In-line flow meters

Process temperature: 0 °C - 870 °C
Process pressure: 0 bar - 1,378.95 bar

The V-Cone Flow Meter is an advanced differential pressure instrument, which is ideal for use with liquid, steam or gas media in rugged conditions where accuracy, low maintenance and cost are important. With its DP built-in flow conditioning design, the ...

Process pressure: 0.6 mbar - 4 mbar
Precision: 0.2 %

... Electromangnetic working principle Analog or digital output options 220VAC or 24VDC power supply IP65 protection class Robust housing Excellent flow mesurement accuracy, can measure duplex flow, electromagnetic debimeter with 4-20mA and other outputs General ...

Volumetric flow rate: 0.5 l/min - 150 l/min
Process temperature: -40 °C - 125 °C
Process pressure: 0 bar - 18 bar

The vortex flow sensor type 200 is based on the Kármán vortex street. You can choose between various versions as integrated temperature measurement. This flow sensor without moving parts is insensitive to pollution and persuade by very few loss of pressure ...

Volumetric flow rate: 0.8 l/min - 630 l/min
Process temperature: 0 °C - 90 °C
Process pressure: 0 bar - 16 bar

... Ultrasonic flowmeter combines temperature-compensated measurement for various media with IO-Link A PC interface enables measurement of media-specific volume flows even at changing temperatures Whether in the pharmaceutical industry, water treatment ...

Volumetric flow rate: 0 l/min - 700 l/min
Process temperature: -10 °C - 125 °C
Process pressure: 25 bar - 40 bar

... Meters of the Flowal® series are based on a robust concept with simplicity and can be adapted to a wide field of applications. The innovative design is the result of merging long years experience with the latest technologies. The OR series are compact ...

... MINISONIC 600 and MINISONIC 2000 are accurate and economical instruments for the flow or volume measurements of liquids in full pipes. These ultrasonic instruments resolve in that way most of industrial needs. In standard they offer : a display of the ...

Volumetric flow rate: 90 m³/h - 1,195 m³/h
Process temperature: -20 °C - 60 °C
Process pressure: 0 bar - 16 bar

... Compact sensor for measuring compressed air or nitrogen. The innovative VA 525 combines modern digital interfaces for connection to an energy monitoring system with a small, compact design. The VA 525 is always used when many machines (compressed air ...

Process temperature: -20 °C - 60 °C
Process pressure: 10,000 Pa

... APPLICATION One instrument for measurement of pressure, air flow, temperature and relative humidity Is tested to comply with standards for ’Ventilation for buildings – test procedures & measuring methods for handing over installed ventilation and air ...

... VAF Instruments positive displacement liquid Flowmeters are the most accurate volumetric measurement system for your installation. Highly accurate measurements for a wide range of liquids from low-density to vicious petrochemical products. The volumetric ...

Mass flow rate: 0 kg/min - 200 kg/min
Process temperature: -196 °C - 400 °C
Process pressure: 0 bar - 882 bar

... The RHM 15 is an all-purpose meter suitable for liquid processing plants. A wide application flow range capability allows for commonality of installation across numerous lines – a real benefit to owners and operators. Materials: SS 316L / SS 316Ti, ...

Volumetric flow rate: 0 l/min - 17 l/min
Process temperature: -20 °C - 80 °C
Process pressure: 0 bar - 15 bar

... Flow monitor and indicator for liquids and gases Easy installation Small size Low pressure drop div. Options Operation: The 2100, 2150, 2300 and 2340 flow monitors operate on the float measuring principle. ...

Volumetric flow rate: 30 l/h - 7,500 l/h
Process temperature: 0 °C - 100 °C
Process pressure: 0 bar - 12 bar

The Series 3000 range of Variable Area Flowmeters provide a cost-effective means of ensuring accurate flow measurement for most process gases and liquids. They feature a scale length of 260mm which ensures excellent resolution via easy-to-read scaled ...

... • Venturi Nozzles • Calculation, Design and Manufacture to BS EN ISO 5167:1 • Fabricated from Plate or Machined from Bar/Forgings • Range of Material Grades • Pipe Sizes from 50 mm to 1200 mm • Calibration Service on Request There are two common ...

