Screw compressor KOMPBERG® ZXF110

airelectricstationary

Product information
BERG develops and manufactures oil-free two-stage screw compressors intended for industrial applications requiring oil-free compressed air. The ZXF110 is an air-cooled, two-stage, oil-free screw compressor designed for continuous operation with tested conformity to ISO 8573-1 CLASS 0. Each unit is factory-tested to verify specifications and operational safety.

Key features

• Oil-free two-stage screw compression
• Air-cooled system
• Designed for low operating costs and continuous industrial use
• ISO 8573-1 CLASS 0 certification (air purity)
• Factory-tested for specification compliance and safety
• Simple operation with minimal maintenance requirements

Technical data (from product table)
Oil-free two-stage screw compressor: ZXF 110
Overpressure [bar]: 8 / 10
Capacity [m3/min] [8 bar]: 18
Capacity [m3/min] [10 bar]: 15.7
Dimension (LxWxH) [mm]: 3300 x 2200 x 2000
Compressed air connection: G 2
Weight [kg]: 4370
Ambient temperature [°C]: +5 ÷ +40
Cooling air demand [m³/h]: 25000
Compressed air temperature on the outlet [°C]: approx. 10 - 15 degrees above ambient temperature
Sound level L [dB(A)]: 85
Power transmission: direct drive
Nominal motor power [kW]: 110
Nominal fan motor power [kW]: 4.0
Feed voltage [V]: 400
Recommended power feed cable [mm2]: 3x120+PE
Protection fuse [A]: 250

Specifications / technical details

• Model: KOMPBERG® ZXF110 (oil-free two-stage screw compressor)
• Overpressure: 8 / 10 bar
• Capacity at 8 bar: 18 m3/min
• Capacity at 10 bar: 15.7 m3/min
• Dimensions (L x W x H): 3300 x 2200 x 2000 mm
• Compressed air connection: G 2
• Weight: 4370 kg
• Ambient temperature range: +5 °C to +40 °C
• Cooling air demand: 25000 m³/h
• Compressed air outlet temperature: approx. 10–15 °C above ambient
• Sound level: 85 dB(A)
• Power transmission: direct drive
• Nominal motor power: 110 kW
• Nominal fan motor power: 4.0 kW
• Feed voltage: 400 V
• Recommended feed cable: 3x120 + PE (mm²)
• Protection fuse: 250 A
