Wire-to-board connectors

Voltage: 250 V
Pitch: 2 mm

HIROSE Electric Co. Ltd, a world-class manufacturer in connectors, introduced the DF51K series of robust Wire-to-Board Connectors for applications requiring more strength and durability. A wide range of applications are suitable ...

Current: 0.45 A
Voltage: 30 V
Pitch: 0.4 mm

Features 0.4 mm Pitch, 1.5 mm Mated Height, Board-to-Fine Coaxial Cable Connectors 1. Small mated height and board occupied space 2. Enhanced shielding and ground connections 3. Reliable lock 4. Reliable electrical and mechanical ...

Current: 0.35 A
Voltage: 30 V
Pitch: 0.3 mm

Contact pitch (mm): 0.3 Termination AWG: 42-44 PCB mounting style: SMT Mated height (mm): 1.5 Number of contacts: 30, 32, 40 Rated voltage: AC 30V Current rating (Amps): AWG 42: 0.15, AWG 44 0.10 Notes: Enhanced ...

Data rate: 2 GB/s

Smiths Interconnect offers a complete line of differential Twinax and Quadrax connectors, contacts and cable assemblies for high speed Ethernet, Firewire, and Fibre Channel applications. Differential pair quadrax and twinax connectors ...

IDC connectors With strain relief Locking levers Flat cable

Variants that supplement standards 72 or 144 contacts

Current: 23 A

Connector, Male connector, Thermoplastic resin, glass-fibre filled, Black, Motherboard to daughtercard, Press-in termination, Rated current: 23A

Current: 25 A

Amphenol Sine Systems’ BoardLock™ Family combines flanged or flangeless, 180° straight or 90° right angle pin-oriented, wire-to-board versatility with the proven reliability of the A Series™ environmentally-sealed thermoplastic connection ...

Pitch: 2.54 mm

Odu's Flakafix system provides an efficient solution for PCB connections. The connector links the board up to the wire, and is characterized by contact protection that enables reliable long-term operation. It also provides low transfer ...

Pitch: 1.27, 2.54 mm

The Mini Flakafix® engineered by ODU, is a PCB wire-to-board connector intended for connecting printed circuit boards over large distances as well as under user-defined and replaceable angles. In addition, the contact between the card ...

Pitch: 0.8 mm

Current: 1 A
Voltage: 250 V
Pitch: 1 mm

PH1.0mm wafer, dual row, horizontal SMT type wafer connectors Specifications: Rating current: 1.0AMP AC/DC Contact resistance: 20mΩ max Withstand voltage: 250V AC/minute Insulation resistance: 100mΩ min Operation temperature: ...

Current: 1 A
Voltage: 100 V
Pitch: 1 mm

PH1.0mm Wafer, Single Row, Horizontal SMT Type Wafer ConnectorsSpecifications: Rating current: 1.0AMP AC/DC Rated voltage: 100V AC/DC Contact resistance: 20mΩ max Withstand voltage: 250V AC/minute Insulation resistance: 100mΩ min Operation ...

Current: 1 A
Voltage: 100 V
Pitch: 1.25 mm

PH1.25mm Wafer, Single Row, Horizontal Type Ultra-thin A1254 Wafer Connectors Specifications: Rating current: 1.0AMP AC/DC Rating voltage: 100V AC/DC Contact resistance: 20mΩ Max Withstand voltage: 500V AC/DC Insulation resistance: ...

Current: 1 A
Voltage: 100 V
Pitch: 1.25 mm

Crimp housings 1,25 mm pitch. Compatible with industries standard. Gender Female Pitch (mm) 1,25 Mating pin size (range) 0,30 Cable termination Crimp Orientation to PCB P - Parallel V - Vertical No of contacts 2, ...

Current: 1 A
Voltage: 125 V
Pitch: 1.25 mm

Crimp housing 1,25 mm pitch for male contacts to be used in wire to wire applications. Gender Male Pitch (mm) 1,25 Mating pin size (range) 0,30 Cable termination Crimp Orientation to PCB P - Parallel V - Vertical ...