Process temperature: 20, 60, 100 °C
Process pressure: 1,013 mbar

... The MPB Series 1700 Variable Area Flowmeter offers an economical solution for the instantaneous reading of a wide range of flows including most process gases and liquids. The MPB Series 1700 Variable Area Flowmeter is ideally suited where highly corrosive ...

Process temperature: 0 °C - 49 °C

... Bubbler level sensing provides the most accurate measurement. Teledyne Isco 730 Bubbler Flow Modules use an internal air compressor to force a metered amount of air through a bubble line submerged in the flow channel. By measuring the pressure needed ...

Volumetric flow rate: 0 l/min - 300 l/min
Process temperature: 0 °C - 50 °C
Process pressure: 0 bar - 34.47 bar

... High purity flow path. Outstanding performance, reliability, and repeatability. Fast responding, repeatable delivery of process gases with high and ultra-high levels of purity—that’s the performance the GF100 series of metal sealed mass flow controllers ...

Volumetric flow rate: 0.1 l/min - 45 l/min
Process temperature: 0 °C - 121 °C
Process pressure: 0 psi - 100 psi

... model F single flow tube all PTFE/PCTFE in line rotameter Design Features chemically inert components removable protective shield individually leak tested vertical in-line Made entirely of PTFE and PCTFE, the model F flow meter is excellent ...

Process temperature: -10 °C - 70 °C
Process pressure: 20 bar - 300 bar

... The DropsaDLFM allows precise monitoring of dual line systems. It can be piped in-line into the dual line system anywhere and measures the amount of flow being injected downstream. Typical applications in the steel industry can see the unit installed ...

With an unmatched accuracy level of 1% of Full scale on the dynamic control range, the M330B Low Pressure Drop Thermal Mass Flow Controller is one of its class. It is very specifically designed for sensitive applications where a low pressure drop across ...

Process pressure: 0 bar - 15 bar
Precision: 5, 10 %
Repeatibility: 1.5, 0.5 %

... Demanding applications across industries at up to 5 ml/min Designed for integration in demanding flow control systems, the SLI liquid flow meter series is a high precision solution for low flow rates of liquids based on water or hydrocarbons (alcohols, ...

Volumetric flow rate: 0.1 l/h - 1,000 l/h
Process temperature: -20 °C - 80 °C
Process pressure: 0 bar - 15 bar

... Control panels, pilot plants, measurement and control on machinery, water purification (osmosis), control of gas burners, industrial and process refrigeration, treatment ovens. Materials Flow tube: borosilicate glass Wetted parts: EN 1.4404 (SS 316L) Float: ...

Volumetric flow rate: 0 l/min - 420 l/min
Process temperature: 0 °C - 90 °C
Process pressure: 0 bar - 420 bar

... High accuracy turbine flow meters with built-in loading valve and thermistor, for use with hydraulic fluids. Flows up to 400 lpm (100 US gpm). For use with oils, fuels, phosphate-esters Bi-directional loading valve with INTERPASS(TM) burst disc ...

Process temperature: 0 °C - 50 °C
Process pressure: 0.2 bar - 11 bar
Precision: 1, 2, 3 %

... The red-y compact series mass flow meters are characterized by powerful technology, intelligent functions and innovative design. The devices offer a new level of ease of use: compact design with battery power, backlit touch display and extended alarm ...

Mass flow rate: 325 kg/h
Volumetric flow rate: 325 l/h
Process temperature: -60 °C - 200 °C

The TRICOR PRO TCMP 0325 Coriolis meter is a combination Density meter and Mass Flow Meter with a maximum mass flow rate of 325 kg/hr (12 lb/min) or 49 bbl/day, and a nominal size of DN4 (1/8”) that provides native measurement outputs of density, mass ...

Process temperature: 0 °C - 40 °C
Process pressure: 0 bar - 1.96 bar

... The FX Series gravity flow detectors employ a precision differential pressure transducer to detect liquid level variations in a measuring cylinder. The detectors are capable of measuring instantaneous and cumulative fuel flow. Applicable Fluids Gasoline, ...
