Pitch: 3, 2 mm
Data rate: 25 GB/s - 56 GB/s
... TO HIGHER BANDWIDTH APPLICATIONS ExaMAX® 92Ω backplane connector system meets industry specifications requiring higher bandwidth applications from 25Gb/s to 56Gb/s. The optimized connector design delivers superior ...
FCI
Primary current: 20 A
Voltage: 20 kV
... single pin high voltage connectors and cable assemblies, some of which have been in production for more than 60 years, reflecting TRI's relentless commitment to engineering, quality and customer service. TRI leads the connector ...
Teledyne Reynolds
... Overview
Universal I-shape
connector designed for aluminium profiles (series 94-228).
Material
Zamac.
Usage
- Allows fastening two aluminium profiles end-to-end quickly and securely.
- Fasteners
... Description
- Field-terminable RJ45 plug Cat.6A / Class EA
- Centrically aligned, multiport-capable
- Straight cable entry (180°)
- Easy field termination without special tools
- Stranded conductor support: AWG
METZ CONNECT
... ・PC board jack RJ45, shielded ・multi port 1x4, top entry, with 8 contacts ・solderable, color metallike ・L x W x H: 16.70 x 55.90 x 16.40 mm ・bottom latch ...
METZ CONNECT
... ・PC board jack M12 ・rear mounting ・3-pole, A-coded according to IEC 61076-2-101 ・THR solderable ・Top entry ・Contact carriers black ・IP67 when plugged in ・suitable for applications in the railway industry according to data sheet ...
METZ CONNECT
Operating temperature: -10 °C - 80 °C
... The WEH® TW131 Quick Connector is the manual version of the WEH® TW130 Quick Connector. The connector has been developed specially for testing components with banjo tube connections, hose and tube connections ...
WEH FluidTech GmbH
Operating temperature: 5 °C - 100 °C
... tests. These connectors are an ideal alternative to collars, beads and male threads at fuel lines of engines or for automotive components. The WEH® TW714 is equipped with an automatic shut off valve, an unlocking device to release the ...
WEH FluidTech GmbH
Operating temperature: -10 °C - 80 °C
... The WEH® TW132 Quick Connector is the low pressure version of the WEH® TW130 Quick Connector. The connector has been developed specially for testing components with banjo tube connections, hose and tube ...
WEH FluidTech GmbH
... Tank monitoring accessorie. In/out, 2 electrical connectors. For use with U·valve, U·valve+, U·meter, U·meter+, U·pulser+, U·count, U·view, U·tank and U·net. ...
Primary current: 30 mA
Operating temperature: -70 °C - 850 °C
... ALMEMO® Connectors for thermocouples • High-level resolution of 0.01 K across the entire measuring range up to 850 °C • Linearization of the Pt100 / Pt1000 characteristic calculated • Calibration with greater accuracy by subjecting ...
Ahlborn Mess- und Regelungstechnik GmbH
Primary current: 12 mA
Voltage: 6, 9, 12 V
Operating temperature: 22 °C
... ALMEMO® Connectors for DC • High resolution up to 0.001 mV / 0.1 μA (200 000 digits) or fast conversion rate, resolution up to 1 mV / 10 μA (2000 digits). • Only for latest ALMEMO® V7 measuring instruments, including ALMEMO® 500, ...
Ahlborn Mess- und Regelungstechnik GmbH
Primary current: 4 mA
Voltage: 6 V - 13 V
Operating temperature: 25 °C
... Pressure measuring connector for barometric pressure and for differential pressure • Compact design - can be plugged directly onto measuring instrument • High measuring accuracy • Designs and specifications see data sheet ...
Ahlborn Mess- und Regelungstechnik GmbH
Voltage: 1,500 V
... Description
The PE 25-I is a magnetic protective earth
connector that provides a fast, tool-free contact to protective earth via a magnetic housing connection and integrates a high-current plug ST 04-i. Engineered for professional ...
SPS electronic GmbH
Primary current: 16 A
Voltage: 7,000 V
... Overview
1-pole high-voltage
connector for voltages up to 7,000 V and currents up to 16 A. Robust mechanical design suitable for industrial environments. Includes a 4 m connection cable with free cable end.
