Self-contained plunger-and-spring device available in many sizes and forces. Long bearing length on plunger for smooth operation. Locking element holds the unit securely in place after installation. Install and/or adjust from either end (when using the slot at the plunger end, install with a Plunger Wrench to avoid over-compressing the spring). Available in steel, with a hardened plunger nose, or stainless steel.
|
|
Ganter offers a wide range of plastic, steel or stainless steel spring loaded plungers in different sizes and versions.
A special thread locking is available on request.
|
|
Material:
Sleeve in thermoplastic,
spring in stainless steel,
ball in stainless steel or plastic
Surface finish:
Sleeve black;
ball in stainless steel hardened, natural finish
|
|
Steel Spring Plungers
Stainless Steel Spring Plungers
Steel Spring Plungers (Metric)
Stainless Steel Spring Plungers (Metric)
Delrin Tip Steel Spring Plungers
Delrin Tip Steel Spring Plungers (Metric)
Delrin Tip Stainless Steel Spring Plungers
|
|
MISUMI Europe
MISUMI offers more than 1 million mechanical standard-, purchasing- and drawing-components from one source. The voluminous catalogue contains over 40 product groups and all important information at a glance: configurable components, material, hardness, surface treatment, tolerance and price including volume discount, reliable lead time, technical drawings and application examples.
Additional features: Average delivery time between 6 to 8 working days, orders without markup for small-volume purchases, no minimum order quantity. MISUMI 24/7 e-Commerce enables our customers to find and configurate products online and download CAD-Data immediately. Quotations and orders can be created and saved directly online.
MISUMI - Precisely Meeting Your Demands
|
|
Spring plungers GN 615.7 are used for end stops as well as contacts.
Simultaneously an electrical control signal can be released from the built-in limit switch.
|
|
WDS Index plungers are available in several types and material specifications
Materials include:
Hardened Steel Chemical Black Finish with options of steel or nylon ball
Case Hardened Steel
303 Stainless Steel and Stainless Ball
Stainless Steel with Nylon Body
|
|
|
|
|
|
The product family Spring Plungers covers the following article groups:
- EH 2203. Spring Plungers with ball and internal hexagon
- EH 2203. Spring Plungers with bolt and internal hexagon
- EH 2204. Spring Plungers, plastic
- EH 2205. Spring Plungers with ball and slot
- EH 2205. Spring Plungers with bolt and slot
- EH 2205. Spring Plungers with ball, headed
- EH 2206. Spring Plungers with internal hexagon
- EH 2206. Spring Plungers with internal hexagon and seal
- EH 2207. Spring Plungers, smooth
- EH 2207. Spring Plungers, long
- EH 2208. Spring Plungers, smooth, with collar
- EH 2208. Spring Plungers, smooth, without collar
- EH 2209. Spring Plungers, double ended
- EH 2210. Spring Bodies
- EH 2214. Lateral Spring Plungers
- EH 2215. Lateral Plungers, smooth (with / without sealing)
- EH 2215. Excenter for lateral plungers, smooth
- EH 2215. Lateral Plungers with thread (with / without sealing)
Additionally to the metric version we have also the following inch version available from stock:
- EH 2B02. Spring Plungers with bolt and slost
- EH 2B03. Spring Plungers with bolt and internal hexagon
- EH 2B05. Spring Plungers with ball and slot
As leading manufacturer with long experience in production of spring plungers we offer a product range for almost all applications. Also special constructions are available within short time upon request.
|
|
03020
Spring Plungers
with end position feedback
Material:
Sleeve, pressure pin and spring in steel,
inductive proximitiy switch
Surface finish:
Black oxide finish, pressure pin hardened
Note:
An electrical control signal can be sent via the built-in end switch.
Voltage: U = 10 – 30 V DC
Electricity: I max. = 200 mA
Temperature range: -25 °C – +70 °C
Protection class: IP 67
Security:
The use of spring plungers with end position feedback is not suitable for restraining people.
|
|
|
|
