Quick-release exhaust valves

DN: 15 mm - 150 mm
Pressure: 10 bar - 40 bar
Temperature: -60 °C - 350 °C

The sliding gate motor valve type 8037 is suitable for the intended use in potentially explosive atmospheres according to Directive 94/9EG. Media such as steam, liquids, gases etc. can excellently be controlled with this ...

DN: 15 mm - 250 mm
Pressure: 10 bar - 100 bar
Temperature: -60 °C - 350 °C

... type 8037 sliding gate motor valve is suitable for use in potentially explosive atmospheres in accordance with Directive 94/9EG. Media such as steam, liquids, gases etc. can be excellently controlled with this motor ...

Pressure: 15 psi - 150 psi
Flow rate: 220, 250, 140 l/min

The MEV-2 threaded exhaust valve provides air flow of scfm @ 50 psig; 9scfm @ 100 psig (exhaust rate); 220 l/min @ 6 bar. Force at 50 psig, opens after approx 5 psig drop; and force at ...

DN: 0.125, 0.25 in
Pressure: 15 psi - 150 psi
Flow rate: 0 l/min - 1,600 l/min

The JEV-F2F2 brass exhaust valve is designed with a molded Buna-N seal. The model has a pressure capacity ranging between 15 psig to 150 psig (1.03 bar to 10.34 bar). It is also capable of flow rates ...

DN: 5 mm - 12.7 mm
Pressure: 200 mbar - 16,000 mbar
Temperature: 0 °C - 80 °C

... and VSO quick exhaust valves are commonly used to increase the speed of cylinders or for rapid depressurisation of tanks containing compressed air. Mod. VSO 425-M5, VSO 426-04: they ...

DN: 4, 8, 6 mm
Pressure: 1 bar - 10 bar
Temperature: -20 °C - 60 °C

The VSR L quick-exhaust valve belongs to the LINE ON LINE® family, which means it can be connected to all the other components in series or in parallel.Available in the version for pipe-pipe ...

DN: 6, 8, 4 mm
Pressure: 1 bar - 10 bar
Temperature: -20 °C - 60 °C

The VSRR L quick-exhaust valve with regulated exhaust belongs to the LINE ON LINE® family of products and can be linked in series or in parallel to all the other products. ...

DN: 0.125, 0.25, 0.5 in
Pressure: 0.5 bar - 12 bar
Temperature: 0 °C - 80 °C

... more compact and lighter version. Used to evacuate air in the cylinder quickly, which increases cylinder speed. EAN code: 8024986179057 Quantity per package: 20 Minimum order quantity: 20 Unit of measure: items Functional ...

DN: 6, 4, 8 mm
Pressure: 10, 6 bar
Temperature: -5 °C - 50 °C

QUICK EXHAUST VALVE ► For higher piston speeds for cylinders ► To bring about quick-action ventilation, the valve must be installed as close to the ...

Pressure: 2 bar - 10 bar
Temperature: -10 °C - 70 °C

The quick exhaust valve allows to exhaust the air in the cylinder to increase the speed. We suggest the mounting directly on the cylinder’s supply

DN: 0.125 in - 1 in
Pressure: 2 bar - 10 bar
Temperature: -20 °C - 180 °C

Airwork’s VRX quick exhaust valves allow the possibility (if mounted on a pneumatic cylinder) to discharge rapidly the pressure contained inside it. Thanks to the material used for their ...

DN: 3 mm - 12 mm
Pressure: 0.1 MPa - 0.7 MPa
Temperature: 5 °C - 60 °C

... drive cylinder. Possible to control high-speed cylinder. Exhaust needle valve type, whose exhaust port incorporates throttling function, is available. Tube O.D. 3mm is available ...

By installing near the actuator, it prevents dew condensation caused by adiabatic expansion. Available tube OD size: 4mm and 6mm.

DN: 0.125 in - 1 in
Pressure: 1 bar - 10 bar
Temperature: -10 °C - 70 °C

Series of quick exhaust valves in nickel-plated brass and in stainless steel

DN: 0.5, 1, 0.125, 0.25 in
Pressure: 1 bar - 10 bar
Temperature: -10 °C - 70 °C

Quick exhaust valves SR are used to exhaust the pressure of the chambers of a pneumatic cylinder directly into the atmosphere, growing the speed of the cylinder to ...

DN: 0.125 in - 0.75 in
Pressure: 2 bar - 10 bar
Temperature: -20 °C - 80 °C

Quick Exhaust Valve This valve can easily vent the circuit in case of an air supply failure. If assembled on the cylinder port, it increases the cylinder speed. DATASHEET Recommended ...

DN: 0.125 in - 1 in
Pressure: 0.8 bar - 10 bar
Temperature: 0 °C - 70 °C

... unidirectional connection, non-return valves, slide valve, quick exhaust valve Flow regulators 041, 042, 043 Unidirectional flow regulator (block ...

DN: 100 mm - 3,000 mm
Pressure: 16, 10, 25 bar
Temperature: -40 °C - 200 °C

... be used as a safety valve (positive safety valve able to close even in case of tampering) In addition to the above mentioned technical advantages there is a remarkable economical benefit as this valve ...