Key features
SPS electronic GmbH
Primary current: 1 A
Voltage: 10,000 V
... Product description
1-pole high-voltage
connector for voltages up to 10,000 V DC and currents up to 1 A. Robust mechanical design for industrial environments and integration in OEM or test equipment.
Key features
- Application
SPS electronic GmbH
Primary current: 57, 72, 48 mA
Voltage: 24 V
Operating temperature: 0 °C - 55 °C
... ±6 V DC
... Product overview
netLINK PROXY NL 51N-DPL is a plug-on PROFINET/PROFIBUS proxy
connector that integrates an existing PROFIBUS DP slave into a PROFINET network. The device is mounted directly onto the PROFIBUS DP interface of ...
Operating temperature: -51 °C - 125 °C
... Overview
With the ODU AMC®, we offer you top-quality
connectors for military and security applications. These can be customized to meet your specific system requirements. The ODU AMC® is available in two locking variants—push-pull ...
ODU GmbH & Co. KG
Operating temperature: -40 °C - 120 °C
... Overview
ODU MINI-SNAP®
Connectors in four series: L, K, B, and F – characterized by robust metal housings with different surfaces. With push-pull locking or break-away function, these metal circular
connectors ...
ODU GmbH & Co. KG
Voltage: 0 V - 1,000 V
... high contact density, and various angle options. We offer flexible complete systems consisting of push-pull or break-away
connectors, cables with suitable assembly and mechanical or optical coding.
- High-voltage solutions
ODU GmbH & Co. KG
... Conductor - Groundind rod connectors · Joins down conductors of an external lightning protection system to the grounding electrode. Characteristics • Made of Cu / Zn (brass) alloy, steel screws. • Bimetallic connector. • ...
INGESCO
... CROSS- CONNECTOR • Cross, “T” and parallel connection of conductors. • Forks for downspout cables of external lightning protection systems and grounding systems. • Crossing of cables into meshes. • Connection of conductors to steel ...
INGESCO
... ADAPTABLE UNIVERSAL CONNECTOR • Cross and parallel union of conductors. • Forks for down conductor cables of external lightning protection systems and grounding systems. • Crossing of cables into meshes. • Connection ...
INGESCO
Primary current: 35 A - 1,500 A
Operating temperature: 80 °C
... Sockets 35-1500 A with thread connection Material: brass silver plated ...
Druseidt
Primary current: 35 A - 1,500 A
Operating temperature: 80, 20 °C
... Plugs 35-1500 A with threat connection Material: brass silver plated ...
Druseidt
Primary current: 80 A - 300 A
Operating temperature: 20, 80 °C
... Sockets 80-300 A with snap-in lock and crimp connection Material: brass, silver plated ...
Druseidt
Operating temperature: -20 °C - 70 °C
... electromagnetic compatibility (EMC)
Characteristics / technical specifications
- Model: EEM 33-27
- Connector thread: M16x0.75
- Number of pins: 6
- Configuration: coupling socket (coupling
Novotechnik
Operating temperature: -40 °C - 125 °C
... Product overview
- MQS connector kit consisting of:
- 1 female connector, PBT GF15
- 6 tin-plated contacts for stranded wire cross-sections of 0.25 … 0.35 mm² (AWG 22)
- Single-conductor
Novotechnik
... Product overview
Angled M16x0.75 8-pin coupling
connector EEM 33–85 with cap nut, solder terminals and shielded housing. Designed for shielded cable systems and industrial installations; protection class IP67; UL-approved.
Features ...
Novotechnik
... Pull RJ45 system” is a ruggedized and lockable designed RJ45 connector system, ideal for pro audio, video and lighting network and digital signal transmission applications. The chassis connectors shaped to fit into standardized ...
EmCom Technology Inc.
... and moisture protection which is the ideal interconnect solution for heavy-duty and harsh-environment applications. RJ45 connector is the most common used interface in data communications and the 4PPoE compliant RJ45 solution supports ...
EmCom Technology Inc.
