Load: 0 kg - 28 kg
Stroke: 210 mm - 370 mm
Telescopic slides GN 1400 are installed vertically and in pairs. The stroke reaches ≈ 75 % of the nominal length l1 (partial extension). With type A without rubber stop, the end stops are made out of ...
Load: 0 kg - 325 kg
Stroke: 298 mm - 1,504 mm
Telescopic slides GN 1440 are installed vertically and in pairs. The stroke reaches ≈100 % of the nominal length l1 (full extension). Patented plastic ball cages ensure extremely smooth running of the ...
Stroke: 600 mm - 1,200 mm
Length: 300 mm - 600 mm
Width: 45.4 mm
Stainless steel telescopic slides GN 1450 are installed vertically and in pairs. The stroke reaches ≈ 100 % of the nominal length l1 (full extension). The telescopic slides ...
... and durability are the hallmarks of KIPP telescopic slides. Stainless steel KIPP telescopic rails are increasingly being used in food-related mechanical engineering and plant construction. ...
Stroke: 150 mm - 232 mm
Length: 214 mm - 342 mm
Width: 27 mm
Material: Steel slides. Plastic ball cages. C-steel balls. Version: Slides electro zinc-plated. Balls hardened. Note for ordering: Supplied in pairs Note: On slot-mounted telescopic ...
Stroke: 310 mm - 910 mm
Length: 310 mm - 910 mm
Material: Steel slides. Plastic ball cages. C-steel balls. Version: Slides electro zinc-plated. Balls hardened. Note for ordering: Supplied in pairsNote:On telescopic slides ...
Load: 280 kg
HTS ball bearing telescopic slides are a high quality low cost solution for drawer applications. Quiet, rigid and smooth – HTS delivers smooth, low friction motion across the complete travel length. ...
Load: 78 kg - 100 kg
Stroke: 340 mm - 733 mm
Length: 300 mm - 700 mm
... Note: On telescopic slides with over-extension, the travel is greater than the installed length. Latches in closed position. The dynamic load capacity of the telescopic slides ...
Stroke: 232 mm - 966 mm
Telescopic rails, double-T form Material: Rail and race ball-bearing steel. Balls, ball-bearing steel. Ball cage steel. Version: Rail, runner and ball cage galvanized. Race inductively hardened. Balls hardened. Note: Full ...
Load: 13 kg - 20 kg
Telescopic slides, steel for side mounting, full extension, load capacity up to 20 kg Material: Slides steel. Ball cages steel. Balls, steel. Version: Slides ...
Load: 0.3 kg - 2.5 kg
Length: 130 mm - 1,170 mm
• If you are planning to combine several options, please contact our application engineering division. • For technical information see Chapter 4 (page 40). • Double stroke (option VR): In order to obtain the double stroke and allow ...
Load: 12 kg - 45 kg
Stroke: 147.5 mm - 554 mm
Load: 50 kg
Stroke: 140 mm - 711 mm
Load: 35 kg - 65 kg
Stroke: 304.5 mm - 698 mm
Load: 250 kg
Stroke: 471.4 mm
heavy duty, full extension ball-bearing slide (3 pieces), front disconnect and positive stop
Load: 43 kg
Stroke: 304.8 mm
3/4 extension ball-bearing slide (2 pieces), front disconnect
Load: 59 kg
Stroke: 378 mm
full extension ball-bearing slide (3 pieces), front disconnect and positive stop
Load: 0 kg - 5.5 kg
Pocket door slide • Maximum door weight 5.5kg • Vertical or horizontal use Notes: • Wood thickness should be 16 - 24mm • Maximum door height 900mm • Hinges, base plates and follower strip not supplied • Follower strip ...
Load: 0 kg - 100 kg
Interlock slide (anti-tilt) with locking option • Load rating up to 100kg • 100% extension • 19.1mm slide thickness • Suitable for drawers up to 800mm wide • Hold-in Kit includes: 1 x interlock ...
Load: 0 kg - 150 kg
... rating up to 150kg • 100%+ extension • 26.5mm slide thickness • Stainless steel ball retainer and ball bearings • Corrosion resistant Notes: • The load rating is based on slides mounted 600mm apart. ...
