Panel meter with LED display CS2-VA

currentvoltage4-digit

CS2-VA 4 2/3 Digits Voltage/Current Meter (96x48mm) Designed with high accuracy measurement, display and communication of 0~600V or 0~10A for DC/AC/TMRS. ● ADTEK builds flexible function as like as 3 bank (for multi-range scaling and set point) and 3 external control inputs meet to various testing equipment inquiry. They are also build in 4 Relay outputs, 3 External Control Inputs, 1 Analogue output and 1 RS485 (Modbus RTU Mode) interface with versatile functions such as control, alarm, re-transmission and communication for a wide range of industrial applications. Summary of specifications ● Measuring Voltage 0~600V or Current 0~10A for DC / AC / TRMS ● Optional 4 banks pre-set for all relay functions are relative to 4 difference scaling, and selectable by 3 External Control Inputs(E.C.I.) or front key ● 4 relay can be programmed individual to be a Hi / Lo / Hi Latch / Lo Latch / Go energized with Start Delay / Hysteresis / Energized & De-energized Delay functions, or to be a remote control. ● Analogue output and RS 485 communication port in option ● 3 external control inputs can be programmed individual to be Relative PV (Tare) / PV Hold / Maximum or Minimum Hold / DI (remote monitoring) / Reset for Relay Energized Latch…. ● CE Approved & RoHS
