Dew-point data-logger METPOINT®️ BDL

flowpressuretemperature

Product overview
The METPOINT®️ BDL portable is a handheld data logger designed for mobile measurement and recording of parameters in compressed air and technical gases. It combines a 3.5" colour graphics touchscreen with universal sensor inputs and large internal storage for on-site audits and spot checks.

Description
The device offers intuitive touch operation and graphical coloured measurement curves for rapid analysis. It accepts universal sensor inputs compatible with conventional industrial transducers and can store up to 100,000,000 measured values with timestamp and measuring point. Data export is available via USB stick. The instrument is powered by an internal accumulator providing extended operating time for field use.

Applications

• Portable audits and spot checks of compressed-air systems
• Mobile quality measurements for technical gases (e.g. N2, O2)
• Verification of dryer performance and troubleshooting
• On-site flow, pressure, temperature and dew point measurements

Advantages

• Portable data recording for field inspections
• Flexible graphical representation on a 3.5" touchscreen
• Integrated data logger with large memory capacity
• Universal sensor inputs for broad sensor compatibility
• USB interface for straightforward data export
• Extended battery (accumulator) runtime for mobile use
• Fast set-up and intuitive user interface

Technical specifications

• Display: 3.5" colour graphics display with touchscreen
• Data storage: up to 100,000,000 measured values with timestamp and measuring point
• Data export: USB stick interface
• Inputs: universal sensor inputs, compatible with common industrial transducers
• Functions: graphical coloured measuring curve, integrated data logger, trend and interpretation functions
• Power: internal accumulator with extended runtime
• Typical measured parameters: flow, pressure, temperature, residual moisture / dew point
• Use cases: portable audits, spot checks and mobile compressed-air quality measurements