Current: 1 A
Voltage: 230 V
Pitch: 1.27 mm

High density transmission connectors. These parts are compatible with industries standard products. Recommended cable: AWG 28 flat ribbon cable 1,27 mm pitch. Pitch (mm) 1,27 Cable termination IDC Board termination T - Through ...

Current: 7 A
Voltage: 250 V
Pitch: 4.2 mm

Transfer rate up to 7A Low engagement terminals Fully insulated terminals Designed for high current/high density applications For wire-to-wire and wire-to-board applications Locking function

Current: 0.8 A - 1 A
Voltage: 50 V
Pitch: 1 mm

Pico-Clasp Wire-to-Board Connectors Molex’s core 1.00mm-pitch, wire-to-board Pico-Clasp Connectors offer a versatile system that offers a variety plating and design options, ideal for nearly all applications The Pico-Clasp 1.00mm-pitch ...

Current: 0.5 A
Pitch: 0.05 in

The 3M™ PAK 50 Series is an EMI shielded Board Mount Plug that is compatible with P50 Series cable mount sockets. It is designed to be highly durable with materials such as glass filled nylon for insulation, phosphor bronze for the contact ...

Current: 5, 2.5 A
Voltage: 32 V
Pitch: 2.5 mm

DESCRIPTION OF SYSTEM Wire to Board socket connectors (WtB) •Crimp version for indirect connections, wire range 0.12 - 0.5 mm² •IDC version for direct and indirect connections, wire range 0.14 - 0.25 mm² •Suitable for terminating ...

Current: 8 A

compact cable mating system for highly loaded connections straight and angled male terminal strips female terminal strips with 90° and 180° cable outlet variable wire diameters Koshiri reliability housing latching compliance to ...

Product Type Features Connector Style : Receptacle Connector System : Cable-to-Board Sealable : No Connector & Contact Terminates To : Printed Circuit Board Center Ground Plate : Without Configuration Features ...

Current: 1.2 A
Voltage: 32 V

Micromodul™ solder-in connector, insulation displacementtechnology (IDT) ,solder contacts dual row staggered

Current: 9 A
Voltage: 600 V

Minitek® Pwr 4.2 connectors are designed for power application with current rating up to 9A per circuit, available for dual row and 2 to 24 circuits, for wire-to-board, wire-to-wire, and wire-to-panel mount application. Crimp, snap-in ...

Current: 1 A
Voltage: 50 V
Pitch: 1 mm

Wafer straight SMT type with walls Technical specifications Current rating : 1 A AC, DC Voltage rating : 50 Volts AC, DC Dielectric withstanding voltage : 500 Volts AC during 1 mn Insulation resistance : > 100 MΩ Contact resistance ...

Current: 16 A
Voltage: 300 V

The MPE Series, manufactured by Deca, is a euro type terminal block equipped with a tape-on-reel filling and compact rolls. The terminal block has a maximum nominal and load current of 16 amperes, and a nominal voltage of 300 V. Additionally, ...

Current: 0.3 A
Pitch: 0.5 mm

Supporting discrete cables (#36 AWG) and utilizing technology for the assembly of fine wiring as perfected in our current SSL Series (0.5mm pitch connectors for ultra-fine coaxial cables), the 0.5-mm pitch connectors of the DCC Series ...

Current: 15 A

PW01 Series Pin connector (pin header) is press fit type (finish diameter: 0.82 to 0.98), and the mounting pitch is 2.54mm. For three contact connector, a wire relay connector is available. Mold latch ensures complete mating and unmating. Highly ...

Current: 13 A
Voltage: 600 V
Pitch: 6.35 mm

Wire-to-Board Connectors 6.35mm Pitch Shell Thermoplastic, rated UL94 V-2 Contact Material Copper alloy Applicable wire AWG 12 ... 24 Contact Resistance 500MΩ Test Voltage 1kVDC Voltage Rating 600VAC Current Rating 13A (02-04 pos.); ...

- Connect directly to PV modules or strings fitted with Sunclix plugs and sockets. There’s a number of different Solar PV installation in current use. Often, their leads connecting the array to the inverter are different too. You may ...
