Hydraulic press

assemblyC-frame

Application - - Extrusion - Industry - - Electronics - Special Features - - • Thru-hole machined in bed for part extrusion • High limit controller - Intended Use - - Used to extrude epoxy resin for circuit boards in the electronics industry Custom Features: (4) 4” diameter chrome-plate guide rods with self-lubricating bronze ram guide bushings Throat Distance: 8” Stripping Capacity: 2 tons 8” x 2” thru-hole machined in bed for part clearance High limit controller with 1 zone of heat works with customer-supplied Type K Thermocouple Skid-mounted power system and reservoir Kidney loop filter/cooler circuit with oversized thermostatically controlled fan motor Light curtains guarding front and side openings of the press Oversized oil cooling system minimizes risk for overheating Calculated Ram Speeds: Fast Approach 10 – 225 IPM; Pressing 1 – 100 IPM IPM; Return 10 – 180 IPM Common Features on Beckwood Presses: Heavy duty box beam design for superior rigidity and modular tie rod assembly utilizing pre-tensioning nuts for optimum performance Fully adjustable Parker cylinders with full rated tonnage throughout the stroke PressLink Remote Support module for complementary diagnostics & troubleshooting Dual linear and pressure transducers in the main ram cylinders for optimal reliability and redundancy Allen Bradley or Siemens PLC, programmable control system with touch screen HMI and Recipe Functionality Structure designed for Infinite Life in accordance with rigorous simulation analysis through FEA (Finite Element Analysis) design testing Backed by Beckwood’s industry leading dedicated service and support team
