best-in-class sampling rate and low power consumption versus the competition.
With a product portfolio spanning a variety of sampling rates and resolutions of 8, 10, 12 and 14 bits, Intersil offers solutions for multiple high-performance conversion applications.
|
|
|
We offer a very wide range of high-performance data converters. Our A/D and D/A converters (ADCs and DACs) have resolutions from 6 bits to 18 bits and sampling rates from DC to 2.3Gsps.
|
|
A/D Converters
5102ALP A/D Converter, 16-bit, 20kHz, Single Event Latchup-protected
7672 A/D Converter, 12-bit, 5us conversion time
7805ALP A/D Converter, 16-bit, Parallel, Single Event Latchup-protected
7809LP A/D Converter, 16-bit, Serial, Single Event Latchup-protected
7820 A/D Converter, 8-bit, 1.36us conversion time
7872 A/D Converter, 14-bit, 10us conversion time
9042 A/D Converter, 12-bit, 41 MSPS
9240LP A/D Converter, 14-bit, 10Mhz, Single Event Latchup-protected
D/A Converters
5675RP D/A Converter, 14-bit, 400 MSPS
7545A D/A Converter, 12-bit, Buffered Multiplying
7846A D/A Converter, 16-bit
8143 D/A Converter, 12-bit, Serial Daisy Chain
8408 D/A Converter, Quad 8-bit Multiplying CMOS
|
|
|
The Microchip Technology Inc. MCP355X devices are 2.7V to 5.5V low-power, 22-bit delta-sigma A/D converters. The devices offer output noise as low as 2.5 µVrms with a total unadjusted error of less than 10 ppm. The family exhibits less than 6 ppm integral non-linearity (INL) error, 3 µV offset error, and 2 ppm full scale error. The MCP355X devices provide high accuracy and low noise performance for applications where sensor measurements such as pressure, temperature, and humidity are performed. With the internal oscillator and high oversampling rate, minimal external components are required for high accuracy applications. The fully differential analog inputs make it compatible with a wide variety of sensor and measurement applications. The MCP355X devices operate from -40°C to +125°C and are available in the space-saving 8-pin MSOP and SOIC packages.
|
|
|
National's Powerwise Analog-to-Digital Converters (ADCs) are the lowest power family of A/D converters on the market. In addition to providing extremely low power consumption over a range of sample rates, each ADC has a very efficient power down feature. For example, a single channel 1Msps PowerWise ADC used in a 10 Ksps application has a typical power consumption of 0.02 mW at 3V.
|
|
As the world's leading supplier of data converters, Analog Devices enables new system architectures with analog to digital converters (ADCs) that deliver breakthrough combinations of performance and function. Analog Devices' ADCs are unmatched in their ability to deliver the low power, small footprint, and low cost requirements today's systems demand. ADI's A/D converters provide superior value for high-volume applications in cost-sensitive markets.
|
|
Linear Technology offers a complete family of high performance analog to digital converters (ADCs), including 16-bit to 24-bit delta-sigma converters for precision measurements, up to 16-bit high-speed pipeline for communications and 8-bit to 16-bit low power successive approximation (SAR) ADCs for everything in between.
|
|
|
High Performance Analog to Digital Converters (ADC) and Digital to Analog Converters (DAC) for real world analog applications.
|
|
austriamicrosystems' portfolio of A/D converters includes 10-bit to 12-bit converters with sampling rates up to 400ksps, offering the low power consumption typical for austriamicrosystems devices.
AS1524: Micro-Power, 12-Bit ADC, 150ksps, 1-Channel True-Differential, TDFN (3x3mm) 8-pin
AS1525: Micro-Power, 12-Bit ADC, 150ksps, 2-Channel Single-Ended, TDFN (3x3mm) 8-pin
AS1526: 10-bit ADC, 1-Channel, 73ksps, with internal reference, SOIC 8-pin
AS1527: 10-bit ADC, 1-Channel, 73ksps, SOIC 8-pin
AS1530: 12-Bit, 8-Channels, Low Power A/D Converter with 400ksps
AS1531: 12-Bit, 8-Channels, Low Power A/D Converter with 300ksps
AS1534: 12-bit ADC, 8-Channel, 200ksps, 16-bit parallel interface, PQFP 44-pin
|
|
