Three-phase motor RPM XE series
synchronous380 V575 V

three-phase motor
three-phase motor
three-phase motor
Add to favorites
Compare this product


Characteristics

AC/DC
three-phase
Type
synchronous
Voltage
380 V, 575 V
Protection class
IP55, ATEX
Configuration
TEFC
Efficiency classes
IE3, IE5
Applications
for compressors, for centrifugal pumps
Other characteristics
NEMA
Power

Min.: 10 ch
(10 hp)

Max.: 100 ch
(100 hp)

Rotational speed

1,800 rpm
(11,309.73 rad.min-1)

Description

Ideally suited for continuous operation on pumps and compressors, the Baldor-Reliance® RPM XE is an innovative, NEMA drop-in replacement motor which achieves leading efficiency and lower lifetime costs. This synchronous motor is unique as it starts across the line and offers IE4+ efficiencies. The motor is also capable of operating on a standard inverter without feedback. Features • HL215T – HL405T NEMA frame • Operates at true synchronous speed regardless of load • Severe duty features and meets IP55 rating • Efficiency two to four levels above NEMA premium • Power dense and standard NEMA frame designs • Designed for across the line operation • Suitable for adjustable frequency power in scalar mode • Class H insulation system with Class B rise • Up to IE3 combined system efficiency when properly matched with VFD running in V/Hz or scalar mode • Operates at true synchronous speed regardless of load • Up to IE5 efficiency when run cross the line • Division 2/Zone 2, ATEX, IEC EXnA available • 575 and 380 volts available Common industries • Paper & Forest • Steel Industry • Water / wastewater Common applications • Centrifugal Pumps • Fans • Compressors • Continuous applications demanding the ultimate efficiency • Applications demanding reduced weight or inertia
