pinch solenoid valve / 2-way / NC / aluminum
GEM-P

Add to MyDirectIndustry favorites
Compare this product Don’t compare this product
pinch solenoid valve / 2-way / NC / aluminum pinch solenoid valve / 2-way / NC / aluminum - GEM-P
{{requestButtons}}

Characteristics

  • Ports/positions:

    2-way

  • Function:

    NC

  • Body:

    aluminum, IP65

  • Other characteristics:

    pinch

  • Temperature:

    Max.: 80 °C (176 °F)

    Min.: -10 °C (14 °F)

  • Pressure:

    Max.: 1 bar (14.5 psi)

    Min.: 0 bar (0 psi)

  • Voltage:

    Max.: 240 V

    Min.: 6 V

Description

•Silicon tubes: 6×4, 8×5, 9.5×6.5 mm
•Pressure range: 0 – 1 bar
•Body material: Aluminium

Function2 Way NC
TubesSilicone tubes : 6x4mm, 8x5mm, 9.5x6.5mm
Pressure range0-1 bar
Temperature rangeFluid : -10ºC to 80ºC (no freezing)
Ambient : -10ºC to 50ºC
MaterialsValve: Aluminium
Solenoid Operator: Stainless Steel AISI 300 & 400 series
Materials in contact with mediaNone* fluid flows through silicone tube
ApplicationsWhere corrosive or contaminated fluidmust be controlled, such as in :
• Laboratories
• Industrial and irrigation control
• Analysis devices
Coil voltage• Voltage and power consumption - see table
• All Baccara coil voltages are ± 10% of nominal
• DC10W
• DC 14W - max 70% duty cycle
• Ton = 7 [min] max
Standard protection classIP65 with connector
* Option : IP68 (please refer to GEM-BP Coil)
