Three-phase motor CFSWD series
synchronous460 V575 V

three-phase motor
three-phase motor
Add to favorites
Compare this product


Characteristics

AC/DC
three-phase
Type
synchronous
Voltage
460 V, 575 V, 230 V, 115 V
Protection class
washdown
Configuration
stainless steel, TENV, TEFC
Applications
for pumps, industrial, for the food industry
Power

Min.: 0.5 ch
(0.5 hp)

Max.: 30 ch
(30 hp)

Rotational speed

1,200 rpm, 1,800 rpm, 3,600 rpm
(7,539.82 rad.min-1, 11,309.73 rad.min-1, 22,619.47 rad.min-1)

Description

Designed for food processing where reliability and cleanability are of utmost importance in an intense, caustic cleaning environment. Baldor-Reliance Food Safe motors are designed to perform reliably- at maximum efficiency- around the clock and be effectively cleaned to a hygienic level to ensure uncompromised food safety. longer than any other industrial electric motor available today. IEC frame also available. Reliability • All stainless steel construction • Encapsulated windings and conduit box • Two barrier mechanical shaft sealing system Cleanability • Smooth contours and finish with a rotatable, round conduit box allows water and debris to shed from the housing • Independent feet allow the motor to be effectively and efficiently cleaned Flexibility & safety • Our rotatable conduit box eliminates the need to reorient the motor to match power supply • Color-coded leads are easily identifiable and make connection safer and easier • Lifting provisions on 180 – 280 frame allow for easier and safer maneuvering Features • 56C – 286TC frame • 115/230, 230/460, 575 volt • Enclosures: TEFC & TENV • IP69 for water • Inverter-duty available • All stainless steel construction • Epoxy encapsulated windings and conduit box • Two-barrier mechanical seal on the output shaft • 360 rotatable conduit box (Three phase) • Laser marked nameplate • Independently welded feet • Polished stainless steel finish • 3 year warranty Common industries • Food processing • Wastewater Common applications • High pressure washdown • Sanitary washdown • Caustic environment • Wet environments • Pumps • Outdoors