Stroke: 20 mm - 508 mm
The Slide Rail is a low-priced limited-type linear guide made of steel plate precision-formed by rolling. Thin, compact and easy to install, this product is suitable for linear guides for various applications.
Load: 100 lb
Designed for use in supply carts or installations that require interior and exterior access such as drawers or trays used at a drive-through pharmacy or bank. Two-way travel and full extension. Load Rating: 100 lbs. Full extension ...
Load: 6 kg - 13 kg
This telescopic slide has 2 elements made of colourless anodised aluminium and offers a partial extension. Very compact, it is designed for light loads.
Load: 35 kg
Width: 9.5 mm
... cycles the slide is required to make. Thomas Regout distinguishes the type of usage between dynamic use and static use. Other factors that influence the load capacity are the features the slide is equipped ...
Load: 280 kg
Working temperature: -4 °C - 55 °C
... travel length. Telescopic Ball Bearing Slides HTS line of telescopic ball bearing slides includes 5 different series ranging from super slim lightweight versions ...
EXTERNAL, AIR CYLINDER LINEAR THRUSTER SLIDES FOR MACHINING & PICK-AND-PLACE - ROBOHAND DESTACO's Robohand DLT-T/A/N external air cylinder linear thruster slides are highly configurable with a wide ...
Load: 45 kg - 50 kg
Length: 300 mm - 650 mm
Working temperature: -20 °C - 70 °C
Self Close Telescopic Slide DZ3832-HDSC facebook sharing buttonlinkedin sharing buttontwitter sharing buttonsharethis sharing button Self-closing telescopic slide DZ3832-HDSC ...
Stroke: 50 mm - 150 mm
Telescope spindle axis SA-1 •Extremely compact •Flexible motor mounting •Precise spindle drive Telescope spindle axis SA-3 •Extremely compact •Flexible motor mounting •Precise spindle drive Telescope spindle axis SA-6 •Extremely ...
Load: 0 kg - 60 kg
Ball bearing slide Load capacity up to 60 kg per pair Slide length 250 – 500 mm Smooth and silent running Travel up to 80% of slide length For more than 40 years, Schock has been ...
Load: 800 lb
Stroke: 500 mm
P5 & P7 feature composite bearing ways, hard chrome shafts, double seals. Way covers not required. Lube free! Least expensive and most durable.
Load: 45 kg
Three-section Slide Rail The AOSITE three-section steel ball slide rail relies on precision steel balls and runs in the slide rail track. The load applied to the slide ...
Load: 120 kg - 140 kg
Stroke: 600 mm - 1,600 mm
The MX-DTP 30 fully extending rails offers high load capacity in a small footprint. Depending on the length, it is fastened by 4 or 6 M5 threaded holes in the middle. Extension length = installation length Overall length = installation ...
Load: 225 lb
... weld jig alignment Specifications: Standard Mounting Tab system allows for quick installation and flexibility in drawer slide model selection cabinet profile is powdercoated, drawer profile is uncoated (raw) to ...
Load: 29, 39, 20 kg
Stroke: 151, 117, 77 mm
NEW FOR 2015! ENGRENAGES HPC has widened its range of telescopic glide rails by adding a miniature version suitable for use in smaller pieces of furniture. General Characteristics: - Manufactured from aluminium - 3 ...
Your suggestions for improvement:
A telescopic slide extends to allow a drawer to be opened or to guide the movement of a heavy element not exceeding its load capacity.Applications
These devices are part of drawer opening mechanisms. In general, they guide the horizontal or vertical movement of heavy elements. Such mechanisms are often used for the vertical movement of touchscreen panels. They are also used to protect machine tool mechanisms from shavings or liquids, and to ensure operator safety.Technologies
These devices usually consist of three tracks made of stainless, electro-galvanized or anodized steel, or of aluminum. The nested rails slide within each another on ball bearing wheels or slider belts. Other models use recirculating ball bearing units or ball cages.
Runner extension is partial or complete. Those with two-way travel can be opened from either side. Set positions are stabilized by track configuration, which includes stops. Drawer opening can be facilitated by a reverse release mechanism and its closure can be cushioned. Vertical, or guillotine models have springs to counterbalance the load.
Choice depends primarily on maximum slide extension, expressed as a percentage, and on maximum load capacity.
Receive updates on this section every two weeks.
