Compressed air nozzle TV-R

blow-offstainless steelaluminum

Adjustable Transvector Jet – Blowing, Suction and Air Amplification The Adjustable Transvector Jet TV-R series is an innovative solution for industrial blowing, suction, cooling and air amplification. Designed to deliver an airflow amplification ratio up to 25:1, it optimizes compressed air consumption while ensuring maximum efficiency. Available in anodized aluminum (AL) or stainless steel (SS), this air nozzle guarantees durability and resistance, even in demanding industrial environments. With a G 1/8” connection and a Ø 9.5 mm outlet, it is easy to install and compatible with most pneumatic systems. Key Benefits of the TV-R Transvector Jet : - Easy and precise adjustment of the airflow by rotating the nozzle. - Reduced compressed air consumption (140 to 490 Nl/min at 4 bar). - Versatile applications: blowing, drying, cooling, suction of fumes or dust. - Robust design with high-quality materials (anodized aluminum or stainless steel). - Noise reduction compared to conventional air nozzles. Typical Industrial Applications : - Removal of chips, dust or sawdust. - Rapid cooling of parts, molds or components. - Drying after washing or machining operations. - Local suction and ventilation. - Optimization of airflow in automated machines. With the ALPHA AUTOMATISMES Adjustable Transvector Jet, you get a high-performance, economical and long-lasting solution for all your pneumatic applications.
