Pinch solenoid valve GEM-P

3-wayaluminiumIP65

•Silicon tubes: 6×4 mm •Pressure range: 0 – 1 bar •Body material: Aluminium Function3 Way TubesSilicone tubes : 6x4mm Pressure range0-1 bar Temperature rangeFluid : -10ºC to 80ºC (no freezing) Ambient : -10ºC to 50ºC MaterialsValve: Aluminium Solenoid Operator: Stainless Steel AISI 300 & 400 series Materials in contact with mediaNone * fluid flows through silicone tube ApplicationsWhere corrosive or contaminated fluidmust be controlled, such as in : • Laboratories • Industrial and irrigation control • Analysis devices Coil voltage• Voltage and power consumption - see table • All Baccara coil voltages are ± 10% of nominal • DC 14W - max 70% duty cycle • Ton = 7 [min] max Standard protection classIP65 with connector * Option : IP68 (please refer to GEM-BP Coil)
