Corded remote control TGD-F15 CAN

with toggle switchwith configurable buttonswith rocker switch

The TGD-F15 CAN wired control impresses with its robust, functional design. 15 large push buttons arranged in three rows are easy to operate even with gloves. Each button features RGB status indication and backlighting. Labeling can be customized.

Tested according to:
• EN ISO 13849
• EN 60204-32
• EN 62061

Technical Data:
• Protocol: CANopen
• Protection class: IP65
• Temperature range: -20 to +60 °C
• Weight: approx. 300 g
• Dimensions (W/D/H): 80 x 45 x 175 mm
• Operating voltage: 10–30 VDC

Options:
• Emergency stop (2x NC)
• 15 single-step push buttons up to Cat. 1 PLc / SIL1
• Button backlighting
• Button status indication (RGB)
• Toggle switch / push toggle up to Cat. 1 PLc / SIL1
• Custom labeling
• Shoulder strap
• Wall mount

Functional design and thoughtful button layout
Robust, functional design with 15 large buttons ensures safe and precise operation – even with gloves.

Industrial-grade robustness
IP65 housing, wide temperature range, and CANopen communication ensure reliable performance in harsh conditions.

Flexible and adaptable for versatile use
Flexible configuration, custom labeling, and accessories such as shoulder strap or wall mount enhance usability and adaptability.