... and moisture protection which is the ideal interconnect solution for heavy-duty and harsh-environment applications. RJ45 connector is the most common used interface in data communications and the 4PPoE compliant RJ45 solution supports ...
EmCom Technology Inc.
... Product description
- Part Number: CSTS19770-4
- Part Type: Static Adapter
- Application: Agusta AB412 helicopter
- Compatible pitot probe: AD5813-1
Compatibility
- Intended for installation
... The RRJ_USB_C_PD PowerDelivery charging socket from the RONTRON-R-JUWEL series offers a spring clamp connection for easy installation. The built-in socket has protection class IP20. Shape round Mounting aperture Ø 22,3mm Connection type spring-clamp ...
Georg Schlegel GmbH & Co. KG
... USB2.0 jack A/ connector A (60 cm) Mounting aperture Ø 22,3mm Shape rounded square Illumination No Front bezel colour silver ...
Georg Schlegel GmbH & Co. KG
... • Shape : round • Mounting Aperture : Ø 22,3mm • Series : RONTRON-R-JUWEL • Illumination : No • Front Bezel Color : silver ...
Georg Schlegel GmbH & Co. KG
Plug-in ConnectorPlug-in TB 5P female horizontal out for power bus.Accessory type: Plug-in connectorOrientation: Female, horizontal outputApplication: Connection to Power BUSProduct status: ACTIVEDocumentation:Instruction Manual D5000-D5200 Series (available ...
GM International S.p.A.
Plug-In ConnectorPlug-in TB 5P male horizontal out for power bus.Status: ACTIVEProduct lifecycle policy: ENDocumentation:Instruction Manual D5000-D5200 Series (EN)Declarations of Conformity:EU Declaration of Conformity for bus D5000 series (zone 2) (EN ...
GM International S.p.A.
... BUS Connector22mm DIN Rail ConnectorStatus: ACTIVEProduct lifecycle policy (EN)Documentation:Instruction Manual D5000-D5200 Series (EN)Declarations of Conformity:EU Declaration of Conformity for bus D5000 series (zone 2) (EN | IT)Drawings:3D_drawing_JDFT050 ...
GM International S.p.A.
Operating temperature: -40 °C - 125 °C
... M12 Power cable connector Housing type - Cable Material housing - brass,Zinc Die Cast Material housing surface - Nickel ...
HUMMEL
Operating temperature: -40 °C - 125 °C
... M12 Power coupler connector Housing type - Coupler Material housing - brass,Zinc Die Cast Material housing surface - Nickel ...
HUMMEL
Operating temperature: -40 °C - 125 °C
... M12 Power panel connector Material housing - Copper-Zinc alloy Material housing surface - Nickel Seal type - Seal Material seals/o-rings - FKM (FPM),NBR ...
HUMMEL
Primary current: 3, 5 A
Voltage: 220 V
Operating temperature: -30 °C - 85 °C
... times Waterproof Rating: IP67 Cable Max. Dia: 2pin/4pin: Ø 6mm Pins Range: 2,4 pin Certificate: CE; RoHS Waterproof Connector - Available Cable Sizes: 2x0,75, 4x0,50 - Available pin Sizes: 2,4 Application Area: LED technologies, ...
Primary current: 14 A
Operating temperature: -40 °C - 125 °C
... Current Rating: 14 Amp maximum Insertion force: Max. 8 N Contact Resistance: Max 3 mΩ (test current 10 mA) Superseal Connector: - Available Cable Sizes: 2x0,50,2x0,75 2x1 / 3x0,50,3x0,75,3x1 / 4x0,50,4x0,75,4x1 - Available pin ...
... tin plated Cu/Sn, contact sleeve of Cu pipe. Insulation halogen-free PC, not Easy-entry. Pre-insulated through connector for 0.25-0.75 mm² cable. Used with certified tool DSA0115. s (mm) - strip length: 7 Insulation material: ...
Elpress
... contact sleeve of Cu pipe. Insulation halogen-free PA, hot melt adhesive inside the isolation. Insulated heat shrink connector with hot melt adhesive for 0.5-1.5 mm² cable. Used with certified tool GSW0560C. d (mm): 3.7 L ...
