AC motor ECP series
synchronous460 V575 V

AC motor
AC motor
Add to favorites
Compare this product


Characteristics

AC/DC
AC
Type
synchronous
Voltage
460 V, 575 V, 230 V
Protection class
IP55, IP66, sealed
Configuration
cast iron, stainless steel
Applications
industrial
Other characteristics
NEMA
Power

Max.: 800 ch
(800 hp)

Min.: 1 ch
(1 hp)

Rotational speed

900 rpm, 1,200 rpm, 1,800 rpm, 3,600 rpm
(5,654.87 rad.min-1, 7,539.82 rad.min-1, 11,309.73 rad.min-1, 22,619.47 rad.min-1)

Description

Baldor's extensive line of Severe Duty motors are designed to provide exceptional performance and long life in harsh industrial processing applications. These premium construction motors include features designed to protect against contamination, moisture, vibration and demanding duty cycles. Super-E electrical designs are available on Severe Duty motors to create a packaged solution that reduces energy consumption and handles the punishment of the application. Features 143T – 588 NEMA frame Division 2, Class I, Groups A, B, C and D Division 2, Class II, Groups F&G, T4 on 586/7/8 frames IP55 on 143T-L449 frames, IP66 on 586-588 frames Heavy duty ALL cast iron construction (frame, endplates, conduit box and fan covers) Premium insulations system(Class F insulation with Class B rise) Inverter ready nameplates Regreaseable bearings on all frame sizes Sealed frame units Gasketed conduit box Stainless steel nameplate Super-E® Premium efficient motors 1.15 service factor ABB smart sensor compatible 3 year warranty Common industries Chemical Industry Oil & Gas Industry Forest Products Industry Cement & Aggregate Industry Mining Industry Metals Industry Water & Waste Water Industry Common applications Compressors Pumps Fans Conveyors Gear Reducers