Elpress
... Material: Cu, tin plated Cu/Sn. Insulation halogen-free PA, Easy-entry. Fully insulated end connector sleeve for 1-3 mm² cable. Used with certified tool GSA0760. s (mm) - strip length: 8 Insulation material: PA Insulation ...
Elpress
Primary current: 2, 4 A
Voltage: 30, 300, 60 V
... Plug-in Connector straight with Cable available in different sizes Halogen, silicone and PVC free Suitable for drag chains (10xØ) ...
Primary current: 4, 2 A
Voltage: 60, 30, 300 V
... Plug-in Connector angled with Cable available in different sizes Halogen, silicone and PVC free Suitable for drag chains (10xØ) ...
Primary current: 4 A
Voltage: 60, 125, 32, 30 V
... Plug-in connector for flexible fabrication on-site Time-saving fabrication without stripping insulation from individual wires ...
... General features ✔ Tin-plated copper. ✔ Barrel with funnel entry. “N” single crimp series: ✔ Polyamide insulation sleeve. ✔ Max. operating temperature: +105°C. ✔ “Easy entry” conical entry. ✔ Flammability rating: UL94V2. “51000” double crimp ...
MECATRACTION
... Crimping Splices with Duall-wall Heat-shrinkable Insulation General features The crimping splice with waterproof seal is a connection made of a duall-wall heat-shrinkable insulation containing a thermoplastic adhesive integral with a tin-plated ...
MECATRACTION
... Connectors for Wiring Photovoltaic Panels General features ✔ Contact material: silvered copper ✔ Box material: Polycarbonate / Polyamide ✔ Contact diameter: 4 mm ✔ Acceptable wire sizes: 4 to 6 mm² ✔ Cable insulation diameter: ...
MECATRACTION
Primary current: 0 A - 40 A
Voltage: 12 V
Operating temperature: -70 °C - 450 °C
... Overview
Ceramic‑to‑Metal and Glass‑Ceramic‑to‑Metal multipin feedthroughs are hermetic electrical feedthroughs with two or more conductors, designed to transmit instrumentation signals, voltage and/or current into high‑vacuum and ultra‑high‑vacuum ...
Xiamen Innovacera Advanced Materials Co., Ltd
Pitch: 1.27 mm
... Product overview
The micro rectangular hermetic
connector uses glass-sintered sealing between the metal shell and contact pieces to ensure hermeticity. This
connector series provides circuit connections between ...
Xiamen Innovacera Advanced Materials Co., Ltd
Voltage: 500 V - 1,500 V
Operating temperature: -55 °C - 230 °C
... pressure-bearing connectors use glass/ceramic-to-metal sealing technology to provide reliable signal transmission and pressure resistance under high temperature and high humidity. Typical variants include single-core sealed connectors ...
Xiamen Innovacera Advanced Materials Co., Ltd
Primary current: 4 A
Voltage: 10 V - 30 V
Operating temperature: -25 °C - 90 °C
... Straight in d.c. • Moulded with cable • According to EN 60947-5-2 • General Features: Female connectors of this section can be matched to the proximity sensors as indicated on the ordering references tables of the products. They ...
BDC ELECTRONIC S.r.l.
Primary current: 4 A
Voltage: 10 V - 30 V
Operating temperature: -25 °C - 90 °C
... • Angled in d.c. • Moulded with cable • According to EN 60947-5-2 General Features: Female connectors of this section can be matched to the proximity sensors as indicated on the ordering references tables of the products. They must ...
BDC ELECTRONIC S.r.l.
Primary current: 4 A
Voltage: 0 V - 75 V
Operating temperature: -25 °C - 90 °C
... Straight in d.c. • Moulded with cable • According to EN 60947-5-2 • Technical data: • Operating voltage: max 50 Vac/75 Vdc • Maximum current: 4 A • Contact resistance: ≤ 5 mΩ • Contacts: CuZn, brass pre-nickeled and gold plated (0,8 µm) • Moulding: ...
BDC ELECTRONIC S.r.l.
